Encore™ PSW3-1000

Wash Stand with Wheels

Technical Information

POLYJOHN

USA

PolyJohn Enterprises Corp

2500 Gaspar Ave.

Whiting, IN 46394

Phone: 800-292-1305

Fax: 219-659-0625

www.polyjohn.com

info@polyjohn.com

POLYJOHN

WORLDWIDE

PolyJohn (UK) Ltd.

Equinox 1 Audby Lane

Wetherby, England LS22 7RD

Phone: 44 (0) 1937-583333

Fax: 44 (0) 1937-583322

www.polyjohn.co.uk

sales@polyjohn.co.uk

PSW3-1000 - Encore

August - 2020

Page 1 of 4

POLYJOHN

CANADA

PolyJohn Canada

P.O. Box 2300

199 Forest Plain Rd.

Orillia, Ontario LV3 6S2

Phone: 800-465-9590

Fax: 705-325-8250

www.polyjohncanada.ca

info@polyjohncanada.ca

All materials, including resin, pigments

and additives used to make the plastic

components as well as the plumbing

components that come in contact with

the fresh water are U.S. FDA food grade

compliant.

General Overview

The ™ sink is easily Encore transportable

with a built-in handle and lightweight

rubber tread wheels. Designed for use

where convenient hand washing is desired

or required, such as o ices, classrooms,

construction sites, festivals, food service

locations, etc., to be used indoors or out. The

compact design allows it to be used most

anywhere. Ideal where space is limited. Shipped

fully assembled.

Specications

Height 62 in 157.5 cm

Width 18 in 45.5 cm

Depth 20 in 50.8 cm

Fresh Water Capacity 15.5 gal 58.7 L

Gray Water Capacity 19 gal 72 L

Pump Capacity 59.14 ml (per stroke) 2  oz

Soap Dispenser Capacity 887 ml30  oz

Number of Single Dispenses 992 992

Paper Towel Capacity 1 Roll or 500 Single Fold

(2 packs - Georgia Pacic 23504)

Weight Empty 47 lb 21.3 kg

Weight Full 177 lb 80 kg

Fresh Water Drain

Emptying Fresh Water

Drain the fresh water by unscrewing the

plug located at the bottom of the sink by

1/4 turn. Tighten the plug when nished.

Emptying Gray Water

Wheel the sink to a proper and approved

drain location. Pull the hose out from the

rib on the back of the holding tank, remove

the hose cap and empty the gray water. Replace

the cap when nished.

Filling with Fresh Water

Unscrew the ll plug located at the top, left hand

side of the wash basin by pushing down and turning

counter clockwise 1/4 turn. Insert a standard 3/4”

garden or similar type hose and ll with a few gallons

of fresh water to perform a system check. Depress

the pump a few times to “prime” it (the pump has a

built-in check valve that will hold a prime between uses).

If needed, continue lling to the top (which is the 15.5

gallon water level capacity). Tighten the plug when

nished.

Operation Directions

Paper Towel Dispenser

These dispensers are designed to accept towels that are no wider than 9-1/2” wide,

whether using single, multi-fold, or a roll towel. The recommended towels are the

Georgia Pacic #23504 - single fold towel or the Baywest Ecosoft #46200 - roll towel.

Opening the Paper Towel Dispenser

Position your hands on both sides of the

dispenser cover While pulling (as shown).

out on both sides lift up the cover and pull

down towards yourself .

Filling the Dispenser

Filling with Fold Towels: Place the package

of towels on the towel tray with the fold of the

towel facing downward. Pull the rst towel through the

middle opening of the paper towel tray. Close the cover.

Filling with a Roll of Towels: Place the roll of towels on the spindle with the roll of

towels coming off towards you with the arrow end of the spindle facing towards the

right. Place the spindle into the right side o the dispenser rst. Place the left side

of the spindle into the groove on the left side of the dispenser and push down in

place. Feed the roll of towels over the front of the paper towel tra . Close the y

cove . r

PSW3-1000 - Encore

August - 2020

Page 2 of 4

Fresh Water

Fill Plug
