INSTALLATION MANUAL

PRJWM8

Projector Wall Mount

20k

0kg

(

(44

44l

lbs

bs)

)

TED

20kg

(44lbs)

RATED

CAUTION: DO NOT EXCEED RATED

LISTED WEIGHT. SERIOUS INJURY OR

PROPERTY DAMAGE MAY OCCUR!

NOTE: Read the entire instruction manual before you start installation and assembly.

WARNING

• Do not begin the installation until you have read and understood all the instructions

and warnings contained in this installation sheet. If you have any questions

regarding any of the instructions or warnings, please contact your local distributor.

• This mounting bracket was designed to be installed and utilised ONLY as

specified in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone with good mechanical ability

who has basic building experience and fully understands this manual.

• Make sure that the supporting surface will safely support the combined weight of

the equipment and all attached hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift and position

the equipment.

• Tighten screws firmly, but do not over tighten. Over tightening can cause damage

to the items, This greatly reduces their holding power.

• This product is intended for indoor use only. Using this product outdoors could

lead to product failure and personal injury.

ST6.3x55 (x4)

W-A

concrete anchor

W-B

(x4)

D8 washer (x4)

W-C

Component Checklist

IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation.

If any parts are missing or faulty, telephone your local distributor for a replacement.

Package M

Package W

adjustable rod (x1)

wall plate (x1)

pivot bracket (x1)

adapter bracket (x1)

cable cover (x1)

M5x10

M-A

(x10) M6x10 (x4)

M-B

D3 (x4)

M-F

washer D5 (x14)

M-H

washer

M5x8 (x4)

M-C

M4x8 (x4)

M-D

4mm Allen key (x1)

M-K

5mm Allen key (x1)

M-L

M3x8 (x4)

M-E

D4 (x4)

M-G

washer D6 (x4)

M-J

washer

94mm

M-M

channel foot (x2)

D5 plastic

washer (x2)

M-I

decorative

cover (x1)

right

connector (x1)

left

connector (x1)

Produkt Specifikationer

Mærke:	Pyle
Kategori:	Wandstøtte
Model:	PRJWM8
Vægt:	1850 g
Produktfarve:	Sølv
Monteringstype:	Væg
Maksimal vægtkapacitet:	20 kg
Afstand til væggen (min.):	430 mm
Afstand til væggen (maks.):	650 mm
