User’s Manual of MGSW-24160F

User’s Manual

MGSW-24160F

16-Port 100/1000Base-X SFP

+ 8-Port 10/100/1000Base-T

L2/L4 Managed Metro Ethernet Switch

User’s Manual of MGSW-24160F

Trademarks

Contents subject to which revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at whose own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be

required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable to disconnect the device from the power circuit.

Without removing power cable, the device is will still consuming power from the power source. In the view of Saving the Energy

and reduce the unnecessary power consuming, it is strongly suggested to remove the power connection for the device if this

device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET 16-Port 100/1000Base-X SFP + 8-Port 10/100/1000Base-T L2/L4 Managed Metro Ethernet Switch

User's Manual

FOR MODEL: MGSW-24160F

REVISION: 1.1 (May. 2012)

Part No: EM-MGSW-24160F (2080-A93270-000)

Produkt Specifikationer

Mærke:	Planet
Kategori:	bryter
Model:	MGSW-24160F
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	440 mm
Dybde:	200 mm
Højde:	44.5 mm
Vægt:	3000 g
Produktfarve:	Blå
Kompatible hukommelseskort:	Ikke understøttet
Formfaktor:	1U
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Driftstemperatur (T-T):	0 - 60 °C
Sikkerhedsalgoritmer:	SNMP, SSH, SSL/TLS
Hurtig start guide:	Ja
Kabler inkluderet:	RS-232
Strømforbrug (maks.):	38 W
Netværksstandarder:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Webbaseret administration:	Ja
Knap til nulstilling:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Ja
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85176990
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ja
Switch-type:	Administreret
ARP inspektion:	Ja
System hændelseslog:	Ja
Switch lag:	L2+
Power over Ethernet plus (PoE+) porte, antal:	8
10G understøttelse:	Ingen
Spanning tree protokol:	Ja
Auto MDI/MDI-X:	Ja
VLAN understøttelse:	Ja
Flowkontrol support:	Ja
Port-spejlning:	Ja
Link aggregering:	Ja
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
Vituelle LAN funktioner:	Private VLAN, Protocol-based VLAN, Port-based VLAN
Basis omskiftning RJ-45 Ethernet porte, antal:	8
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
Port til konsol:	RS-232
IGMP snooping:	Ja
BPDU filtrering/beskyttelse:	Ja
Adgangskontrolliste (ACL):	Ja
IP-MAC-portbinding:	Ja
Filtrering af MAC-adresser:	Ja
Loop beskyttelse:	Ja
Fiber ethernet kabelteknologi:	1000BASE-X
Opbevar-og-frem:	Ja
MAC adresselabel:	16000 entries
Switch kapacitet:	48 Gbit/sek.
Gennnemløb:	35.6 Mpps
Antal køer:	8
Jumbo Frames support:	Ja
Jumbo rammer:	10000
Stativ-montering:	Ja
Antal blæsere:	2 blæser(e)
Multicast-understøttelse:	Ja
Trafik klassificering:	Ja
Antal SFP modulslots:	16
Power over Ethernet (PoE) porte, antal:	8
Strømforsyning inkluderet:	Ingen
MAC-adresse auto-indlæring understøttet:	Ja
MAC-adresse auto-forældelse understøttet:	Ja
Stabelbar:	Ja
Auto-forhandling:	Ja
DHCP funktioner:	DHCP server, DHCP client
Rack monteringskit:	Ja
Klemrække port:	Ja
Klemrække inkluderet:	Ja
Fibertype:	Multitilstand
IP-routing:	Ja
SSH/SSL support:	Ja
MIB support:	RFC 1213 MIB-II, RFC 1493 Bridge MIB, RFC 1643 Ethernet MIB, RFC 2863 Interface MIB, RFC 2665 Ether-Like MIB, RFC 2819 RMON MIB (Group 1, 2, 3 and 9), RFC 2737 Entity MIB, RFC 2618 RADIUS Client MIB, RFC 2863 IF-MIB, RFC 2933 IGMP-STD-MIB, RFC 3411 SNMP-Frameworks-MIB, RFC 4292 IP Forward MIB, RFC 4293 IP MIB, RFC 4836 MAU-MIB, IEEE 802.1X PAE, LLDP
Gummifødder:	Ja
Transmissionsafstand (maks.):	120 km
Antal filtrerede multicast-grupper:	255
Antal trunks:	24
Trafik formning:	Ja
Autokant port:	Ja
Adminkant port:	Ja
