OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
888-994-7636, fax 888-864-7636
uniedbrands.net
PART NUMBER PP MNL1803, REV. H (08/23)
This manual provides information for:
8000-290 & 9000W-290 SERIES
PREP TABLES
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other ammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING R290 ammable refrigerant in use. Improper installation,
adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Randell suggests
that if you are suspicious of damage to make a notation on the delivery
receipt. It will be the responsibility of the consignee to le a claim with the
carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE: Due to a continuous program of product improvement, Randell reserves the
right to make changes in design and specications without prior notice.
NOTICE: Please read the entire manual carefully before installation. If certain
recommended procedures are not followed, warranty claims will be denied.
MODEL NUMBER _________________________
SERIAL NUMBER _________________________
INSTALLATION DATE ______________________
The serial number is located behind the hinged vented
door of the compressor machine compartment. An
example is shown here.
EQUIPMENT DESCRIPTION
MODEL PAN
CAPACITY
1/3 SIZE
L D H DOORS STORAGE
CU. FT.
HP VOLT AMPS NEMA SHIP
WT.
WORK
SURFACE
REAR OF UNIT
(CLOSED COVER)
OVERALL
(COVER OPEN)
8148N-290 6 48” 33” 35” 44” 52.5” (1)27” 9.0 1/3 115/60/1 6 5-15P 405
8260N-290 8 60” 33” 35” 44” 52.5” (2)24” 14.67 1/3 115/60/1 6 5-15P 459
8268N-290 9 68” 33” 35” 44” 52.5” (2)27” 17.76 1/3 115/60/1 6 5-15P 484
8383N-290 11 83” 33” 35” 44” 52.5” (2)24”,(1)21” 23.55 (2) 1/4 115/60/1 5.8 5-15P 585
8395N-290 13 95” 33” 35” 44” 52.5” (3)27” 28.18 (2) 1/4 115/60/1 5.8 5-15P 630
84111N-290 15 111” 33” 35” 44” 52.5” (3)24”,(1)21” 32.81 (2) 1/4 115/60/1 5.8 5-15P 675
MODEL PAN
CAPACITY
1/6 SIZE
L D H DOORS STORAGE
CU. FT.
HP VOLT AMPS NEMA SHIP
WT.
WORK SURFACE
(NO CUTTING BOARD)
REAR OF UNIT
(NO COVER)
OVERALL
8148W-290 21 48” 33” 35” 46.5” 53.5” (1)27” 9.0 1/3 115/60/1 6 5-15P 530
8268W-290 30 68” 33” 35” 46.5” 53.5” (2)27” 17.76 1/3 115/60/1 6 5-15P 595
8395W-290 42 95” 33” 35” 46.5” 53.5” (3)27” 28.18 (2) 1/4 115/60/1 5.8 5-15P 785
MODEL PAN
CAPACITY
1/6 SIZE
L D H DOORS STORAGE
CU. FT.
HP
(BASE &
RAIL)
VOLT AMPS NEMA SHIP WT.
9148W-290 18 48" 33" 46.5" (1) 27" 5.5 1/3 115/60/1 6 5-15P 405
9260W-290 24 60" 33" 46.5" (2) 24" 9.8 1/3 115/60/1 6 5-15P 465
9272W-290 30 72" 33" 46.5" (2) 27" 11.2 1/3 115/60/1 6 5-15P 510
Information contained in this document is known to be current and accurate at the time of printing/creation. Reference our product line website for the most
updated product information and specications. © 2023 Electrolux Professional, Inc. All Rights Reserved.
2 OM-8000 & 9000W SERIES PREP TABLES
INSTALLATION
CAUTION: THIS UNIT CONTAINS R290 FLAMMABLE REFRIGERANT. USE CAUTION
WHEN HANDLING MOVING AND USE OF THE REFRIGERATOR OR FREEZER.
AVOID DAMAGING THE REFRIGERANT TUBING OR INCREASE THE RISK OF A
LEAK.
WARNING:
FAILURE TO FOLLOW INSTALLATION GUIDELINES AND
RECOMMENDATIONS MAY VOID THE WARRANTY ON YOUR UNIT.
WARNING: IT IS IMPORTANT THAT YOUR UNIT HAS ITS OWN DEDICATED LINE.
CONDENSING UNITS ARE DESIGNED TO OPERATE WITH A VOLTAGE
FLUCTUATION OF PLUS OR MINUS 10% OF THE VOLTAGE INDICATED ON
THE UNIT DATA TAG. BURN OUT OF A CONDENSING UNIT DUE TO EXCEEDING
VOLTAGE LIMITS WILL VOID THE WARRANTY.
THE DANFOSS CONTROLLER HAS LOW VOLTAGE PROTECTION AND WILL
NOT OUTPUT VOLTAGE TO THE COMPRESSOR IF VOLTAGE IS LESS THAN
104V.
