Side 1/12
Installation Instruction
安裝說明書
Trim kit / 專用框架
24”cabinet /
24寸儲藏櫃
(596mm)
TK611SWQP
TK611SSQP
TK611SSHP
Contents /目錄
Attention / .....P1注意 ..............................................................................................................................
Step1. Unpacking list / 步驟1. 包裝中的部件 ......................................................................................P2
Step2. Feature diagram / 步驟2. 外觀示意圖 ......................................................................................P3
Step3. Cabinet Preparation / 步驟3. 儲藏櫃的準備 ............................................................................P4
Step4. Microwave Oven Installation / 步驟4. 微波爐的安裝 ...............................................................P5
Step5. Cabinet Installation / 步驟5. 儲藏櫃的安裝 .......................................................................... P6-7
Step6. Lower Duct Installation / 步驟6. 底板的安裝 ............................................................................P8
Step7. Finishing Installation / 步驟7. 完成安裝 ............................................................................. P9-11
IP3628_F03139Y10QP_18_110823.indd 1
IP3628_F03139Y10QP_18_110823.indd 1
IP3628_F03139Y10QP_18_110823.indd 1
IP3628_F03139Y10QP_18_110823.indd 1IP3628_F03139Y10QP_18_110823.indd 1 2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:022011-8-23 Lynn 10:24:02
1
en
1. This trim kit can be installed into a cabinet.
The cabinet opening must have the following
internal dimensions as shown in , . g 1fip 4
A vent is required at the rear of the cabinet.
It should travel the full height of the cabinet
and the cabinet should not be obstructed.
Minimum dimension of vent: 45 mm x 562 mm
( ).fig 1, p 4
MINIMUM INSTALLATION HEIGHT 850 MM.
2. Electrical Connections The appliance is
supplied with a mains plug attached and
should only be connected into an earthed
socket that has been installed according to
the relevant safety regulations.
If the plug is no longer accessible after the
appliance has been built into the cabinet, a
dual pole isolator must be installed to conform
to the relevant safety standards.
3. Appliance shall be provided with means for
disconnection from the supply mains having
a contact separation in all poles that provide
full disconnection under overvoltage
Ⅲ
conditions, such means must be incorporated
in the xed wiring in accordance with the fi
wiring rules and accessible.
4. It is essential that the cabinet is xed to the fi
wall for stability. The shelf must be able to
support a weight of 30 kg.
5. If the microwave oven is to be removed from
the kitchen cabinet and used free standing,
the built in parts must be removed, and the
oven returned to its original condition. Keep
these installation instructions for future
reference so the installation process can be
reversed.
TAKE CARE NOT TO KINK OR TRAP THE
MICROWAVE ELECTRICAL CABLE.
The diagram may vary from the actual unit
and is only for your reference.
zh
1. 此專用框架可安裝在開放式橱櫃內。橱櫃內部
尺寸請參考第4頁圖1所示。
橱櫃後必須預留有足够高度的通風空隙，幷確
保橱櫃不被阻塞。最小通風尺寸爲45 mm x 562
mm（第4頁圖1）。
最小安裝高度爲850 mm。
2. 綫路 本設備配有一個接地插頭，必須確保插在
符合相應安全標準的插座上。
如果當微波爐安裝在橱櫃內後，插頭不易接近
原有插座時，可另行安裝符合相應安全標準的
插座。
3. 本設備應提供一個停止供電的方法：在過壓Ⅲ
條件下，電源會通過全電極的觸點斷開使電源
停止供電。這種方法必須包含一個固定綫路，
該電路應該符合電路法規幷且是可使用的。
4. 確保有足够穩定性的開放式橱櫃，幷且能支撑
30千克的載重。
5. 如果要把微波爐從橱櫃內取出置放在桌上使
用，必須取去專用框架部件使微波爐恢復原來
的狀態。請妥善保存此安裝說明書以備查閱。
不可扭曲或纏繞電綫。
圖標與實際産品可能有不同，僅供參考。
IP3628_F03139Y10QP_18_110823.indd Sec1:1
IP3628_F03139Y10QP_18_110823.indd Sec1:1
IP3628_F03139Y10QP_18_110823.indd Sec1:1
IP3628_F03139Y10QP_18_110823.indd Sec1:1IP3628_F03139Y10QP_18_110823.indd Sec1:1 2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:02
2011-8-23 Lynn 10:24:022011-8-23 Lynn 10:24:02
