Quick Start Guide
Q-SYS Core 610 Processor
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions and keep a copy for future reference. Strictly follow and heed all instructions and warnings. Install the
device only as instructed.
2. Do not use or submerge this device in or near water or liquids.
3. Clean only with a dry cloth. Do not use any aerosol spray, cleaner, disinfectant or fumigant on, near, or into the device.
4. Do not install the device near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers).
5. Refer all service to qualified personnel.
6. Observe all applicable local codes. Consult a licensed professional engineer when devising an equipment installation to ensure
compliance.
Maintenance and Repair
WARNING: Advanced technology, e.g., the use of modern materials and powerful electronics, requires specially adapted
maintenance and repair methods. To avoid a danger of subsequent damage to the apparatus, injuries to persons and/or the creation
of additional safety hazards, all maintenance or repair work on the apparatus should be performed only by a QSC authorized service
station or an authorized QSC international distributor. QSC is not responsible for any injury, harm or related damages arising from any
failure of the customer, owner or user of the apparatus to facilitate those repairs.
Overview
The Q-SYS Core 610 represents the next-generation of Q-SYS processing, pairing the Q-SYS OS with an enterprise-grade Dell COTS
server to deliver a flexible and scalable audio, video and control solution for a vast range of larger scale applications. It is a fully
networked AV&C processor, letting you centralize processing for multiple spaces or zones while distributing network I/O where it’s
most convenient.
Reference
Dell Server Hardware — For additional information regarding hardware specifications, regulatory compliance, or iDRAC, visit the
Dell server website at dell.com/servers.
Q-SYS Specifications and Software — For additional information regarding the Q-SYS Core 610 and other software feature
specifications, Q-SYS Designer Software (QDS), and other Q-SYS products and solutions, visit qsys.com.
Self Help Portal — Read knowledge base articles and discussions, download software and firmware, view product documents and
training videos, and create support cases at qscprod.force.com/selfhelpportal/s.
Customer Support — Refer to the Contact Us page on the Q-SYS website for Technical Support and Customer Care, including their
phone numbers and hours of operation. Go to qsys.com/contact-us.
Warranty — For a copy of the QSC Limited Warranty,go to qsys.com/support/warranty-statement.
TD-001671-01-B
*TD-001671-01*
2
© 2023 QSC, LLC All rights reserved. QSC, the QSC logo, Q-SYS, and the Q-SYS logo are registered trademarks of QSC, LLC in the U.S. Patent and Trademark Office and
other countries. Patents may apply or be pending. All other trademarks are the property of their respective owners.
qsys.com/patents
qsys.com/trademarks
Front Panel Features
1 2 3 4 5 6
789
1. Status and ID indicator – Enabled via Q-SYS Designer
Software
2. Bezel lock
3. Removable active bezel
4. LCD navigation buttons
5. – Displays Q-SYS Core processor name, status, and LCD
health alerts.
Rear Panel Features
1 2 3 4
56789
1. Serial communications RS232 (male DE-9) – For connection to serial devices
2. – Not supportedOn-board LAN ports
3. Q-SYS LAN ports (RJ45, 1000 Mbps) – From left to right: LAN A, LAN B, AUX A, AUX B
4. – 450WPower supply unit (PSU)
5. – Press to identify the device in Q-SYS Designer SoftwareID button and indicator
6. – For connection to a cable management armCMA jack
7. USB ports – Not supported
8. – For remote iDRAC access: iDRAC dedicated port (RJ45)
Default IP = 192.168.0.120, Default username = root, Default password = calvin
9. VGA video output (female HD15) – Not supported
6. Power button
7. USB port – Not supported
8. – Includes the product serial number and Information tag
Q-SYS Support contact information
9. Q-SYS Media Drive – One 2.5-inch, 480 GB, SATA 6 Gb
SSD drive. Additional drives not supported.
ATTENTION!: The Front Panel is included separately in the box and must be installed to observe boot-up and status
messages. After a power cycle, the LCD displays "Initializing" for approximately 1 minute. During this time, no other
indicators or sounds are active. Total boot-up time after a power cycle is approximately 4 minutes (2-3 minutes for
subsequent reboots), at which time the Core 610 is discoverable in QDS.