WARNING: IT IS IMPORTANT THAT A VOLTAGE READING BE MADE AT THE COMPRESSOR
MOTOR ELECTRICAL CONNECTIONS, WHILE THE UNIT IS IN OPERATION
TO VERIFY THE CORRECT VOLTAGE REQUIRED BY THE COMPRESSOR IS
BEING SUPPLIED. LOW OR HIGH VOLTAGE CAN DETRIMENTALLY AFFECT
OPERATION AND THEREBY VOID ITS WARRANTY.
WARNING: EVAPORATOR FANS RUN CONTINUOUSLY WHILE THE BASE IS POWERED
ON.
WARNING: THIS UNIT IS INTENDED FOR USE IN LABORATORIES IN COMMERCIAL,
INDUSTRIAL, OR INSTITUTIONAL OCCUPANCIES AS DEFINED IN THE
SAFETY STANDARD FOR REFRIGERATION SYSTEMS, ASHRAE 15.
SELECTING A LOCATION FOR YOUR NEW UNIT
The following conditions should be considered when selecting a location for
your unit:
1. Floor Load: The area on which the unit will rest must be level, free of vibration,
and suitably strong enough to support the combined weights of the unit plus
the maximum product load weight. All casters must be in contact with the oor
to support the weight. Casters may require shims in order for the caster to be
in contact with the oor. NOTE: If there is a question pertaining to weight load
limits, consult the factory at 1-888-994-7636.
2. Clearances: Unit shall have a clearance of 0 inches at the top, 0 inches at
the rear and 0 inches at each side.
3. Ventilation: The air cooled self contained unit requires a sufcient amount
of cool clean air. Avoid surrounding your unit around other heat generating
equipment and out of direct sunlight. Also, avoid locating in an unheated
room or where the room temperature may drop below 70° F (21°C) or above
86°F (32°C). Do not place any object that can block the ventilation exhaust
from the machine compartment register.
INSTALLATION CHECKLIST
After the nal location has been determined, refer to the following checklist prior
to start-up:
1. Check all exposed refrigeration lines to ensure that they are not kinked,
dented, or rubbing together or rubbing against any steel.
2. Check all visible components for any potential damage.
3. Check that the condenser and evaporator fans rotate freely without striking
any stationary members.
4. Unit must be property leveled; Check all legs or casters ensure they all are
in contact with the oor while maintaining a level work surface. Adjusting
bullet feet height or shimming casters may be necessary if the oor is not
level. NOTE: Damage to equipment may result if not followed. Randell is
not responsible for damage to equipment if improperly installed.
5. Plug unit into power source. Unit will come on. If unit does not turn on, refer
to controller operation section of this manual to manually turn on the unit.
6. Allow unit time to cool down to holding temperature. If temperature
adjustments are required, the control is located on the front panel. Conrm
that the units is holding the desired temperature.
7. If unit has drawers, check drawer to ensure the drawer slides freely and fully
extents along with seating in the cabinet properly when closed.
8. Refer to the front of this manual for serial number location. Please record
this information in your manual on page 1 now. It will be necessary when
ordering replacement parts or requesting warranty service.
9. Allow your unit to operate for approximately 45 minutes before putting in
food in the rail. Allow 2 hours for base of the unit to cool down to storage
temperature, prior to loading product. NOTE: All motors are oiled and sealed.
ELECTRICAL SUPPLY
The wiring should be done by a qualied electrician in accordance with local
electrical codes. A properly wired and grounded outlet will assure proper
operation. Please consult the data tag attached to the compressor to ascertain
