AUDIO/VIDEO MULTI-CHANNEL RECEIVER

Operating Instructions

Discover the benefits of registering your product online at http://www.pioneer.co.uk (or http://www.pioneer.eu).

VSX-S500-K

Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you

have finished reading the instructions, put them away in a safe place for future reference.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT

D3-4-2-1-1_A1_En

WARNING

To prevent a fire hazard, do not place any naked flame

sources (such as a lighted candle) on the equipment.

D3-4-2-1-7a_A1_En

D3-4-2-1-2-2*_A2_En

Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified

service personnel.

IMPORTANT: THE MOULDED PLUG

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 10 amp fuse is fitted in this plug.

Should the fuse need to be replaced, please ensure that the replacement fuse has a rating of 10 amps and that it is approved by ASTA or BSI

to BS1362.

Check for the ASTA mark or the BSI mark on the body of the fuse.

If the plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug

must not be used until a replacement cover is obtained. A replacement fuse cover can be obtained from your local dealer.

If the fitted moulded plug is unsuitable for your socket outlet, then the fuse shall be removed and the plug cut off and disposed of

safely. There is a danger of severe electrical shock if the cut off plug is inserted into any 13 amp socket.

If a new plug is to be fitted, please observe the wiring code as shown below. If in any doubt, please consult a qualified electrician.

IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:

Blue : Neutral Brown : Live

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in

your plug, proceed as follows;

The wire which is coloured BLUE must be connected to the terminal which is marked with the

letter or coloured BLACK.N

The wire which is coloured BROWN must be connected to the terminal which is marked with the

letter or coloured RED.L

How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.

VENTILATION CAUTION

When installing this unit, make sure to leave space

around the unit for ventilation to improve heat radiation

(at least 10 cm at top, 5 cm at rear, and 5 cm at each

side).

WARNING

Slots and openings in the cabinet are provided for

ventilation to ensure reliable operation of the product,

and to protect it from overheating. To prevent fire

hazard, the openings should never be blocked or

covered with items (such as newspapers, table-cloths,

curtains) or by operating the equipment on thick carpet

or a bed.

D3-4-2-1-7b*_A1_En

Operating Environment

Operating environment temperature and humidity:

+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH

(cooling vents not blocked)

Do not install this unit in a poorly ventilated area, or in

locations exposed to high humidity or direct sunlight (or

strong artificial light)

D3-4-2-1-7c*_A1_En

Produkt Specifikationer

Mærke:	Pioneer
Kategori:	Modtager
Model:	VSX-S500
Vekselstrømsindgangsspænding:	220-230 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	435 mm
Dybde:	317 mm
Højde:	85 mm
Vægt:	4200 g
Brugervejledning:	Ja
Produktfarve:	Black, Blue, Silver
Wi-Fi:	Ingen
Understøttede videotilstande:	1080p
3D:	Ja
DLNA-certificeret (Digital Living Network Alliance):	Ja
Lyddekodere:	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Understøttede lydformater:	AAC, FLAC, MP3, WAV, WMA
Strømforbrug (standby):	0.45 W
Strømforbrug (typisk):	70 W
Skærm:	LCD
Volumenkontrol:	Dreje
Batterier inkluderet:	Ja
Sammensat videoindgang:	1
Fjernbetjening inkluderet:	Ja
Frekvensområde:	5 - 100000 Hz
Impedens:	4 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	5.1 kanaler
Indbygget kortlæser:	Ingen
Antal USB-porte:	1
Understøttede radiobånd:	AM, FM
RDS Tuner inkluderet:	Ja
Tilslutning af hovedtelefoner:	3,5 mm
AC (strøm) indgang:	Ja
Sammensat videoudgang:	1
klirfaktor (THD):	1 %
Garantibevis:	Ja
Modtagertype:	Surround
Signal/støjforhold:	98 dB
FM båndbredde:	87.5 - 108 MHz
AirPlay:	Ingen
Højttalere tilslutningstype:	Klemmeterminaler
Kampatibilitet med Apple-docking:	iPhone, iPod
Antal forudindstillede stationer:	30
FM-antenne:	Ja
HSMI-indgang:	4
Antal HDMI-udgange:	1
Digital lyd koaksial indgang:	1
Output impedans:	4 ohm (Ω)
AM båndbredde:	531 - 1602 kHz
Digital akustisk og optisk indgang:	2
Automatisk digital indstilling:	Ja
AM-antenne:	Ja
Antal FM-antenneporte:	1
Udgangseffekt pr. kanal (20-20KHz @8 Ohm):	- W
Optisk drev inkluderet:	Ingen
Audio D/A-konverter (DAC):	24-bit/192kHz
Lyd A/D konverter (ADC):	24-bit/96kHz
Indgangsfølsomhed:	200 mV
Dynamisk effekt pr. kanal (4 Ohm):	100 W
Antal AM-antenneporte:	1
Grafisk brugergrænseflade (GUI):	Ja
Lydindgangstype med flere kanaler:	Terminaler
