Side 1/3

www.PyleUSA.com

PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION

Features:

• UHF Band Receiver System

• Quad Frequency 4-Channel Design (Channel 1, 2, 3, 4) Addressable Frequency

• Broad Frequency Response Range & Low Distortion

• High Signal/Noise Ratio Performance

• RF Signal Indicator on LCD Screen

• Radio Frequency Display on LCD Screen

• 1 XLR Output Connector Jacks (as only one receiver)

• Independent Channel Adjustable Frequency Controls

• Universal Portable Microphone System

What's in the Box:

• (4) Wireless Microphone

• (8) 'AA' Battery

• (1) USB to Micro USB Charging Cable

• (4) Plastic Microphone Anti-Drop Rubber Ring

• (4) Microphone Sponge

• (1) Microphone Receiver

• (1) 3.5mm Jack Audio Input Connector

• (1) 18650mA Battery

• (1) Plastic Case

Transmitter Technical Specs:

• Frequency Range: 500-938MHz

• Number of Channels: 16

• Oscillation Mode: DSP Chip Frequency Lock

• Stability: ±10ppm

• RF Power: 10dBm

• Audio Frequency Response: 40-18000Hz

• Distortion Degree: <0.5%

• Battery Type: 1.5V, 'AA' Alkaline Battery

• Battery Life: 4-8 Hours

Receiver Technical Specs:

• Frequency Response: 500-938MHz

• Use LCD Screen Display

• Oscillation Mode: DSP Chip Frequency Lock

• Stability: ±10ppm

• Receiving Sensitivity: -95-72 dBm

• Audio Frequency Response: 40-18000Hz

• Distortion Degree: <0.5%

• Signal To Noise Ratio: >90dB

• Audio Output: 300mv (Maximum)

Pairing (pairing ID code + pairing frequency):

The “Frequency Hopping Mode” is a brandnew operation mode introduced

by this program. The data is sent wirelessly by the hand microphone to the

receiver for pairing. After the pairing is successful, the frequency point of the

hand microphone will switch between these 10 frequency points.

The hand microphone can manually change the frequency at any time.

The receiver will automatically follow and jump to the corresponding frequency.

In this way, it not only solves the crosstalk problem, but also provides the

exibility of frequency setting. Products using frequency hopping have been

widely recognized by the market and meet the requirements of most products.

KTV rooms, hand boxes, teaching, personal entertainment and other occasions

to be applicable.

Performance and Characteristics

1. UHF 500MHz-938MHz frequency band is used.

2. Using one-dimensional code + frequency for data encryption and frequency

(even when the same frequency is used to receive, the internal chip and is

interfered by RF, it will only aect the connection range. If the two receivers

are separated by a certain distance (for example, 10 meters), the frequency

re-use can be considered.

3. With automatic mute and impact elimination circuit, help to avoid the impact

and noise of the mic switch.