the correct electrical requirements. Supply voltage and amperage requirements
are located on the serial number tag located on the rear interior wall.
IMPORTANT - READ FIRST - IMPORTANT
INTERIOR EVAPORATOR COVER
EXTERIOR OF UNIT
RISK OF FIRE OR EXPLOSION.
FLAMMABLE REFRIGERANT USED.
DO NOT USE MECHANICAL DEVICES
TO DEFROST REFRIGERATOR. DO NOT
PUNCTURE REFRIGERANT TUBING.
RIESGO DE INCENDIO O EXPLOSIÓN. REFRIGERANTE INFLAMABLE UTILIZADO. NO
UTILICE DISPOSITIVOS MECÁNICOS PARA DESCONGELAR EL REFRIGERADOR. NO
PERFORE LA TUBERÍA DEL REFRIGERANTE.
RISQUE D’INCENDIE OU
D’EXPLOSION.
INFLAMMABLE
RÉFRIGÉRANT UTILISÉ.
NE PAS UTILISER DE
DISPOSITIFS
MÉCANIQUES POUR
DÉGIVRER LE
RÉFRIGÉRATEUR. NE
FAIRE AUCUN TUBE
RÉFRIGÉRANT DE
PONCTION.
DANGER
SB6.1.2
WARNING ALERTE
CAUTION ATTENTIÓN
DO NOT REMOVE PANEL - HIGH VOLTAGE -
QUALIFIED PERSONNEL ONLY
NE PAS RETIRE LE PANNEAU - HAUTE TENSION -
PERSONNEL QUALIFIÉ SEULEMENT
NO RETIRE EL PANEL - ALTA TENSIÓN -
CALIFICADO PERSONAL
MOVING PARTS, DO NOT OPERATE
WITH COVER REMOVED
PIÉCES MOBILES NE PAS FAIRE
FONCTIONNER SANS COUVERCLE
LAS PIEZAS DE MOVIMIENTO NO FUNCIONAN
CON LA CUBIERTA RETIRADA
PP LBL1701 REV B
LABEL DIMENSION: 9 in x 3.25 in
RISK OF FIRE OR EXPLOSION.
DISPOSE OF PROPERLY IN
ACCORDANCE WITH FEDERAL OR
LOCAL REGULATIONS.
FLAMMABLE REFRIGERANT USED.
PRECAUCIÓN RIESGO DE INCENDIO O EXPLOSIÓN. DESÉCHELO ADECUADAMENTE CONFORME
A REGLAMENTOS FEDERALES O LOCALES. REFRIGERANTE INFLAMABLE UTILIZADO.
MISE EN GARDE RISQUE
D’INCENDIE OU
D’EXPLOSION. ÉLIMINER
(or DISPOSER)
CORRECTEMENT
CONFORMÉMENT AUX
RÉGLEMENTATIONS
FÉDÉRALES OU LOCALES.
RÉFRIGÉRANT
INFLAMMABLE UTILISÉ.
SB6.1.4
LABEL DIMENSION: 6 in x 2.75 in
PP LBL1704 REV B
CAUTION
RISK OF FIRE OR EXPLOSION DUE TO
PUNCTURE OF REFRIGERANT TUBING; FOLLOW
HANDLING INSTRUCTIONS CAREFULLY.
FLAMMABLE REFRIGERANT USED.
PRECAUCIÓN RIESGO DE INCENDIO O EXPLOSIÓN DEBIDO A LA PERFORACIÓN DE LA TUBERÍA DE
REFRIGERANTE; SIGA CUIDADOSAMENTE LAS INSTRUCCIONES DE MANEJO. REFRIGERANTE
INFLAMABLE UTILIZADO.
MISE EN GARDE RISQUE
D’INCENDIE OU
D’EXPLOSION EN RAISON
DE LA PERFORATION DU
TUBE RÉFRIGÉRANT;
SUIVEZ ATTENTIVEMENT
LES INSTRUCTIONS DE
MANIPULATION.
RÉFRIGÉRANT
INFLAMMABLE UTILISÉ.
CAUTION
SB6.1.5
PP LBL1705 REV B
LABEL DIMENSION: 6.25 in x 2.8 in
RISK OF FIRE OR EXPLOSION. FLAMMABLE
REFRIGERANT USED. CONSULT REPAIR MANUAL
/ OWNER’S GUIDE BEFORE ATTEMPTING TO
INSTALL OR SERVICE THIS PRODUCT. ALL
SAFETY PRECAUTIONS MUST BE FOLLOWED.
PRECAUCIÓN RIESGO DE INCENDIO O EXPLOSIÓN. REFRIGERANTE INFLAMABLE UTILIZADO. CONSULTE EL MANUAL DE REPARACIÓN /
MANUAL DEL USUARIO ANTES DE INSTALAR O REPARAR ESTE PRODUCTO. DEBEN SEGUIRSE LAS PRECAUCIONES DE SEGURIDAD.
MISE EN GARDE RISQUE
D’INCENDIE OU
D’EXPLOSION. RÉFRIGÉRANT
INFLAMMABLE UTILISÉ.
CONSULTER LE MANUEL DE
RÉPARATION / GUIDE DE
L’UTILISATEUR AVANT
D’ESSAYER D’INSTALLER OU
DE RÉPARER CE PRODUIT.
TOUTES LES PRÉCAUTIONS
DOIVENT ÊTRE RESPECTÉES.
SB6.1.3.b
PP LBL1703 REVB
LABEL DIMENSION: 7.5 in x 5.36 in
SB6.1.3.a
RISK OF FIRE OR EXPLOSION. FLAMMABLE
REFRIGERANT USED. TO BE REPAIRED ONLY
BY TRAINED SERVICE PERSONNEL. DO NOT
PUNCTURE REFRIGERANT TUBING.
PELIGRO RIESGO DE INCENDIO O EXPLOSIÓN. REFRIGERANTE INFLAMABLE UTILIZADO. DEBE SER REPARADO
SOLAMENTE POR PERSONAL DE SERVICIO CAPACITADO. NO PERFORE LA TUBERÍA DEL REFRIGERANTE.
DANGER RISQUE
D’INCENDIE OU
D’EXPLOSION.
RÉFRIGÉRANT
INFLAMMABLE UTILISÉ.
POUR ÊTRE RÉPARÉ QUE
PAR UN TECHNICIEN
QUALIFIÉ. NE PAS
PERFORER LE TUBE
RÉFRIGÉRANT.
CAUTION
DANGER
NEAR EXPOSED REFRIGERANT TUBING
NEAR MACHINE COMPARTMENT AND NAMEPLATE

