Owner's Manual
for Maintenance and Safety
RANGER CREW
®
900
RANGER XP
®
1000
RANGER XP CREW
®
1000
RANGER XP
®
900
WARNING
Read, understand, and follow all of the instructions
and safety precautions in this manual and on all product labels.
Failure to follow the safety precautions could result in serious injury or death.
WARNING
The engine exhaust from this product contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive harm.
For videos and more information
about a safe riding experience with
your Polaris vehicle, scan this QR
code with your smartphone.
1
WELCOME
Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide family of
POLARIS enthusiasts. Be sure to visit us online at www.polaris.com for the latest news, new
product introductions, upcoming events, career opportunities and more.
Here at POLARIS we proudly produce an exciting line of utility and recreational products.
We believe POLARIS sets a standard of excellence for all utility and recreational vehicles
manufactured in the world today. Many years of experience have gone into the engineering,
design, and development of your POLARIS vehicle, making it the finest machine we’ve ever
produced.
For safe and enjoyable operation of your vehicle, be sure to follow the instructions and
recommendations in this owner’s manual.
Your manual contains instructions for minor maintenance, but information about major
repairs is outlined in the POLARIS Service Manual and can be performed by a factory
certified Master Service Dealer® (MSD) Technician.
Your POLARIS dealer knows your vehicle best and is interested in your total satisfaction.
Your POLARIS dealership can provide for all of your service needs during, and after, the
warranty period.
• Snowmobiles • RZR® sport vehicles
• All-terrain vehicles (ATVs) • GEM® electric vehicles
• Low emission vehicles (LEVs) • VICTORY® motorcycles
• ®RANGER utility vehicles • INDIAN® motorcycles
• BRUTUS® work vehicles • POLARIS POWER® generators
• SLINGSHOT® three wheel motorcycles • POLARIS DEFENSE® combat vehicles
4
INTRODUCTION
Failure to follow the warnings contained in this manual can result in severe injury or death.
Your POLARIS RANGER is not a toy and can be hazardous to operate. This vehicle handles differently
than other vehicles, such as cars, trucks or other off-road vehicles. A collision or rollover can occur
quickly, even during routine maneuvers like turning, or driving on hills or over obstacles, if you fail to
take proper precautions.
• Read this owner’s manual and review the safety DVD that came with your vehicle. A free extra copy
of the DVD can be obtained by contacting your local POLARIS dealer. Understand all safety
warnings, precautions and operating procedures before operating the vehicle. Keep this manual with
the vehicle.
• Review the safety DVD and take the free online Recreational Off-Highway Vehicle Association
(ROHVA) training course at www.rohva.org.
• This vehicle is an ADULT VEHICLE ONLY. You MUST be at least age 16 and have a valid driver’s
license to operate this vehicle.
• No person under the age of 12 may ride as a passenger in this vehicle. All riders must be able to sit
with backs against the seat, both feet flat on the floor and both hands on the steering wheel (if
driving) or on a passenger hand hold.
• Never permit a guest to operate this vehicle unless the guest has read this manual and all product
labels.
• Always use the cab nets (or doors) while riding in this vehicle. Always keep hands, feet and all other
body parts inside the vehicle at all times.
• Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants and over-the-ankle
boots.
• Never use this vehicle with drugs or alcohol, as these conditions impair judgment and reduce
operator reaction time.
WARNING
5
INTRODUCTION
The RANGER is an off-road vehicle. Familiarize yourself with all laws and regulations
concerning the operation of this vehicle in your area.
The following signal words and symbols appear throughout this manual and on your vehicle.
Your safety is involved when these words and symbols are used. Become familiar with their
meanings before reading the manual.
The safety alert symbol indicates a potential personal injury hazard.
DANGER
A DANGER indicates a hazardous situation that, if not avoided, will result in death or serious injury.
WARNING
A WARNING indicates a hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION
A CAUTION indicates a hazardous situation that, if not avoided, could result in minor or moderate
injury.
NOTICE
A NOTICE indicates a situation that could result in property damage.
The Prohibition Safety Sign indicates an action NOT to take in order to avoid a hazard.
The Mandatory Action Sign indicates an action that NEEDS to be taken to avoid a hazard.
6
INTRODUCTION
Vehicle Identification Numbers
Record your vehicle's identification numbers and key number in the spaces provided.
Remove the spare key and store it in a safe place. An ignition key can be duplicated only by
ordering a POLARIS key blank (using your key number) and mating it with one of your
existing keys. The ignition switch must be replaced if all keys are lost.
