• Three models to choose from:
— 2" to 131ft (0.05 to 40m) Model DT40M
— 2" to 196ft (0.05 to 60m) Model DT60M
— 2" to 330ft (0.05 to 100m) Model DT100M
• Automatically calculates Area and Volume
• Indirect measurement using Pythagorean theorem
• Continous mode with min/max function
• Displays Sum (+) / Difference (-) of multiple readings
• Front or rear edge reference
• Memory automatically stores 20 data points
• Stakeout function allows user to accurately mark
distances between studs (for wall framing) and
• Large quad-LCD display with backlit feature
• Low battery indicator and Auto power off
• Complete with 2 AAA batteries and wrist strap
DT40M Laser Distance Meter (131ft/40m) ..............
DT60M Laser Distance Meter (196ft/60m) ..............
DT100M Laser Distance Meter (330ft/100m) ............
Specifications subject to change without notice. Copyright © 2017 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.
Specifications Model DT40M Model DT60M Model DT100M
Measurement Range 2" to 131ft (0.05 to 40m) 2" to 196ft (0.05 to 60m) 2" to 330ft (0.05 to 100m)
Accuracy ±0.08" (±2mm) ±0.08" (±2mm) ±0.08" (±2mm)
Resolution 0.0", 0.00ft, 0.000m 0.0", 0.00ft, 0.000m 0.0", 0.00ft, 0.000m
Area calculation 99,999ft², 99,999m² 99,999ft², 99,999m² 99,999ft², 99,999m²
Volume calculation 99,999 ft³, 99,999 m³ 99,999 ft³, 99,999 m³ 99,999 ft³, 99,999 m³
Dimensions/ Weight 4.6 x 2.2 x 1.3" (116 x 56 x 32mm)/ 3.5oz (100g)
Extech’s Laser Distance Meters offer 3 models measuring
distance up to 131ft (40m), 196ft (60m), or 330ft (100m).
They can calculate area and volume and the integrated
Pythagorean Theorem allows the user to take indirect
measurements. Other features include continuous
measurement with Min/Max distance tracking, 20 point
memory, addition/subtraction of sequential readings,
front or rear edge reference, and a Stakeout function. This
DT series is designed with large quad backlit LCD display
and double molded housing. It also has a handy built-in
bubble level and comes with a wrist strap and batteries.
DT40M UPC Code: 793950520406
DT60M UPC Code: 793950520604
DT100M UPC Code: 793950521014
