Side 1/2

KEY FEATURES

360° Panning Base

25mm Ball

is hollow

for reduced

weight.

CNC machined

body is robust

and sealed to

prevent dust

contamination.

Quick-Release clamps are offered in screw-

knob or lever-release styles (platform also

available). Both clamp styles have laser-

engraved scales in 1mm increments.

Use Drop Notch

to position your

camera at 90° from

top dead center

(portrait mode).

Main lock T-Lever

to easily lock

ballhead; T-Lever

simultaneously

locks both ball

articulation and

panning.

Load Capacity....................................................8.8 pounds (4kg)

Ball Articulation.....................................................±45º, 90º notch

Tension Adjustment......................................via Main Lock T-lever

Height of BH-25 Pro...........................................2.6” (66mm)

Tripod Mount.............................................Stainless Steel 3/8”-16

Base Diameter...........................................................1.3” (33mm)

Ball Diameter.............................................................1.0” (25mm)

Weight of BH-25 Pro..............................6.5 ounces (185g)

Main Lock T-Lever..........................Spring loaded & repositionable

SPECIFICATIONS:

BH-25 Pro Shown Below

BALLHEAD ID: _____________________________

BH-25 BALLHEAD

1146 Farmhouse Lane, San Luis Obispo, CA 93401 USA

1-805-528-6321 | 1-888-777-5557

www.ReallyRightStu.com

MODELS

The BH-25 ballhead is available with a Really Right Stuff quick-release

clamp or a flat platform; also available without clamp or platform.

BH-25 PF

Head comes with flat platform with ¼”-20

threaded stud for direct mounting of camera.

Platform diameter = 1½ inches (38mm); fitted

with cork bed to provide snug fit of camera.

BH-25 Pro

Head comes with B2-mAS quick-release clamp

secured with ¼”-20 flat head screw. Clamp

accepts most Arca-Swiss compatible plates (not

Novoflex). Purchase plates separately.

BH-25 LR

Head comes with B2-40 LR quick-release clamp

secured with ¼”-20 flat head screw. Clamp

accepts all Really Right Stuff quick-release plates.

Purchase plates separately.

GUARANTEE

ALL REALLY RIGHT STUFF BRAND PRODUCTS ARE

GUARANTEED TO THE ORIGINAL PURCHASER TO BE FREE

OF DEFECTS IN MATERIALS OR WORKMANSHIP FOR FIVE

(5) YEARS FROM THE DATE OF PURCHASE. PRODUCTS

WILL BE REPAIRED OR REPLACED AT OUR OPTION.

MAINTENANCE

General Care

The BH-25 is finished with a protective anodize plating that protects

the aluminum from corrosion and mild abrasion. It will not protect it

from scraping against or dropping on rocks/concrete/etc.

Cleaning

Take precautions to prevent your BH-25 from getting fouled in mud, dirt,

or sand. If the BH-25 is fouled, dry dust and dirt can be blown off and/

or wiped off with a soft cloth. Mud or salt water should be lightly rinsed

off with fresh water and then thoroughly dried. If fine sand/grit fouls

the knob, simply run a gentle stream of water around the knob while

rotating it one-half turn back and forth. Do NOT submerge the ballhead

and do not direct a high-pressure stream of water at it.

INSTALL TO TRIPOD

1. Tighten the Main Lock T-Lever to lock the Panning Base.

2. Screw the ballhead onto the 3/8”-16 threaded stud on

the top of the tripod (stud should not protrude more than

3/8” above platform or 5-6 threads). Tighten the ballhead

onto the tripod snugly, but do not over-torque or it will be

difficult to remove.

USING THE MAIN LOCK T-LEVER

The Main Lock T-Lever is longer on

one end. This design makes it easy

to turn the lever and apply enough

pressure to solidly lock the head. In

some instances, though, the long

end of the lever may hit the tripod

platform or even the clamp. That’s

why we made the main lock T-Lever

spring loaded and re-positionable:







1. Pull the T-Lever out.

2. Rotate T-Lever to a new

position. The T-Lever actually

drives an internal six-sided

hex nut, so there are 6

possible positions for the

T-Lever.

3. Allow T-Lever to snap into

place.
