INSTRUCTION MANUAL - OTAMATONE DELUXE
How to connect Headphones an AC adapter - No headphones or AC adapter included.
This is for 3.5mm stereo mini plug.
You can connect your Headphones here.
You will hear the sound from the
speaker while using headphones.
Mouth Technique does not work
Set the volume low first and then
adjust it while using headphones
It`s not unusual to hear some noises
from the amplifier or speakers
While using headphones, listening at high
volume for extended periods of time may
cause hearing impairment.
Use only the specified AC adapter
approved for use with this product.
We assume no responsibility whats-
oever for any damage or loss of the
product and/or AC adapters caused
by the use of inappropriate adapters
or by mishandling of adapters.
AC adapter specifications:
Input: AC100 - 240V, 50 - 60Hz
Output characteristics: Switching-mode
(regulated output voltage) recommended
DC plug size: 2.1mm / 5.5mm
Plug polarity: Center positive
Important Safety Instructions
Safety instructions for using AC power source:
Mishandling of power source may cause fatal accidents or serious injuries.
• Check the voltage rating before you connect the adapter to an electrical
outlet to ensure that the required voltage and frequency match the available
• Use only the specified AC adapter approved for use with this product. Wipe
off dust from the AC adapter plug to avoid electric shock or short circuit.
• Electric Shock Hazard: Do not handle the AC-adapter with wet hands.
• Unplug the AC adapter after use.
• Be sure to grasp the adapter itself, not the cable, when disconnecting
the AC adapter from the power source.
• Do not piggyback the electrical outlet. lt may cause overheating.
• Do not forcefully bend, twist, or pull the cable, or modify the cable.
• Do not put the cable under furniture, electric appliances, figurines, or any
other heavy objects. Damaged cables may cause fire or electric shock.
• Do not use any AC adapter with damaged cable.
• In the event that the AC adapter becomes damaged or the unit mal-
functions, turn the unit off and disconnect the AC adapter immediately.
