Please read these operating instruc-
tions carefully with particular atten-
tion to the safety notes. Always
store these operating instructions
together with the orbital sander.
Technical data
Voltage 230 Volts
Power consumption 135 Watts
Grinding surface area 180 x 85 mm
Sandpaper size 225 x 85 mm
Vibrations per minute 20,000
Shockproof, interference suppressed
Designed in accordance with appli-
cable VDE standards
Included in delivery
EOS 170, orbital sander
Dust extraction connectors ø 32, ø 36,
Operating instructions,
3 sheets of sandpaper
General safety notes
– Always remove the plug from the
power supply socket before carrying
out any maintenance or repair work
such as cleaning the sander or
changing the sandpaper!
– Always disconnect the machine by
removing the plug from the socket,
not by pulling on the mains cable.
– Always wear safety goggles and
dust mask when working.
– Keep the workplace clean and well
illuminated.
– Ensure that the workpiece is suffi-
ciently secured so that you are able
to work safety and effectively.
– Keep children away from the
machine.
– Always keep your machine clean,
and check for possible defects of
damage after every job.
– Always ensure that the switch is
switched off before you insert the
plug into the power supply socket.
– Ensure that any platforms you are
working on are sturdy and stable.
– If the machine is damaged, use the
exploded diagram and the spare
parts list to order any neccessary
parts from Customer Service.
1 Front grip
2 Machine identification
plate
3 On/Off trigger
4 Locking button
5 Main grip
6 Sandpaper
7 Vibration plate
8 Clamping device
9 Vacuum cleaner
attachment
10 Electrical cord
Attaching the dust extraction
connector
Note!
For health reasons, you must use a dust
extraction device.
Warning!
– The orbital sander is not
designed for wet sanding.
– When using a cable reel, make
sure to unroll the cable comple-
tely (wire diameter min. 1 mm
2).
– Disconnect the sander from the
power supply when work has
been completed.
– If the machine is defective, have
it serviced by a qualified dealer
immediately.
On/Off switch
On: Press trigger A.
Continuous Lock trigger A with locking
operation: button B.
Off: Briefly depress trigger A.
