Description
The UEX3D-WP-EU is a USB Device solution utilises HDBaseT™
technology to allow for remote connectivity to a USB 3.2 Gen1 Host
at distances of up to 100m over a single CAT6A cable in a dual EU /
UK wall plate format.
The UEX3D-WP-EU allows for 4 x USB Devices (2 x USB type A,
and 2 x USB-C) to be connected to a compatible Blustream USB
HDBaseT Receiver (Host) extender with support for a combined
transmission data bandwidth of up to 5Gbps.
The UEX3D-WP-EU is backwards compatible with USB 2.0 and 1.1
devices, and utilises bi-directional Power over Cable (PoC) to power
from either end of the HDBaseT link. The UEX3D-WP-EU is ideal
for applications requiring extension of USB 3.2 Gen1 conferencing
cameras, video capture devices, ash/hard drives, KVM devices,
audio devices and other USB 3.2 Gen1 devices.
* Requires compatible Blustream USB 3.2 HDBaseT Host product
UEX3D-WP-EU
136mm
USB 3.2 Gen1 HDBaseT™ Extender - Device
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.
86mm
Key Features
•
USB 3.2 Gen1 HDBaseT Extender supporting 2 x USB-C and 2 x
USB-B ports for connection to USB devices
• Supports USB 3.2 signal extension up to 100m over HDBaseT *
• Backwards compatible with USB 2.0 & 1.1 devices
• Combined USB3.2 Gen1 data transfer rate up to 5Gbps *
• Provides up to 3A combined power to USB devices (up to 1.7A per
single USB port)
• Congurable USB device power management via API commands
• Bi-directional PoC (Power over Cable) to power extenders from
either the host or device unit (supports 12-48V PoC)
• Supports bi-directional RS-232 when used with compatible
HDBaseT™ products
• PoC function can be enabled/disabled via dipswitch
• Simple plug and play, no driver installation or setup required
* Signal distribution bandwidth and distance are subject to length of device and
host USB cables, and CAT cable type. It is recommended to use a minimum of
CAT6A cabling.
Compatible with Blustream UEX3H and UEX3H-WP
Please note: This USB HDBaseT Extender product is not compatible with ‘DP Alt
Mode’ signals
