QFinderUser’sManual

A.Overview

QFinderutilizesthe toGPStechnology markyourdesiredlocations and allowsyoutobe

backtothelocationslateratanytimebytheprecisedigitalcompasswith ‐8 directional

arrows.It’s a prettypracticaltoolintermsofhiking,camping,kayaking,fishing,parking,

andtraveling.

B.Product Notice

z QFinder   must be used outdoorsbecauseitutilizesGPStechnologytomark

locations. Indoor environmentwillcausethedeviceunabletoreceivesatellite

signalstofindyourlocation         and movement, such as in am indoor parking garage

z For          the first time use or not use after a long time   of the device, it   would need more

timetogetGPSfixed.

z The      manufacturer assumes no responsibility for any damages and lossresulting

fromthe             use of this manual or from misuse of the product in any way

z Please         clean the unit with a dry and clean softclose.Donotuseharshcleaning

solvents,chemicals,alcohol,   or strong detergents

z Donotattemptto take apartthedevicebyyourself.Unauthorized  hacking may

damagetheunit,andvoidyourwarranty



C.StandardPackage

1. 2.QFinder NeckLanyard



D.Features

z 4locationbackpoints(A/B/C/Dpoint) 

z The         estimate straight line distance measuring of the location back points

z LCD  Display with Backlight

z Support    ‐Digital Compass with 8 directionalarrow

z Support   Temperature and Real Time   (Time Zone adjustable)

z Adopts      SiRF Star III GPS GPS chipset

z High   ‐  sensitivity‐159dBm and 20 Channel tracking

z Smart   power saving and operateson 2 AAAbatteries(notincluded)

z IPX‐   6 Water resistance

z SupportstandardNMEA‐0183protocol

E.ProductSpecification

General

GPSChipSiRFStarIII

FrequencyL1,1575.42MHz

C/ACode   1.023MHz chip rate

ChannelsSupport20channels

Antenna(Intemal)Built‐in low noiseantenna

Sensitivity

To‐159dBmTracking,SuperiorUrbanCanyonPerformance

AcquisitionRate

ColdStart42sec,average

WarmStart38sec,average

HotStart 1 sec,average

Reacquisition0.1sec

Accuracy

Position<10 M at2DRMS

Velocity0.1m/sec,withoutSA

Time1 sμsynchronizedtoGPStime

Datum

WGS‐84

DynamicConditions

Altitude<18,000m

Velocity<515m/sec

Acceleration<4G

MotionalJerk4m/sec.

Display & Button

LCM‐ICON33x42mmdisplaysize

2Buttons(Power/ModeandMark/Backlight)

GPSProtocol

Default:NMEA‐0183 – GGA, GSA, GSV,GLL,RMC,VTG

Baudrate4800~38400bps,Databit bit : 8,stop  : 1(Default)*

Device Size

88Lx53Wx29Dmm

  100g (excluding battery)



Power

2 x AAAbatteries(forbothalkalineandrechargeable)

OperationCurrent<55mA(Typical)

OperationTime 12hrs,

Functionality

E 4‐Compass locationback(A/B/C/Dmarks)

Temperature  (℃/℉)Time display

Accessories

Lanyard

Environmental

OperatingTemperature0 + ℃to 60 ℃

StorageTemperature‐20     ℃to + 70 ℃

WaterresistanceIPX‐ 6



F.Appearance

IconIndicators:

BatterystatusCompassmode

GPSFix

TemperatureMode

 (Flash) GPSnotFixA/B/C/Dlocationmode



G.HardwareFunction

HardwareFunctionDescription

Poweron/offthe

device

Hold Mode/Power buttonfor1sectopoweron;hold

Mode/Power button againfor3secto power off

Modeswitch

Afterpoweron,shortpush Mode/Power buttonto

switchamongdifferentmodes

Marklocation

Shortpush Mode/Power button selectto either

A/B/C/DlocationandholdMarkbuttonfor3secto

mark

Setuptimezone

1.Incompassmode,hold Mark buttonfor3sec 

2.PressMode/Power     button to change time zone

3.Hold Mark buttonfor3sectofinish setup

Change

temperature/distance

Unit

Intemperature/distancemode,holdboth Mark and

Mode/Power   button for 3sec

30secBacklight

Shortpush Backlight/Mark buttontoenablebacklight

for30sec

Note:Thedevicewillautomaticallypower pushingoffafter30minuteswithout any

buttontosaveenergy.



H.BatteryInstallation

1.Rotatescrewcounterclockwisetoopenbatterycover.



2.Insert 2 “AAA”alkalineorlithiumbatteries.

  (Batteriesare    not included in package)



3.Put andthebatterycoverback rotatescrewclockwisetolockit.

I.Starttouse

1.Push Mode/Power buttonto power onthedevice

2.EnsureyouareoutdoorunderanopenskyenvironmentandwaituntilQFinderget

fixwithGPSindicatornotflashing

 

3.CompassMode: aQFindercanbe digitalcompass.Arrowwillalways  point north.



To setup time zone, hold Mark buttonfor3secandPress Mode/Power buttonto

changetimezone.Hold finish Mark buttonfor3secto setup

4.Temperature Mode: ShortpushMode/Power     button to switch to temperature

mode.



To change temperature unit, holdboth Mark and Mode/Power buttonfor3sec.

5.Location Mode: Shortpush Mode/Power buttonto toswitch locationmode.



To marklocation, Shortpush Mode/Power button selectto eitherA/B/C/Dlocation,

andholdMarkbuttonfor3secuntil the distanceindicatorbecomes 0 and ‐8 directional

arrowsflash.

Tochangedistanceunit,holdbothMark and Mode/Power   button for 3sec.

When becomearrivelocation,thedistancewill  0 and ‐8 directional willarrows flash.

J.TroubleShooting

ProblemSolution

Unableto power on1. Checkif isthe the device alreadyoutofbettery

2. Checkifthebatterymaynotinstalledproperly.

Unabletodisplay

information

GPSmaynotgetfix.Pleasemakesuretohave

QFinder outside underopensky environment until 

theGPSindicatorisstea dy.

GPSnotfix

BlinkingGPSindicator

Notimedisplay

GPSfix

SteadyGPSindicator

Timedisplay

CurrentTime  ‐  in 24 hour format

Currentazimuth

Arrowpointsnorth

CurrentTime  ‐  in 24 hour format

Currenttemperaturein°C °For 

Arrowpointsnorth

CurrentTime  ‐  in 24 hour format

CurrentstraightlinedistancefromlocationA

LocationA/B/C/Dicon

ArrowpointslocationA/B/C/D

Spec.issubjecttochangewithoutpriornotice. 

All Allrightsreserved. registeredtrademarkisbelongtotheir

respectedcompanies.