Vehicle Model Number: ________________________________________________________________________
Frame VIN: _________________________________________________________________________________
Engine Serial Number: ________________________________________________________________________
Key Number: ________________________________________________________________________________
####
Engine Serial
Number
Key Number
VIN
7
INTRODUCTION
European Vibration and Noise
The driver-perceived noise and hand/arm and whole body vibration levels of this machinery
is measured per prEN 15997.
The operating conditions of the machinery during testing:
The vehicles were in like-new condition. The environment was controlled as indicated by the
test procedure(s).
The uncertainty of vibration exposure measurement is dependent on many factors, including:
• Instrument and calibration uncertainty
• Variations in the machine such as wear of components
• Variation of machine operators such as experience or physique
• Ability of the worker to reproduce typical work during measurements
• Environmental factors such as ambient noise or temperature
8
SAFETY
Safe Riding Gear
The driver and all passengers must wear helmet, eye protection, gloves, long-sleeve shirt,
long pants, over-the-ankle boots and seat belt at all times. Protective gear reduces the chance
of injury.
Helmet
Wearing a helmet can prevent a severe head injury. Whenever riding this POLARIS vehicle,
always wear a helmet that meets or exceeds established safety standards.
Approved helmets in the USA and Canada bear a U.S. Department of Transportation (DOT)
label.
Approved helmets in Europe, Asia and Oceania bear the ECE 22.05
label. The ECE mark consists of a circle surrounding the letter E,
followed by the distinguishing number of the country which has granted
approval. The approval number and serial number will also be displayed
on the label.
E
4
051039
0006.31
Helmet
Eye Protection
Gloves
Over-the-Ankle
Boots
Long Pants
Long
Sleeves
9
SAFETY
Safe Riding Gear
Eye Protection
Do not depend on eyeglasses or sunglasses for eye protection. Whenever riding this
POLARIS vehicle, always wear shatterproof goggles or use a shatterproof helmet face
shield. POLARIS recommends wearing approved Personal Protective Equipment (PPE)
bearing markings such as VESC 8, V-8, Z87.1, or CE. Make sure protective eye wear is kept
clean.
Gloves
Wear gloves for comfort and for protection from sun, cold weather and other elements.
Boots
Wear sturdy over-the-ankle boots for support and protection. Never ride a POLARIS vehicle
with bare feet or sandals.
Clothing
Wear long sleeves and long pants to protect arms and legs.
Rider Comfort
Under certain operating conditions, heat generated by the engine and exhaust system can
elevate temperatures in the driver and passenger cab area. The condition occurs most
frequently when a vehicle is being operated in high ambient temperatures at low speeds and/
or high load conditions for an extended period of time. The use of certain windshield, roof
and/or cab systems may contribute to this condition by restricting airflow. Any discomfort
due to heat buildup in this area can be minimized by wearing proper riding apparel and by
varying speeds to increase airflow.
10
SAFETY
Safety Labels and Locations
Warning labels have been placed on the vehicle for your protection. Read and follow the
instructions of the labels on the vehicle carefully. If any of the labels depicted in this manual
differ from the labels on your vehicle, always read and follow the instructions of the labels
on the vehicle.
If any label becomes illegible or comes off, contact your POLARIS dealer to purchase a
replacement. Replacement safety labels are provided by POLARIS at no charge. The part
number is printed on the label.
Proper Use Warning (XP 900)
Require Proper Use of Your Vehicle
Do your part to prevent injuries:
• Do not allow careless or reckless driving.
• Make sure operators are 16 or older with a valid driver’s license.
• Do not let people drive or ride after using alcohol or drugs.
• Do not allow operation on public roads (unless designated for off-highway vehicle access) - collisions
with cars and trucks can occur.
• Do not exceed seating capacity: 3 occupants.
7179979
Proper Use Warning (CREW)
Require Proper Use of Your Vehicle
Do your part to prevent injuries:
• Do not allow careless or reckless driving.
• Make sure operators are 16 or older with a valid driver’s license.
• Do not let people drive or ride after using alcohol or drugs.
• Do not allow operation on public roads (unless designated for off-highway vehicle access) - collisions
with cars and trucks can occur.
• Do not exceed CREW-6 seating capacity: 6 occupants.
Proper Use
Warning
Shift Caution
Seat Belt/Drive Responsibly
Warning
Payload
Warning
12
SAFETY
Safety Labels and Locations
Load/Passenger/Tire Pressure Warning
WARNING
• Never carry passengers in cargo box.
