When Image Experience Matters.

See Back for More Information



LC15 SERIES

QUICK START GUIDE

LC15 Series

Thank you for choosing Planar’s LC15 series

touchscreen monitor.

Customer Service:

To view online documentation and

frequently asked questions, or to send an

email to our technical support sta , please

visit: www.planar.com/support or call

1-866-PLANAR1 (1-866-752-6271).

To receive advanced noti cation of product

updates, please register your monitor at

www.planar.com/support.

Planar is one of the world’s most

accomplished providers of  at-panel

displays, with over 27 years expertise in

 at-panel innovation. The company provides

the most dependable display solutions for

various applications in industrial, medical,

and commercial markets.



Monitor Set-up

1. If it is necessary, clean the front surface of the

display by using clean, compressed air or by

using only a clean, dry soft cloth.

2. Mount the monitor to your enclosure using

your hardware. Detailed mechanical drawings,

including mounting hole patterns, may be

found at: www.planar.com/support

3. Securely tighten all mounting hardware.

4. Connect the video and power cables.

5. Power up the computer. See the user’s guide for

your product at: www.planar.com/support for

advanced set-up instructions.

Package Overview

Contents -

LCD Display

Side Mounting Brackets

and Screws

Power Cord

The test results show that this device meets the FCC rules. Refer to the product operation

manual for FCC classi cation found at www.planar.com/support. Those limits are set to

protect residential areas from devices with harmful emission. This device will produce,

use, and radiate radio frequency energy. Failure to follow the user’s manual to install

or use this device might produce harmful interference with radio communication.

Planar does not guarantee that this type of harmful interference will not occur in some

special installations. The interference caused by this device with the reception of radio

or television signals may be veri ed by turning the device on and o . Any changes or

modi cations to this TFT LCD would void the user’s authority to operate this device.

020-1134-00

Ambient Light

Sensor

Power Supply

VGA

Power

LC1503R-C LC1503R

VGAPower

For best performance, set your computer video

graphics resolution to 1024 x 768.

Produkt Specifikationer

Mærke:	Planar
Kategori:	overvåge
Model:	LC1503R
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Brugervejledning:	Ja
Produktfarve:	Sort
Skærm diagonal:	15 "
Skærmopløsning:	1024 x 768 pixel
Berøringsskærm:	Ingen
Naturligt aspektforhold:	4:3
Responstid:	8 ms
Synsvinkel, horisontal:	160 °
Synsvinkel, vertikal:	160 °
3D:	Ingen
Indbyggede højttaler(e):	Ingen
Opbevaringstemperatur (T-T):	-30 - 70 °C
Ethernet LAN:	Ingen
VESA montering:	Ja
Panel montering grænseflade:	75 x 75 mm
Strømforbrug (typisk):	20 W
Bredde (uden stativ):	327 mm
Dybde (uden stativ):	31 mm
Højde (uden stativ):	253 mm
Vægt (uden stativ):	1000 g
Driftstemperatur (T-T):	-20 - 70 °C
Skærm:	LCD
Understøttede grafikopløsninger:	1024 x 768 (XGA)
Certificering:	FCC, CE, TUV
Indbygget kamera:	Ingen
Slot til kabellås:	Ingen
Billedformat:	4:3
Plug and play:	Ja
Skærmens lysstyrke (typisk):	1600 cd/m²
Kontrastforhold (typisk):	600:1
Antal VGA-porte (D-sub):	1
AC (strøm) indgang:	Ja
TV-tuner, integreret:	Ingen
Sikkerhed:	RoHS
Tynd klient installeret:	Ingen
