1. Introduction

Thank you for purchasing PLANET H.265 25-ch 4K Network Video

Recorder. The is used as an alternative name “NVR-25xx series”

in this Quick Installation Guide. The following is the NVR-25xx

series:

NVR-2500 H.265 25-ch 4K Network Video Recorder

NVR-2516P H.265 25-ch 4K Network Video Recorder with

16-Port PoE

2. Package Contents

Open the box of the NVR-25xx series and carefully unpack it. The

box should contain the following items:

zThe NVR x 1

zQuick Installation Guide x 1

zHDD Screw Package x 1

zPower Cord x 1

zPower Adapter x 1 (NVR-2500 only)

zBracket & Screw Package x 1 (NVR-2516P only)

If any item is found missing or damaged, please contact your local

reseller for replacement.

3. Hard Disk Installation

The hard disk is installed as shown in Figure 3-1.

(1) Unscrew the cover to open the cover.

(2) Connect one end of the hard disk data cable and power cable

to the motherboard, and connect the other end to the hard

disk.

(3) Turn over the chassis, mount the hard disk in the indicated

position and screw it tightly.

(4) Now turn over the chassis again and cover it with screws.

Note

1. Before installation, make sure the power is

disconnected.

2. Use the NVR dedicated hard drive for monitoring

recommended by the device manufacturer.

NVR-2500

NVR-2516P

Figure 3-1: Hard Disk Installation

4. Requirements

zWorkstations running Windows XP/2003/2008/Vista/7/8/10, MAC

OS X or later, Linux, UNIX, or other platforms are compatible

with TCP/IP protocols.

zWorkstations are installed with Ethernet NIC (Network Interface

Card).

zEthernet Port Connection

 Network cables -- Use standard network (UTP) cables with

RJ45 connectors.

 The above PC is installed with Web browser.

Note

It is recommended to use Internet Explorer 8.0 or

above to access the NVR-25xx series. If the Web

interface of the NVR-25xx series is not accessible,

please turn o the anti-virus software or rewall and

then try it again.

5. Starting Web Management

The following shows how to start up the of the Web Management

NVR-25xx series. Note the NVR-25xx series is congured through

an Ethernet connection. Please make sure the manager PC must be

set to the same IP subnet address.

User PC

(192.168.0.X)

Ethernet Switch H.265 25-ch 4K NVR

Figure 5-1: IP Management Diagram

Note

1. Make sure the input voltage matches the NVR

consumption. Connect the device to the monitor and

the power adapter (if available). Plug in the power

and switch on the power button (if available) for the

device to boot up.

2. It is recommended that you refer to international

standards for power supply input with stable voltage

values and low ripple interference.

►

NVR-2500/NVR-2516P

H.265 25-ch 4K Network Video Recorder

– 5 – – 6 –

– 7 – – 8 –

2. After entering the username and password, the main screen

appears as Figure 5-4 shows.

Figure 5-4: Web Main Screen of NVR-25xx series

Now, you can use the Web management interface to continue the

NVR-25xx series management.

Please refer to the user’s manual for more.

Customer Support

Thank you for purchasing PLANET products. You can browse our

online FAQ resource and User’s Manual on PLANET Web site rst

to check if it could solve your issue. If you need more support

information, please contact PLANET support team.

PLANET online FAQs:

http://www.planet.com.tw/en/support/faq?method=category&c1=8

Support team mail address:

support@planet.com.tw

For example, the NVR-25xx series default network type is DHCP

Client; to search the current IP address of the NVR-25xx series,

follow the procedure below:

1. Download the “PLANET Search Tools” utility from the following

PLANET website link:

http://www.planet.com.tw/en/support/downloads?method=keywo

rd&keyword=PLANET+Search+Tools&view=6#list

2. Install the utility.“PLANET Search Tools”

3. After the utility is launched, all NVRs found in your local area

network will be displayed.

4. The existing NVR-25xx series in the local network.

5. Search the NVR-25xx series in the network.

6. Modify the IP parameters of the selected NVR-25xx series.

7. Select the NVR-25xx series you want to congure and double-

click on it.

8. You will be connected to the NVR-25xx series via web browser

automatically.

Figure 5-2: PLANET Search Tools Utility Screen

9. Without DHCP server, the NVR-25xx series default IP address

is 192.168.0.20. Then the manager PC should be set to

192.168.0.x (where x is a number between 1 and 254, except

20), and the default subnet mask is 255.255.255.0.

5.1 Logging in to the NVR-25xx Series

1. When the following dialog box appears, enter the default user

name and password . The login screen in Figure 5-3 “admin”

appears.

Default Username: admin

Default Password: admin

Figure 5-3: NVR-25xx series Web Login Screen

Note

When the browser fails to enter the device login

interface, open IE browser, select” Tools > Internet

Options > Security> Custom Level > ActiveX controls

and plug-ins” and enable all of them.

NVR-25xx Series User’s Manual:

https://www.planet.com.tw/en/support/downloads?&method=keywo

rd&keyword=NVR-25&view=3#list

Android APP IOS APP

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy savings, please remove the power cable to disconnect the device from the power

circuit. Without removing the power cable, the device will still consume power from the power source. In view of Saving the Energy and reducing the unnecessary
