WIRING

1) Connect the Red Power Wire to a switched power source.

2) Connect the Black Ground Wire to either a chassis ground

or directly to the battery (on most off road, marine,

motorcycles and recreation vehicles the battery ground will

be the best location to get your grounding point from).

3) Connect the Yellow wire to 12V Constant Power or the

Battery 12V positive terminal.

4) Connect the Blue Wire to the remote turn-on lead of your

amp. This will turn your amp on and off from the XL-BTR1.

5) Connect the 3.5mm Output to your amplifier (if the

amplifier has a 3.5mm input) or the supplied 3.5mm to RCA

Signal Adapter Cable.

BLUETOOTH PAIRING AND OPERATION

1) Ensure your streaming device has Bluetooth enabled.

2) Turn the ignition (ACC) on.

3) The LED starts blinking (pairing mode).

4) Select XL-BTR1 in your devices Bluetooth setup menu.

5) When successfully connected, the LED on the XL-BTR1

will stop blinking and remain lit. A single beep will be heard

through the connected sound system.

NOTES

- Multiple devices can be paired to the XL-BTR1 but only one

device can be connected at a time.

- The XL-BTR1 will automatically connect to the last device it

was paired with. If that device is not active, other devices will

need to be paired manually.

- When a connected device is out of range for more than a

minute, the XL-BTR1 will automatically disconnect and return

to pairing mode.

- Once connected, audio, volume and media selection is

controlled from the streaming device.

- The XL-BTR1 can be installed in a concealed location since

there are no user controls that need to be accessed.

UNIVERSAL BLUETOOTH RECEIVER

Application Guide

SPECIFICATIONS

- Power: 12V DC

- Current Consumption: 40mA max

- Certified 4.2 Bluetooth Chip

- Frequency Range: 20Hz-20kHz

- Output Level: 1V RMS / 2V max

XL-BTR1

POWERBASS XTREME

LIMITED WARRANTY POLICY

PowerBass USA, Inc. offers limited warranty on PowerBass products under normal use on the following terms:

PowerBass Xtreme Accessories are to be free of defects in material and workmanship for a period of one (1) year.

This warranty applies only to PowerBass products sold to consumers by Authorized PowerBass Dealers in the

United States of America. Products purchased by consumers from a PowerBass dealer in another country are

covered only by that country’s Distributor and not by PowerBass USA.

This warranty covers only the original purchaser of PowerBass product. In order to receive service, the purchaser

must provide PowerBass with the receipt stating the consumer name, dealer, product and date of purchase.

Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to

be equivalent) at PowerBass’s discretion and will not be liable for incidental or consequential damages. PowerBass

will not warranty this product under the following situations:

• Speakers received with bent/cracked frames or significant water damage

• Abuse such as holes in the cone, surround or ripped spider

• Voice coil damage due to amplifier clipping or distortion

• Amplifiers received with apparent rust or corrosion

• Any evidence of liquid damage or exposure to excessive heat

• Attempted repairs or alterations of any nature

• Product that has not been installed according to this owners manual

Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the

period of the express warranty set forth above. Some states do not allow limitations on the length of an implied

warranty, so this limitation may not apply. No person is authorized to assume for PowerBass any other liability in

connection with the sale of this product.

Please call (909) 923-3868 for PowerBass Customer Service. You must obtain an RA# (Return Authorization

Number) to return any product to PowerBass. The RA number must be prominently marked on the outside of the

shipping carton or the delivery will be refused. Please pack your return carefully; we are not responsible for items

damaged in shipping. Return the defective product along with a copy of the original dated retail sales receipt, plus

$12.00 for handling and diagnostic evaluation to:

PowerBass USA, Inc.,

Attn: Returns (RA#__________)

2133 S. Green Privado, Ontario, CA 91761

Residents of HI, AK and US territories will be charged for return shipping. All inquires regarding service and

warranty should be sent to the above address.

Removed or altered serial numbers will void this warranty

Please read through this manual to familiarize yourself with your new Bluetooth Receiver. Should

your PowerBass Xtreme Bluetooth Receiver ever require service, you will need to have the

original dated receipt.

PowerBass Xtreme – A division of PowerBass USA, Inc.

2133 S. Green Privado, Ontario, CA 91761

Tel. (909) 923-3868 – Fax (909) 923-8048

www.powerbassusa.com

This manual is the exclusive property of PowerBass USA, Inc. Any reproduction of this manual, or use other than its

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this product not authorized by PowerBass USA could void the user’s authority to

operate the product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received, including intereference that may cause undesired operation.

FCC COMPLIANCE STATEMENT

1. BLUE/WHITE WIRE -

Remote Amp Turn-on Lead

2. RED WIRE - Remote In (Acc)

3. YELLOW WIRE - 12V Constant Lead

4. BLACK WIRE - Ground Lead

5. 3.5mm PREAMP OUTPUT -

Connect to amplifiers with 3.5mm input

6. RCA to 3.5mm ADAPTER -

Connect to amplifiers with RCA input
