a WARNING! Read and follow all Safety Rules and
Operating Instructions before using this product.
Failure to do so can result in serious injury.
Instruction Manual
PR5020
Quick-Start Guide
NOTE: Your product may differ slightly from the item shown.
1
Mix 2.6 oz. of full synthetic 2-Cycle Oil with 1 gallon of fresh seasonal
gasoline for a 50:1 mixture. Shake well. Pour into fuel tank.
CAUTION: Do not use alternate fuels such as ethanol blends above
10% by volume (E-15, E-85) or any methanol blended fuel.
2
Add bar and chain oil to oil tank
until full.
3
Make sure chain brake is locked by
pushing forward on handguard.
4
Slowly press primer (air purge) bulb
10 times.
5
Pull blue choke lever out fully.
6
Place right foot in rear handle as shown.
Using right hand, pull starter rope sharply
until machine attempts to start, or a maximum
of 5 times.
7
Push blue choke lever to half choke
position.
8
Pull starter rope until engine starts.
9
Allow engine to warm for 30 seconds.
10
Make sure chain brake is unlocked by
pulling back on handguard.
11
Squeeze throttle trigger to set normal
idle. Your chainsaw is now ready
for use.
12
Press red switch to STOP position
ZKHQ¿QLVKHGXVLQJVDZ
STARTING A WARM ENGINE
4 + 5 + 7 + 8
NOTE: If the product does not restart, the problem could be overheated
IXHO7R¿[WKLVSUREOHPWU\WKHIROORZLQJSURFHGXUH
1. Set the product in a cool area away from direct sunlight.
2. Allow the product to cool for at least 20 minutes.
3. Press primer (air purge) bulb repeatedly for 10-15 seconds.
4. Follow the cold starting procedure.
Repeat this procedure if the problem still exists.
NOTE: Always use fresh seasonal fuel and shorten operation time
during unseasonably warm weather.
IMPORTANT:
• Never let your saw chain come in contact with soil/dirt during
operation. This will completely dull your chain and will require
installation of a new chain.
• Check your chain tension prior to each time you start the chainsaw.
&KHFNWHQVLRQRQDQHZFKDLQDIWHUWKH¿UVWPLQXWHVRI
operation. See the manual for chain tensioning instructions.
LDAV50MC115817295 Rev. D 2019-01-23
