Instructions for Manhatton, Keyhole, Chicago, Oakland, Glendale, Baltimore & Arlington

STAINLESS STEEL INSET SINKS

WITH FIXED POSITION CLIPS

Installation Instructions

Aftercare Information

Installer

Please leave this leaet with the user, as it contains valuable

after care advice.

Notes

 Please take care of sharp metal edges before and

during installation.

 During installation, take care to protect the sink

from scus and scratches.

 Avoid straining and overtightening of all plumbing

xtures connected to the sink.

 Carefully check that the moulding and edges of the

sink are dead level so that water will ow o the

drainer.

 We recommend that the worktop opening is sealed

using waterproof sealant, paint or a similar material.

 The clamping brackets are suitable for worktops of

between 28–40 mm thickness. If your worktop is a

dierent size then it may require packing under the

clips or rebating.

Installation

Marking Out the Opening

1. We recommend that you t the inset sink to the

worktop before permanently xing the worktop to the

cabinet.

2. Place the sink upside down on the worktop. Position

the sink on the worktop as required. Make sure the

cabinet framework will clear all parts of the sink. Using a

soft, sharp pencil draw around the sink as accurately as

possible (Fig.1). Remove the sink.

Alternatively, you can use a sink template. For details go

to www.rangemaster.co.uk.

3. Draw another line 10 mm inside the sink top outline –

this is the cutting line for the opening (Fig.2).

4. Drill as large a hole as possible inside the cutting line.

Using a padsaw, jigsaw or similar, cut out the opening

up to the cutting line.

Fitting the Sink

1. Open the hinge on the clip.

2. Turn the sink upside down and lay the worktop over

the sink. Swing each clip into place (Fig.3) – this is the

most eective method, although if the worktop has

been tted to the cabinet the sink can be placed in the

opening and xed in position from underneath.

3. Centre the sink. Tighten the xing screws in the

sequence shown in Table 1.

 DO NOT tighten fully at rst attempt.

 DO NOT overtighten the clips as this may distort the

sink rim.

Remove any surplus sealing material (Fig.4).

Worktop

Final position

of sink

Cutting line for opening

10 mm

Fig.1

Fig.2

Due to our policy of continual improvement, we reserve the right to change specications without prior notice.

1 2 3

SinkWorktop

Worktop

Trim with a sharp knife

Sealing tape

Fig.3

Fig.4

INSTALLATION

Produkt Specifikationer

Mærke:	Rangemaster
Kategori:	Køkkenvask
Model:	OL9851
Bredde:	985 mm
Dybde:	508 mm
Vægt:	6500 g
Produktfarve:	Rustfrit stål
Pakkevægt:	8600 g
Pakkedybde:	265 mm
Pakkebredde:	650 mm
Pakkehøjde:	1130 mm
Installationsrum bredde:	965 mm
Installationsrum dybde:	488 mm
Første skål, dybde:	190 mm
Første skål, dimensioner (BxL):	450 x 420 mm
Antal vaskeskåle:	1 skåle
Vask, type:	Skylle-monteret håndvask
Vask form:	Rektangulær
Vask materiale:	Rustfrit stål
Facon på første vask:	Rektangulær
Vandhane, hul:	Ja
Drænebræt:	Ja
Drænebræt, position:	Højre
Vandhane inkluderet:	Ingen
Antal huller til haner:	1
Størrelse på vandhane:	35 mm
