Features
DisplayPort (Female)
Rocstor introduces the DisplayPort 1.4 repeater, oering users a convenient means to
extend DP signals from a host PC to a monitor or projector, reaching up to 20 meters
(10 meters in and 10 meters out), supporting resolutions of up to max 8K/30Hz
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual x1
• USB-A to Micro USB M/M Cable 1m x1
DisplayPort (Female)
• Support DP1.4 and downward
compatible with lower versions
• Transmission speed：1.62 Gbps / 2.7
Gbps / 5.4Gbps / 8.1 Gbps
• Support DisplayPort 1.4 HBR3 with max
video resolution 8K@30Hz.
• Extending Distance: max 20m (10m input,
10m output) with 28AWG or above cable
• Support cascading function up to 3 levels
Note: 1) To achieve 8K transmission, the
source and display should support DP1.4,
the connected cable should be 28AWG or
above DP1.4 cable
2) When using the cascading function to
achieve longer distance, the max
resolution will be decreased
3) The repeater is not bidirectional, so
make sure to connect the source to the
input port and display to the output port
Upstream:
Downstream:
Package Contents
Specication
Input
Output DisplayPort Female
DisplayPort Female
Maximum Resolution
Supported DP Version DP1.4/DP1.2
7680*4320@30Hz
Bandwidth 1.62 / 2.7 / 5.4 / 8.1 Gbps
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
0°C to 45°C (32°F to 113°F)
5% to 90 % RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 85% RH (no condensation)
Introduction
Environmental
Signal Inputs/Output
Converter Unit FCC, CE
Regulatory Approvals
User Manual English Version
Accessory Adapter
Operating Temperature
Power Requirement
Micro USBExternal Power Supply
1W（5V/200mA）Power Consumption
®
TrueReach 8K/4K DisplayPort 1.4 Extender Repeater
Max 65ft (20m)
User Manual
Y10A328-B1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
