RME ADI-648 MKII Manual

RME Audio/video konverter ADI-648 MKII

Læs gratis den danske manual til RME ADI-648 MKII (32 sider) i kategorien Audio/video konverter. Denne vejledning er vurderet som hjælpsom af 8 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 4.5 anmeldelser. Har du et spørgsmål om RME ADI-648 MKII, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/32

User's Guide

ADI-648

Multichannel Audio Digital Interface

SyncAlign

SyncCheck

Intelligent Clock Control

SteadyClock

Hi-Precision 24 Bit / 192 kHz

64 Channel MADI / ADAT Converter

16 x 16 Matrix Router

MIDI embedded in MADI

Firmware 2.5

MADI

24 Bit Interface

User's Guide ADI-648 © RME

Important Safety Instructions ........................................................................... 3

1 Introduction ........................................................................................................ 5

2 Package Contents .............................................................................................. 5

3 Brief Description and Characteristics .............................................................. 5

4 Technical Specifications

4.1 Inputs ............................................................................................................... 6

4.2 Outputs ............................................................................................................ 7

5 First Usage

5.1 Quick Start ...................................................................................................... 8

5.2 Firmware ......................................................................................................... 8

5.3 Operating the ADI-648 .................................................................................... 9

6 The MADI to ADAT Converter

6.1 General .......................................................................................................... 10

6.2 Inputs ............................................................................................................. 10

6.3 Input State Display ........................................................................................ 10

6.4 Outputs ADAT Optical ................................................................................... 11

7 The ADAT to MADI Converter

7.1 General .......................................................................................................... 12

7.2 Inputs ............................................................................................................. 12

7.3 Input State Display ........................................................................................ 12

7.4 Outputs MADI ................................................................................................ 13

8 Clock Section

8.1 Clock Configuration ....................................................................................... 13

8.2 Lock and SyncCheck .................................................................................... 14

8.3 Word Clock Input and Output ........................................................................ 15

9 Word Clock

9.1 Operation and Technical Background ........................................................... 16

9.2 Cabling and Termination ............................................................................... 17

10 MIDI

10.1 Transmission of MIDI .................................................................................. 18

10.2 Remote Controlling the ADI-648 ................................................................. 18

10.3 Remote Control Software ........................................................................... 19

11 Special Modes

11.1 MADI to MADI Converter ............................................................................ 21

11.2 ADAT Patchbay and Splitter ....................................................................... 21

11.3 MADI Coaxial/Optical Converter ................................................................. 21

11.4 MADI Merger .............................................................................................. 22

11.5 MADInet ...................................................................................................... 22

12 Technical Background

12.1 DS – Double Speed .................................................................................... 23

12.2 QS – Quad Speed ...................................................................................... 23

12.3 MADI Basics ............................................................................................... 24

12.4 SteadyClock ................................................................................................ 25

13 Controls and Connectors ................................................................................ 26

14 Block Diagram .................................................................................................. 27

15 MIDI Implementation Chart

15.1 Basic SysEx Format ................................................................................... 28

15.2 Message Types .......................................................................................... 28

15.3 MADI Input State – Redundancy Mode ...................................................... 28

16 Warranty ............................................................................................................ 31

17 Appendix ........................................................................................................... 31
