MiniPro Hard Drive Series

User Guide

(3) Connecting the Hard Drive

Connecting using USB:

1) Connect the USB connector from the USB cable to a USB port on

your computer. (If your drive includes a USB y-cable, we recommend

connecting both USB connectors for maximum power. This is generally

not necessary if connecting to a USB 3.0 integrated port.)

2) Connect the other end of the USB cable to the hard drive.

3) Turn the power switch on. Wait 5-20 seconds for the computer

to recognize the drive.

Notes:

a) Front USB ports on a desktop may not be able to provide adequate power.

b) If connecting to a USB Hub, make sure it is a powered hub (uses AC adapter).

Connecting using FireWire:

1) Connect the appropriate FireWire cable to a FireWire port on

your computer.

2) Connect the other end of the FireWire cable to the hard drive.

3) Turn the power switch on. Wait 5-20 seconds for the computer

to recognize the drive.

Connecting using eSATA:

1) Connect the eSATA cable to the eSATA port on your computer.

2) Connect the other end of the cable to the hard drive.

3) Connect power to the drive using one of the following options:

• AC Power Adapter

• DC to USB Power Cable

• eSATAp Power Cable (not included)

4) Turn the power switch on. Wait 5-20 seconds for the computer

to recognize the drive.

Note: The drive should only be connected to your computer via

one interface at a time.

The drive is pre-formatted as either NTFS (Win) or Mac OS

Extended (Mac) depending on the software included.

For users who wish to reformat the drive, please visit our

website for instructions.

To reformat using Windows:

http://oyendigital.com/FAQs.html#10

To reformat using MAC OS:

http://oyendigital.com/FAQs.html#8

Note: The drive can be used on both Windows and Mac

systems by formatting the drive as “MS-DOS (FAT32).”

Instructions are provided in the Mac OS link above.

(4) Formatting the Hard Drive (5) Using the Hard Drive (6) Disconnecting the Hard Drive

(7) Warranty Information

(9) FAQs

(8) Safety Information

Using the MiniPro with the included software

The MiniPro includes software (via download) that allows you to

easily backup your important les. The software is not required in

order to use the drive. To install the software, simply follow the

steps on the included glossy card.

Using the MiniPro without software

1) Look for the MiniPro drive in My Computer (Win) or Finder (Mac).

2) Click and hold down the mouse button on the le/folder that you

want to copy to the MiniPro drive.

3) Drag the mouse over the icon representing the MiniPro drive.

4) Let go of the mouse button and the le will copy to the MiniPro.

5) The task is complete. This is known as a "drag-and-drop" action.

Using the MiniPro with Apple Time Machine (Mac Users Only)

1) Make sure the drive is formatted as Mac OS Extended (Journaled)

as described in the “Formatting the Hard Drive” section.

2) Go to the Apple Menu > System Preferences and click on the

Time Machine icon. The Time Machine panel will then launch.

3) Click On to enable Time Machine.

4) Select the MiniPro hard drive and choose “Use for Backup.”

5) You can set additional options by clicking the Options button.

6) Time Machine is now backing up your Mac automatically to the

MiniPro hard drive.

The disk drive contained in your MiniPro is a delicate

electronic device and is susceptible to damage due to

excessive physical shock. Please handle the unit with care.

Avoid moving the drive while it is reading/writing data.

Doing so can cause corruption and/or damage to the drive.

Q: Can I use my drive with bus power only?

A: Yes, in the majority of cases bus power is adequate. However, if you

are using the drive with a hub, make sure that it is a powered hub

(uses AC adapter).

Q: Why does my computer show that the external hard drive

has less capacity than advertised?

A: In the hard drive industry the partitioned size will be less than the

printed capacity on the label. This is due to the fact that computers

calculate capacity based on a binary (base 2) method, where

1GB = 1024 MB. The hard drive industry calculates using a decimal

method, where 1GB = 1000 MB. This is why the two dierent industries

will report dierent capacities for the same drive.

Q: How do I boot in MAC OS X using the external hard drive?

A: Open Disk Utility, click the drive and select “Partition” in menu on

the right. Choose “Mac OS Extended (Journaled).” 2) Click “Options”.

If you have an Intel Mac, select “GUID” as the partition scheme. If you

have a Power PC Mac, select “Apple Partition Map.” 3) Click “Partition” ;

upon completion, install the Operating System on the external drive.

5) Upon completion, eject the external drive and reboot the Mac as

normal. 6) After reboot, connect the external drive to the computer.

Open System Preferences and click “Startup Disk.” Choose the external

drive. Conrm and click restart.

For other questions please contact tech support or visit the FAQ

section of our Web site (www.oyendigital.com/support.html).

Technical Support: tech@oyendigital.com

This product includes a three (3) year repair/replacement

warranty provided by Oyen Digital. This warranty is non-

transferable and is limited to the original purchaser. Warranty

service may be requested by completing the form at the

following link: www.oyendigital.com/rma-request-form.html

For our complete warranty policy, visit:

www.oyendigital.com/warranty.html

Windows: Close all windows and applications that are accessing

the drive. Click the green “Eject Hardware” (Safely Remove

Hardware) icon in the system tray and highlight the external drive.

Wait for a few seconds until the system prompts “You may safely

remove this device.”

MAC: Close all windows and applications that are accessing the

drive. Drag the external drive to the Trash/Eject icon to dismount it.

After the disk icon has disappeared from the desktop, you may

safely disconnect the external hard drive.

4.9 x 3.1 x 1.0 inches

6Gbps

Produkt Specifikationer

Mærke:	Oyen Digital
Kategori:	Ekstern harddisk
Model:	EN3-54-1000-M
Type:	HDD
Tænd-/slukkontakt:	Ja
Bredde:	124.5 mm
Dybde:	79 mm
Højde:	25.4 mm
Vægt:	296 g
Brugervejledning:	Ja
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-20 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 80 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
Driftstemperatur (T-T):	5 - 40 °C
USB-stik:	USB Type-A
Husmateriale:	Aluminium
Indgangsspænding for vekselstrømsadapter:	100-240 V
Frekvens for vekselstrømsadapter:	50 - 60 Hz
Kabler inkluderet:	eSATA, USB
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
HDD kapacitet:	1000 GB
USB version:	3.2 Gen 1 (3.1 Gen 1)
Understøttede Windows-operativsystemer:	Windows 7 Home Premium, Windows 8, Windows Vista Home Premium, Windows XP Home
Understøttede Mac-operativsystemer:	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Understøttede Linux-operativsystemer:	Ja
Maksimal dataoverførselshastighed:	5000 Mbit/s
Plug and play:	Ja
Ekstern strømadapter:	Ja
Fingeraftrykslæser:	Ingen
I/O-porte:	1x eSATA, 1x USB3.0, DC In
HDD-størrelse:	- "
HDD hastighed:	7200 rpm
USB-dataoverførselshastigheder:	5000 Mbit/s
Bus poweret:	USB
Lagringsdrev buffer størrelse:	32 MB
eSATA:	Ja
eSATA dataoverførselshastigheder:	6 Gbit/sek.
