MULTI-CURRENCY DETECTOR

User Manual

PRMDC40

Function Button

The Function Button allows you to customize your machine

• Press and hold the Function Button once and

you will see ( ) in the LED display. This will CLr

clear all calcuation and bring the display back

to ( ).0

• If you continue holding the Function Button,

within 5 seconds you will have the choice

the direction the banknote will exit.

Exiting though the rear ( ) will be displayedUUUU

in the LED.

Exiting thought the front ( ) will be displayed

in the LED.

• The unit will beep 2 times and the

direction of bill exit will blink one in the

LED that go dark. The bill direction is now

set as the new default

• To change direction repeat the above steps

to show the desired direction.

Counting Function

The bill detector has a built-in counting function.

• The unit will automatically detect the bill

denomination and add it to the previous

amount. The new total will then appear in the

LED.

• The machine will count, add and display totals

up to ( )9999

Clearing The Totals

Clearing the totals from the machine is very simple.

• Press and hold the Function Button once and

you will see ( ) in the LED display. This will CLr

clear all calcuation and bring the display back

to ( ).0

Updating For New Currency

The machine has the ability to be updated with the introduction of new currency.

Press and Hold

Function Button to Clear

Press and Hold

Function Button to Clear

Bill Rear Exit

Bill Front Exit

Displays maxium of 9999

UUUU

Bill Exit

Power On Off Switch/

AC Power Input

USB Software

Upgrade Input

4 Digit LED Display

Red Fail/

Green Pass/

Bill Entrance Exit/

Status Indicators

Function Button

Introduction:

Counterfeit Bill Detector

Operating Instructions:

Starting up

Plug the power cord into the AC power input and plug the AC adapter into any

standard AC 110 volt or 220 volt outlet Switch the machine onto the ON position. .

The machine will then go though a calibration setup.

• The unit will display (8.8.8.8.).

• The unit will then sound two (2) beeps and a

Window.

• The machine will then verify the default currancy.

( ) Euro will show in the LED display.EUr

• ( ) or ( ) will then be displayed.UUUU

This indicates the direction the bill will exit

after it is scanned. (See Function Button)

• The motor will then cycle twice.

• Once a ( ) is displayed in the LED, the unit0

is now ready use.

Getting Started

Once the ( ) is displayed in the LED, the machine is ready to use.0

• Place a bill along the left edge of the entrance

with the top of the head on the bill to the right.

• Gently push the bill into the entrance throat.

• The machine will pull the bill into the unit. It will

scan the bill for ( ) correct direction of bill IM

being fed ( ) Infrared characteristics, ( ) IR UV

Ultraviolet characteristics and ( ) Magnetic MG

strip detection.

• The machine will discharge the bill either through

the front of rear of the unit.

If The Banknote Passes Inspection

• If the bill passes inspection, the light in the

• The unit will sound a beep.

• The denomiation of the bill will be displayed

by the LED.

If The Banknote Fails Inspection

• If the bill fails inspection, the light in the

• The Unit will sound with (3) beeps.

• The LED will display the same amount

before the last bill was inserted.

• Failure Lights will display for feature or

Ready to Use

Place Bill Along Left Edge

Passes with GREEN Light

and Bill Denomination Displayed

Failed with RED Light

Failure LED Indicators Light

UUUU

C alibration Display

features which did not pass.(Status Indicator)