• Passengers can be thrown off. This can cause serious
injury or death.
• If total payload is greater than 500 lbs., the vehicle must
be operated in LOW range.
IMPROPER TIRE PRESSURE OR OVERLOADING CAN
CAUSE LOSS OF CONTROL RESULTING IN SERIOUS
INJURY OR DEATH.
• Reduce speed and allow greater distance for braking
when carrying cargo.
• Overloading or carrying tall, off-center, or unsecured loads will increase your risk of losing control.
Loads should be centered and carried as low as possible in box.
• For stability on rough or hilly terrain, reduce speed and cargo.
Clutch Cover Warning
WARNING
Improper service or maintenance of this PVT system can result
in vehicle damage, SEVERE INJURY or DEATH.
Always look for and remove debris inside and around clutch
and vent system when replacing belt.
Read owner’s manual or see authorized POLARIS dealer.
7177469
RANGER XP 4x4 4x4 CA CREW CA CREW
MAXIMUM CARGO BOX LOAD 1000 lbs.
(454 kg)
600 lbs.
(272 kg)
1000 lbs.
(454 kg)
600 lbs.
(272 kg)
TIRE PRESSURE IN PSI (KPa) FRONT 10 (69)
REAR 12 (83)
FRONT 10 (69)
REAR 12 (83)
FRONT 14 (96)
REAR 16 (110)
FRONT 14 (96)
REAR 16 (110)
MAXIMUM WEIGHT CAPACITY
INCLUDES WEIGHT OF
OPERATOR, PASSENGERS,
CARGO AND ACCESSORIES
1500 lbs.
(682 kg)
1100 lbs.
(499 kg)
1750 lbs.
(795 kg)
1350 lbs.
(612 kg)
Read Operation and Maintenance Manual for more detailed loading information.
RANGER XP 4x4 Hunter CA 4x4 Hunter
MAXIMUM CARGO BOX LOAD 1000 lbs. (454 kg) 600 lbs. (272 kg)
TIRE PRESSURE IN PSI (KPa) FRONT 12 (83)
REAR 12 (83)
FRONT 12 (83)
REAR 12 (83)
MAXIMUM WEIGHT CAPACITY
INCLUDES WEIGHT OF OPERATOR,
PASSENGER, CARGO AND NON-
FACTORY INSTALLED
ACCESSORIES
1275 lbs. (578 kg) 875 lbs. (397 kg)
Read Operation and Maintenance Manual for more detailed loading information.
Load/Passenger/Tire Pressure
Warning
Clutch Cover
Warning
17
SAFETY
Operator Safety
Cab Nets and Doors
Riding in this vehicle without using the cab nets (or doors, if equipped) increases the risk of serious
injury or death in the event of an accident or rollover. Always use the cab nets (or doors) while riding in
this vehicle.
Always keep hands and feet inside the vehicle at all times.
Failure to Inspect Before Operating
Failure to inspect and verify that the vehicle is in safe operating condition before operating increases
the risk of an accident. Always perform the pre-ride inspection before each use of your RANGER to
make sure it's in safe operating condition. See page 40.
Always follow all inspection and maintenance procedures and schedules described in this owner's
manual. See page 65.
Operating With a Load on the Vehicle
The weight of both cargo and passengers impacts vehicle operation. For your safety and the safety of
others, carefully consider how your vehicle is loaded and how to safely operate the vehicle. Follow the
instructions in this manual for loading, tire pressure, gear selection and speed.
•Do not exceed vehicle weight capacities. The vehicle’s maximum weight capacity is listed in the
specifications section of this manual and on a label on the vehicle. When more passenger weight is
added, cargo weight may need to be reduced accordingly.
• The recommended tire pressures are listed in the specifications section of this manual and on a label
on the vehicle.
Always follow these guidelines:
Under ANY of these conditions: Do ALL of these steps:
Passenger and/or cargo exceeds half the maximum weight capacity 1. Slow down.
2. Verify tire pressure.
3. Use extra caution when
operating.
Operating in rough terrain
Operating over obstacles
Climbing an incline
Towing
18
SAFETY
Operator Safety
Handling Gasoline
Gasoline is highly flammable and explosive under certain conditions.
• Always exercise extreme caution whenever handling gasoline.
• Always turn off the engine when refueling.
• Always refuel outdoors or in a well ventilated area free of any source of flame or sparks.
• Always use an approved gasoline container to store fuel and remove the container from the vehicle
before filling to avoid fuel ignition due to electrical static discharge.
