Pyle PDWM4520 Manual

Pyle Mikrofon PDWM4520

Læs gratis den danske manual til Pyle PDWM4520 (9 sider) i kategorien Mikrofon. Denne vejledning er vurderet som hjælpsom af 6 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 3.5 anmeldelser. Har du et spørgsmål om Pyle PDWM4520, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/9

PDWM4520

PDWM4540 PDWM4560

Wireless Microphone System

PDWM4520 - PDWM4540 - PDWM4560

www.PyleUSA.com www.PyleUSA.com

CATALOG

1. FOREWORD 2 ---------------------------------------------------------------------------------------------

2. INTRODUCTION --------------------------------------------------------------------------------------- 2

3. SYSTEM FEATURES ----------------------------------------------------------------------------------- 2

4. SYSTEM TYPE ------------------------------------------------------------------------------------------- 2

5. FOUR CHANNEL RECEIVER FEATURES -------------------------------------------------------- 3

6. TRANSMITTER FUNCTION & FEATURES --------------------------------------------------- 4-5

7. TRANSMITTER BATTERY INSTALLATION ----------------------------------------------------- 6

8. BODYPACK TRANSMITTER CONNECTION --------------------------------------------------- 7

9. SYSTEM CONNECTIONS --------------------------------------------------------------------------- 8

10. BODYPACK TRANSMITTER AUDIO GAIN ADJUSTMENT ----------------------------- 9

11. TIPS FOR ACHIEVING MAXIMUM PERFORMANCE ------------------------------------- 9

12. TROUBLESHOOTING ----------------------------------------------------------------------------- 10

12. SPECIFICATIONS ----------------------------------------------------------------------------------- 11

SYSTEM COMPOSITION

1. Receiver ------------------------------------------------------------------------------------------------ X1

2. Wireless hand-held or body-pack microphone ---------------------------------------- X4

3. Audio Cable ------------------------------------------------------------------------------------------ X1

4. AC power adapter of special receiver ------------------------------------------------------ X1

5. Battery 1.5V ------------------------------------------------------------------------------------------ X8

6. User guide -------------------------------------------------------------------------------------------- X1

1 2

FOREWORD

This professional wireless set provides a high quality microphone with UHF

radio system for freedom of movement without loss of audio quality. Please

read this manual before using this equipment in order to avoid damage

through incorrect operation and to get the best performance from your

purchase. This professional series wireless microphone system used an ecient

American, low consumption discharging technique with a super sensitive UHF

high broadband frequency receiver and controlled with 10ppm crystal,

matched with an independent developed mobile frequency compression,

expander circuit, image frequency limiting circuit, a multiple checked silent

and noisy circuit, switch impact noise defect circuit, resist reverberation circuit

and changed output controlled slowly etc. Designed by a computer EDA

system and nished on its item named pattern line. Every system is available to

an excellent electric function by Q.C. strictly.

INTRODUCTION

Your new wireless Series system is designed to give you the best of both sound

reinforcement worlds: the freedom of a wireless system, and the excellent

quality. This manual covers each of the Series system: The VocalArtist-UHF, The

Presenter UHF, The headset-UHF and The Guitarist-UHF.

SYSTEM FEATURES

All UHF Series systems oer a variety of exceptional features, including:

1. Simultaneous Output Use: Unbalanced 1/4' phone plug and balanced XLR

output connectors may be used simultaneously to dierent externaldevices.

2. Range: UHF Series transmitters will work at a distance of up to 50 meters

(about 164 ft.) from the receiver.

3. Noise Squelch: Squelch circuit analyzes signal strength and quality so that

can reduce the likelihood of noise burst due to environmental RF (radio

frequency) noise.

4. Low Battery Warning Light: A red light on the body-pack and hand-held

transmitters warns the user that there is less than one hour of battery Iife left.

SYSTEM TYPE

The Vocal Artist-UHF is a hand-held system designed for singers who desire

the high quality of microphones and the freedom of wireless performance.

The Presenter-UHF is a body-pack system designed for public speakers who

prefer an inconspicuous, hands-free lavalier microphone.

The Headset-UHF is a body-pack system designed for users in physically

active applications, who desire the freedom of hand-free microphone.

The Guitarist-UHF is a body-pack system designed for use with electric

guitars, basses, and other electric instruments.

Produkt Specifikationer

Mærke:	Pyle
Kategori:	Mikrofon
Model:	PDWM4520
Mikrofontype:	Håndholdt mikrofon
Modtager vægt:	3510 g
klirfaktor (THD):	0.5 %
Modtagertype:	Rack beslag modtager
Antal kanaler:	4 kanaler
Signal/støjforhold:	85 dB
Modtager dimensioner (BxDxH):	393 x 234 x 55 mm
Radiofrekvens (RF) interval:	673 - 697.975 MHz
Antal mikrofoner inkluderet:	4
Antal inkluderede modtagere:	1
Driftsfrekvenstype:	Ultrahøj frekvens (UHF)