Produkt Specifikationer

Mærke: Randell
Kategori: Ikke kategoriseret
Model: 8000W-290

Har du brug for hjælp?

Hvis du har brug for hjælp til Randell 8000W-290 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Randell Manualer

Randell

Randell FX-1RE-290 Manual

17 September 2025
Randell

Randell 3300 Manual

17 September 2025
Randell

Randell FX-1-290 Manual

17 September 2025
Randell

Randell FX-2CS-290 Manual

17 September 2025
Randell

Randell 3500 Manual

17 September 2025
Randell

Randell 3600 Manual

17 September 2025
Randell

Randell FX-2UCB-290 Manual

16 September 2025
Randell

Randell RS FG-EHI Manual

2 September 2025
Randell

Randell RSW-STSSFF Manual

2 September 2025
Randell

Randell RSW-STSSNA Manual

2 September 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Sungrow

Sungrow SH10RT-V113 Manual

18 Oktober 2025
AstralPool

AstralPool Niche Switch Manual

18 Oktober 2025
Sungrow

Sungrow SH8.0RT-V113 Manual

18 Oktober 2025
AstralPool

AstralPool Roma Manual

18 Oktober 2025
Evenflo

Evenflo SafeMax Manual

18 Oktober 2025
NEO Tools

NEO Tools 94-002 Manual

18 Oktober 2025
LC-Power

LC-Power Platinum Pro LC1000P V3.1 Manual

17 Oktober 2025
Metz

Metz 130B21-E Manual

17 Oktober 2025
NEO Tools

NEO Tools 99-038 Manual

17 Oktober 2025
FBT

FBT MPU 2120 Manual

17 Oktober 2025