• Do not smoke or allow open flames or sparks in or near the area where refueling is performed or
where gasoline is stored.
• Do not overfill the tank. Do not fill the tank neck.
• If gasoline spills on your skin or clothing, immediately wash it off with soap and water and change
clothing.
Exposure to Exhaust
Engine exhaust fumes are poisonous and can cause loss of consciousness or death in a short time.
Never start the engine or let it run in an enclosed area.
The engine exhaust from this product contains chemicals known to cause cancer, birth defects or other
reproductive harm. Operate this vehicle only outdoors or in well-ventilated areas.
Operating a Damaged Vehicle
Operating a damaged vehicle can result in an accident. After any rollover or other accident, have a
qualified service dealer inspect the entire machine for possible damage, including (but not limited to)
seat belts, rollover protection devices, brakes, throttle and steering systems.
Operating at Excessive Speeds
Operating this vehicle at excessive speeds increases the operator's risk of losing control. Always
operate at a speed that's appropriate for the terrain, the visibility and operating conditions, your skills
and experience and your passengers’ skills and experience.
Operating on Pavement
This vehicle's tires are designed for off-road use only, not for use on pavement. Operating this vehicle
on paved surfaces (including sidewalks, paths, parking lots and driveways) may adversely affect the
handling of the vehicle and may increase the risk of loss of control and accident or rollover. Avoid
operating the vehicle on pavement. If it's unavoidable, travel slowly, travel short distances and avoid
sudden turns or stops.
21
FEATURES AND CONTROLS
Component Locations
Your vehicle is equipped with cab nets (or doors, if equipped) on both sides of the vehicle.
Cab nets must be used by both operator and passengers at all times. Any illustrations without
cab nets are only to allow component identification. Always use the cab nets (or doors).
Not all models (or doors) are equipped with all features. Refer to the specications section
on page 96.
Headlights
Front Bumper/Brush Guard
Radiator
ROPS Cab
Frame
Console
Cargo Box
Fuel Tank
Cap
Cab Net
Receiver
Hitch
CV Boot/Rear Caliper
Muffler (Spark Arrester)
Tailgate
Intake Screens
(both sides)
26
FEATURES AND CONTROLS
Switches
AUX Switch
The AUX switch activates power to the rear accessory
plug. The rear accessory plug is not active/live until the
AUX switch is in the ON position.
Ignition Switch
The ignition switch is a three-position, key-operated
switch. The key can be removed from the switch when
it is in the OFF position.
Auxiliary Outlets
The 12-volt receptacles have spade
connections on the back that may be used to
power an auxiliary light or other optional
accessories or lights. The connections are
behind the console, under the dash.
OFF The engine is off. Electrical circuits are off,
except Acc, 12V.
ON Electrical circuits are on. Electrical equipment
can be used.
START Turn the key to the START position to engage
the electric starter. The key returns to the ON
position when released.
AUX Switch
Ignition Switch
12V Auxiliary
Outlets
30
FEATURES AND CONTROLS
Rollover Protective Structure (ROPS)
The Rollover Protective Structure (ROPS)
on this vehicle meets OSHA 1928.53
rollover performance requirements. Always
have your authorized POLARIS dealer
thoroughly inspect the ROPS if it ever
becomes damaged in any way.
No device can assure occupant protection
in the event of a rollover. Always follow all
safe operating practices outlined in this
manual to avoid vehicle rollover.
WARNING! Vehicle rollover could cause severe
injury or death. Always avoid operating in a
manner that could result in vehicle rollover.
Hood Latches
To remove the hood, rotate the hood latches
1/4-turn and lift the hood away from the
vehicle.
ROPS
Hood Latches
Produkt Specifikationer
| Mærke: | Polaris |
| Kategori: | Ikke kategoriseret |
| Model: | Ranger XP Crew 1000 (2017) |
Har du brug for hjælp?
Hvis du har brug for hjælp til Polaris Ranger XP Crew 1000 (2017) stil et spørgsmål nedenfor, og andre brugere vil svare dig
Ikke kategoriseret Polaris Manualer
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
11 Januar 2025
11 Januar 2025
11 Januar 2025
11 Januar 2025
Ikke kategoriseret Manualer
- HyperJuice
- Pangea Audio
- Essenza
- JUNG
- Lelit
- Proline
- Nero
- RCBS
- LG
- Snazzy FX
- Blue
- Louroe Electronics
- Black Line
- Vipack
- Proficook
Nyeste Ikke kategoriseret Manualer
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
