Package Contents
Introduction
Rocstor introduces the most powerful Thunderbolt™ 4 dock, oering an advanced, ecient, and
versatile I/O solution with speeds of up to 40Gb/s for data and video transmission. The Thunderbolt 4
port enables cascading Thunderbolt devices up to 6 levels, supporting one 8K monitor or two
4K/60Hz monitors. Additionally, it allows for connecting three displays simultaneously, achieving
triple displays output (max 4K/60Hz*2 + 4K/30Hz) with distinct images when paired with TBT4/USB4
Windows PCs. The RJ45 port supports a maximum bandwidth of 2.5G, while the USB ports facilitate
rapid 10G data transmission. The Type-C PD port supports either max 10G data transmission or
mobile phone charging at up to 30W. Furthermore, it features a smart power function that optimally
distributes power based on connected device consumption, maximizing the use of external power
supply. Designed for TBT4/USB4-based PCs, it's also compatible with TBT3/DP-Alt-mode PCs.
WARNING:
Please follow these safety instructions. Failure to do so may result damages or injury. It is normal that
the device becomes very warm during use.
Please note that:
Continuous contact with warm surfaces for extended time may cause discomfort or injury. In order
to reduce the possibility of overheating or heat-related injuries, always allow needed ventilation
around the device and use care when handling it. Avoid instances where your skin is in extended
contact with the device when plugged into the host computer. It is not recommended to sleep with
the device when plugged into a host computer. Avoid placing the device under a pillow, blanket, or
your body when connected to a host computer. If you have a medical condition that aects your
ability to detect heat against the body, extra care should be used. Never use the device in locations with
water, such as a sink, bathtub, or shower stall. Never connect or disconnect the device with wet hands.
Before utilizing this unit, kindly inspect the packaging to ensure the following items are included:
• Main Unit x1
• User Manual x1
• 150W DC Power Adapter x1
• Thunderbolt 4 M/M Cable p2-x1 (optional)
