Side 1/6

234913 0716

Distributed Exclusively by Ferguson and Wolseley Canada

Remove Old Toilet

1. Shut off water supply line to toilet. Flush toilet and

remove all water from the bowl and tank. Use a

sponge to absorb the water.

2. Disconnect the water supply from the tank.

3. Remove tank from bowl, use screwdriver and

adjustable wrench or socket wrench. Loosen toilet

bowl flange nuts under caps.

4. Remove old bowl by carefully lifting it off the floor.

Clean flange and plug drain with a rag to prevent

sewer gas from escaping.

Install New Toilet

1. If new installation, install a toilet flange into waste

line per flange instructions. Make sure you have

the correct rough in to match your new toilet.

2. Remove the rag from the drain. Install the closet

bolts and washers.

3. Turn the bowl upside down and place it on the flattened

carton box to prevent damage.

4. Install a wax ring evenly around the bowl flange, (horn).

5. Gently lower the

bowl onto the flange

making sure the

flange bolts protrude

through the toilet

openings on the foot.

6. Apply pressure evenly

and rock the bowl

from side-to-side

and front-to-back

until it is firmly on

the floor.

7. Secure the toilet

by first installing

the bolt cap

base, then T-bolt

washer & nut

on each side of

the toilet foot,

tighten evenly

alternating from

side to side until the toilet is secure.

8. Cut any excess closet bolt thread above the nut by

using a hacksaw before snapping on the bolt caps

Preparing the Toilet Tank to Install

To make room for inserting the brass tank connection

bolts, disassemble the flush valve barrel by rotating

counter-clockwise, then re-assemble the barrel after

tank is connected.

9. Place the coupling

gasket around the

flush valve threads

on the tank bottom.

Place the tank

connection rubber

gaskets onto the

brass bolts. Make

sure the gasket seats

firmly. Insert both

bolts from the inside into the tank connection holes.

10.Attached the brass washers and nuts to the brass

bolts on the underside of the bowl rim. While

pressing down on the top of the tank, tighten the

nuts alternately until the tank comes in contact

with the front and back of the toilet bowl tank bars,

achieving a china to china contact.

CAUTION: DO NOT overtighten nuts more than required

for a snug fit. DO NOT spin bolts inside tank with a

screwdriver.

11. Connect the water supply to the ballcock.

Only hand tighten the supply line. DO NOT USE

CHANNEL LOCKS.

CAUTION: Do NOT use cone washer with a plastic

supply line.

CAUTION: If connection leaks after hand tightening,

replace the supply line. Do NOT use any type of sealant

on the water supply connections.

CAUTION: Use of plumber’s putty, pipe dope or any

other sealant on the fittings will VOID the warranty

12. Turn on water, flush, and check for leaks. Adjust

ballcock to proper water line height as noted on the

flush valve tube.

13. Gently place the tank lid cover on to of the tank.

Install the toilet seat and cover per manufacturers

instructions. (Sold Seperately)

Flange Bolts

Flange

Recommended

tools & materials

A. Screwdriver

B. Wrench

C. Marker

D. Sponge

E. Ratchet

F. Tape Measure

G. Level

H. Hacksaw

I. Drill

J. Putty Knife

K. Wax Seal

L. Closet Bolts

M. Water Supply &

Stop Valve

N. Toilet Seat

Installation Instructions

PF9800 Series UHET Toilet

Bowl And Tank With 0.8 GPF

CAUTION

Product is fragile. To avoid breakage and

possible injury handle with care!

Always check components for damage and

tightness before installation.

Horn
