DIGITAL TIME SWITCH EN - 1

PCF-230

We thank you for the purchase of this Profile product.

Note: It is important that you read this manual carefully

before using the product Then keep this manual in a safe

place.

Note

Check that the voltage in-house corresponds to the

information on the type plate.

Do not expose the appliance to extremely high or low

temperatures.

Avoid contact with water.

Technical information

Working voltage: 230V (50Hz) – 250V

Maximum resistive capacity: 3500W/16A

Maximum inductive capacity: 625 VA ind.

Programming: periods of min. 60 seconds.

Day/week program.

Random function.

Explanatory terms

Resistive appliances are appliances that consume the

same current quantity for the whole duration. E.g. lights.

Inductive appliances, on the other hand, consume much

more current at the start than in normal operation. This

includes coffee-makers, boilers, heating appliances, etc.

If the inductive appliance exceeds the inductive capacity

of the time switch the appliance may not be connected to

it. If it is the switching contact in the time switch will

prematurely fail. This falls outside the guarantee

conditions.

Rechargeable battery

A rechargeable battery ensures that the set time and all

other settings are saved in the case of a power failure (to a

maximum of 150 hours with a fully charged battery). If the

battery appears to be nearly empty on purchasing, plug the

time switch into the plug socket for 5 minutes before

starting programming.

12- or 24-hour display

You can select either 12-hour or 24-hour display. To switch

between the 12-hour display and 24-hour display keep the

“h key” +/-1h” pressed together with the “ key

Setting the time

Keep the pressed then press the to set



 key “1-7 key”

the correct day. (1:Monday, 7:Sunday)

Keep the pressed then press the to set



 key “h key”

the correct hour.

Keep the pressed then press the to



 key “m key”

set the correct minute.

ON/OFF switching program

You can set up to 20 programs with the option of

repeating them daily or weekly.

If you press the key once, appears with PROG “--:--“

each day of the week on the display.

Press the repeatedly to set the day(s) on “1-7 key”

which the program must activate. You can also

select combinations of days along with separate

weekdays. Press PROG to confirm and proceed with

setting the hour.

Press the to set the hour at which the “h key”

program must activate then PROG to set the minute.

Press the to set the minute at which the “m key”

program must activate.

 With the you can switch between key

(switching on) and (switching off)

Always confirm a command with .PROG

Repeat the steps above to set a maximum of 20

programs.

The time switch automatically goes back to the

current operating mode and displays the time.

NOTE: The number of memory locations still free is

indicated by e.g. FR18. If all memory locations are

occupied FR00 appears.

Insert the plug of the device to be switched in the plug

socket part of the time switch. If the connected

appliance has an “on-off” switch make sure this is “on”.

Deleting a set program

Press the key 1 to 20 times until the required PROG

switching command appears. Then press the “h

key” and the until you see appear. “m key” “--:--“

Keep the 



 key pressed for 3 seconds to delete the

switching time. The time switch then goes back to

the current operating mode.

NOTE RESET: If you press the key the factory settings

are automatically reset.

Random function

This function randomly switches the timer on and off.

This function ensures the timer generates a random

delay of 1 to 45 minutes for the set times.

Press RND to activate the random function.

This function can be switched off by again

pressing RND.
