Side 1/2
Features
USB Type-C Male (Connect to host computer)
• Supports DP1.4 Alt mode
• Supports DSC 3:1
HDMI
• Support HDMI max 4K/60Hz，8bit with
max 18Gbps
• Support RGB, YCbCr 4:4:4 ,4:2:2 ,4:2:0,
• Support 8bit/10bit deep color
• Support HDR
• Support HDCP2.2&1.4
Note: To achieve max 4K/60Hz, it requires
the host PC supports DP1.4 Alt mode; if
the host supports DP1.2 Alt mode, the
max resolution of HDMI is 4k/30Hz due
to bandwidth limitation
Introduction
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the Packaging:
• Main Unit x1
• User Manual x1
Rocstor introduces the Type-C 5-in-1 Adapter, featuring HDMI, 3 USB-A ports, and an
RJ45 port, oering an ideal solution for expanding the port options of Type-C or
Thunderbolt hosts (PC/Laptop/Mobile phone, etc.), especially benecial for those with
a single Type-C port. Equipped with the latest DP1.4 Alt mode supported IC, this
adapter enables HDMI video output at a maximum resolution of 4k/60Hz while
simultaneously transferring USB 3.1 data at a maximum speed of 5Gbps. Additionally,
the Gigabit Ethernet port provides the host computer with access to super-fast
networks. Compatible with all DP Alt mode supported Type-C hosts, this adapter
ensures seamless compatibility and enhanced functionality.
USB-A Female X3
• Compliant with USB3.2 Gen1 with max
5Gbps data transmission, downward
compatible with lower versions
• Max 900mA downstream charging per
port ( the actual downstream charging
power depends on the charging ability of
the host)
Note: To guarantee that 3 USB-A achieve
optimal performance,it is suggested not
to connect 2 or 3 high-power devices like
hard drive
Upstream:
Downstream:
RJ45 (Gigabit Ethernet）
• Supports Gigabit
Ethernet,10M/100M/1000M
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no
light when no Internet connected,
orange light turns on when network
connection is established, green light
ashes when transmitting data.
Specication
Input / Output Connector
Input
Output HDMI x1
USB-A x3
RJ45 x1
Type-C Male x1
Limited Warranty
Warranty
3 Years
Size (LxWxH)
Physical
4.5x0.9x0.6in (114.5x22.8x16.8mm)
Weight 1.76lbs (40g)
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
0°C to + 45°C
10% to 90 % RH (no condensation)
-10°C to + 70°C
10% to 90 % RH (no condensation)
Regulatory Approvals
Certications FCC, CE
Accessories
User Manual English Version
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Type-C to HDMI(4K/60Hz）/USB-AX3/
RJ45 with DP1.4 Alt mode
User Manual
Y10A312-S1
Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: +1 (818) 727-7000
( )National and international
Fax: +1 (818) 875-0002
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Connection Diagram
Safety Information:
Email: support@rocstor.com
WARNING:
Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the device adapter becomes very warm during use.
Please note that:
Continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the device and use care when handling it. Avoid instances where your skin is in extended contact
with the device when plugged into the host computer. It is not recommended to sleep with the
device when plugged into a host computer. Avoid placing the device under a pillow, blanket, or your
body when connected to a host computer. If you have a medical condition that aects your ability to
detect heat against the body, extra care should be used. Never use the device in locations with water,
such as a sink, bathtub, or shower stall. Never connect or disconnect the device with wet hands.
Limitation of Liability
In no event shall the liability of Rocstor, Inc. and Rocstor (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (3) three-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
!
©2024 Rocstor, Inc. All rights reserved. Rocstor is registered trademark of Rocstor, Inc.
Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,
iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are
registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al
other product names and logos mentioned herein may be trademarks of their respective companies.
Thunderbolt is a trademark of Intel Corporation or its subsidiaries. USB Type-C® and USB-C® are
registered trademark of USB Implementers Forum. The terms HDMI, HDMI High-Denition
Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc. Feature and specication are subject to change without notice.
All trademarks and registered trademarks are the property of their respective. All rights reserved.
USB Devices
Ethernet Source
HDMI Display
4K @ 60Hz
Host Computer with
USB Type-C
