AV Control Receiver
Operating Instructions
Model No. SA-HE200
Dear customer
Thank you for purchasing this product.
Before connecting, operating or adjusting this product, please read
these instructions completely.
Please keep this manual for future reference.
Note:
“EB” on the packaging indicates the United Kingdom.
E EB
TV
MD
TUNER/BAND
TOP MENU
MENU
RECEIVER
TAPE CD
VCR
DVD
RETURN
PAUSESTOP
SOUND MODE
CHANNEL VOLUME
PLAY
SLOW /SEARCH
SKIP
DISPLAY
MUTING
INPUT
SELECTORSUBWOOFER
ENTER
DOLBY
DIGITAL DOLBY
PRO LOGIC 2
DTS-ESDOLBY
DIGITAL EX
RE-MASTER
WAKE
8
^
SOURCE DIRECT
NEO:6
DSP
SOUND MODE
DOLBY
PRO LOGIC 2
HQ
SOUND MODE ENHANCED
SURROUND
DTS
MULTI DECODER
NEO:6
INPUT SELECTOR
VOLUME
DOWN UP
A SPEAKERS B
PHONES
RDS
- BAND
–
FM MODE
MEMORY
DISPLAY
MODE
PTY SEARCH PTY SELECTOR
PRESET
2
TUNING
1
INPUT
MODE
TAPE
MONITOR
DVD
6CH INPUT
VCR 3
S-VIDEO IN VIDEO IN
L AUDIO IN R
Table of contents
Caution for AC Mains Lead ...............................................2
Safety precautions.....................................................................2
Supplied accessories................................................................4
The remote control ....................................................................4
Troubleshooting guide ...........................................................23
Specifications ..........................................................Back cover
Maintenance .............................................................Back cover
Equipment connections
4
Speaker connections
8
Settings
10
Step 1
Control guide
12
Before use
Reference
Step 1Step 2Step 3Step 4 Before useOthersReference
Step 2
Step 3
Step 4
Sound modes ............................................................................16
Other functions.........................................................................18
The radio.....................................................................................19
RDS broadcasts ...............................................................20
Other settings ...........................................................................21
Timer function ..................................................................22
Making a recording..................................................................22
The RESET function................................................................22
Others
RQT6252-B
2
RQT6252
Fuse cover
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A Figure B
Safety precautions
Placement
Set the unit up on an even surface away from direct sunlight, high
temperatures, high humidity, and excessive vibration. These
conditions can damage the cabinet and other components, thereby
shortening the unit s service life.’
Do not place heavy items on the unit.
Voltage
Do not use high voltage power sources. This can overload the unit
and cause a fire.
Do not use a DC power source. Check the source carefully when
setting the unit up on a ship or other place where DC is used.
AC mains lead protection
Ensure the AC mains lead is connected correctly and not damaged.
Poor connection and lead damage can cause fire or electric shock.
Do not pull, bend, or place heavy items on the lead.
Grasp the plug firmly when unplugging the lead. Pulling the AC
mains lead can cause electric shock.
Do not handle the plug with wet hands. This can cause electric
shock.
Foreign matter
Do not let metal objects fall inside the unit. This can cause electric
shock or malfunction.
Do not let liquids get into the unit. This can cause electric shock or
malfunction. If this occurs, immediately disconnect the unit from the
power supply and contact your dealer.
Do not spray insecticides onto or into the unit. They contain
flammable gases which can ignite if sprayed into the unit.
Service
Do not attempt to repair this unit by yourself. If sound is interrupted,
indicators fail to light, smoke appears, or any other problem that is
not covered in these instructions occurs, disconnect the AC mains
lead and contact your dealer or an authorized service center.
Electric shock or damage to the unit can occur if the unit is repaired,
disassembled or reconstructed by unqualified persons.
Extend operating life by disconnecting the unit from the power
source if it is not to be used for a long time.
(For United Kingdom)
(“EB” area code model only)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug for
your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5-ampere and that it is approved
by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it
is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR
THE SOCKET OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND THE PLUG CUT
OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK IF THE CUT OFF PLUG IS INSERTED INTO
ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring code as stated
below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the
following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be connected to the
terminal which is marked with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE
EARTH TERMINAL WHICH IS MARKED WITH THE
LETTER E, BY THE EARTH SYMBOL OR
COLOURED GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF KEEP DRY.–
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC mains
plug (figures A and B). Confirm the AC mains plug fitted and follow
the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
Caution for AC Mains Lead
