Side 1/6

MIDI Implementation

Model: TB-3

Date: Jul. 04, 2014

Version: 1.10

1. Receive data

9System Exclusive Message

Status Data byte Status

F0H iiH, ddH, ......,eeH F7H

F0H: System Exclusive Message status

ii = ID number: An ID number (manufacturer ID) to indicate the manufacturer

whose Exclusive message this is. Roland’s manufacturer ID is

41H.

ID numbers 7EH and 7FH are extensions of the MIDI standard;

Universal Non-realtime Messages (7EH) and Universal Realtime

Messages (7FH).

dd,...,ee = data: 00H - 7FH (0 - 127)

F7H: EOX (End Of Exclusive)

Of the System Exclusive messages received by this device, the Universal Non-

realtime messages and the Universal Realtime messages and the Data Request (RQ1)

messages and the Data Set (DT1) messages will be set automatically.

Universal Non-realtime System Exclusive Messages

6Identity Request Message

Status Data byte Status

F0H 7EH, dev, 06H, 01H F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H, 7FH)

06H Sub ID#1 (General Information)

01H Sub ID#2 (Identity Request)

F7H EOX (End Of Exclusive)

* When this message is received, Identity Reply message will be transmitted.

7Data Transmission

This instrument can use exclusive messages to exchange many varieties of internal

settings with other devices.

The model ID of the exclusive messages used by this instrument is 00H 00H 7BH.

6Data Request 1 RQ1 (11H)

This message requests the other device to transmit data. The address and size

indicate the type and amount of data that is requested.

When a Data Request message is received, if the device is in a state in which it is able

to transmit data, and if the address and size are appropriate, the requested data is

transmitted as a Data Set 1 (DT1) message. If the conditions are not met, nothing is

transmitted.

Status Data byte Status

F0H 41H, dev, 00H, 00H, 7BH, 11H, aaH, bbH, F7H

ccH, ddH, ssH, ttH, uuH, vvH, sum

Byte Remarks

F0H Exclusive status

41H ID number (Roland)

dev device ID (dev: 10H, 7FH)

00H model ID #1 (TB-3)

00H model ID #2 (TB-3)

7BH model ID #3 (TB-3)

11H command ID (RQ1)

aaH address MSB

bbH address

ccH address

ddH address LSB

ssH size MSB

ttH size

uuH size

vvH size LSB

sum checksum

F7H EOX (End Of Exclusive)

* The size of data that can be transmitted at one time is xed for each type of data.

And data requests must be made with a xed starting address and size. Refer to the

address and size given in “Parameter Address Map”.

Data set 1 DT1 (12H)

Status Data byte Status

F0H 41H, dev, 00H, 00H, 7BH, 12H, aaH, bbH, F7H

ccH, ddH, eeH, ... H, sum

Byte Explanation

F0H Exclusive status

41H ID number (Roland)

dev Device ID (dev: 10H, 7FH)

00H Model ID #1 (TB-3)

00H Model ID #2 (TB-3)

7BH Model ID #3 (TB-3)

12H Command ID (DT1)

aaH Address MSB: upper byte of the starting address of the data to

be sent

bbH Address: upper middle byte of the starting address of the data

to be sent

ccH Address: lower middle byte of the starting address of the data

to be sent

ddH Address LSB: lower byte of the starting address of the data to be

sent.

eeH Data: the actual data to be sent. Multiple bytes of data are

transmitted in order starting from the address.

: :

H Data

sum Checksum

F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of

data, and data will be transmitted from the specied starting address and size.

Refer to the address and size given in “Parameter Address Map”.

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and

each packet will be sent at an interval of about 20 ms.

MIDI Implementation

2. Data Transmission

9System Exclusive Message

Status Data byte Status

F0H iiH, ddH, ......, eeH F7H

F0H: System Exclusive Message status

ii = ID number: An ID number (manufacturer ID) to indicate the manufacturer

whose Exclusive message this is. Roland’s manufacturer ID

is 41H. ID numbers 7EH and 7FH are extensions of the MIDI

standard; Universal Non-realtime Messages (7EH) and Universal

Realtime Messages (7FH).

dd, ..., ee = data: 00H–7FH (0–127)

F7H: EOX (End Of Exclusive)

Universal Non-realtime System Exclusive Messages and Data Set 1 (DT1) are the only

System Exclusive messages transmitted by the SH-01.

Universal Non-realtime System Exclusive Message

6Identity Reply Message (TB-3)

Receiving Identity Request Message, the TB-3 send this message.

Status Data byte Status

F0H 7EH, dev, 06H, 02H, 41H, 41H, 02H, F7H

00H, 00H, 00H, 03H, 00H, 00H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H)

06H Sub ID#1 (General Information)

02H Sub ID#2 (Identity Reply)

41H ID number (Roland)

7BH 02H Device family code

00H 00H Device family number code

00H 03H 01H 00H Software revision level

F7H EOX (End of Exclusive)

7Data Transmission

6Data set 1 DT1 (12H)

Status Data byte Status

F0H 41H, dev, 00H, 00H, 7BH, 12H, aaH, bbH, F7H

ccH, ddH, eeH, ... H, sum

Byte Explanation

F0H Exclusive status

41H ID number (Roland)

dev Device ID (dev: 10H)

00H Model ID #1 (TB-3)

00H Model ID #2 (TB-3)

7BH Model ID #3 (TB-3)

12H Command ID (DT1)

aaH Address MSB: upper byte of the starting address of the

data to be sent

bbH Address: upper middle byte of the starting address

of the data to be sent

ccH Address: lower middle byte of the starting address

of the data to be sent

ddH Address LSB: lower byte of the starting address of the

data to be sent.

eeH Data: the actual data to be sent. Multiple bytes

of data are transmitted in order starting

from the address.

: :

H Data

sum Checksum

F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of

data, and data will be transmitted from the specied starting address and size.

Refer to the address and size given in “Parameter Address Map”.

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and

each packet will be sent at an interval of about 20 ms.

3. Parameter Address Map

* Transmission of “#” marked address is divided to some packets. For example, ABH in

hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this

order.

* “<*1>” marked address or parameters are ignored when the TB-3 received them.

* “<*2>” marked address or parameters are not supporting RQ1.

TB-3 (Model ID = 00H 00H 7BH)

Controller

+-------------------------------------------------------------------------------+

| Address | Description |

|--------------+----------------------------------------------------------------|

|# 00 10 00 00 | 0000 aaaa | CUTOFF (CC# 74) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 02 | 0000 aaaa | RESONANCE (CC# 71) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 04 | 0000 aaaa | ACCENT (CC# 16) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 06 | 0000 aaaa | EFFECT (CC# 17) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 08 | 0000 aaaa | ENV MOD X (CC# 12) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 0A | 0000 aaaa | ENV MOD Y (CC# 13) <*2> (0 - 255) |

| | 0000 bbbb | |

|# 0C | 0000 aaaa | TUNING (CC# 104) <*2> (0 - 255) |

| | 0000 bbbb | |

|--------------+----------------------------------------------------------------|

| 00 00 00 0E | Total Size |

+-------------------------------------------------------------------------------+

Patch

+-------------------------------------------------------------------------------+

| Address | Description |

|--------------+----------------------------------------------------------------|

| 00 20 00 00 | 0000 000a | SW SAW (0 - 1) |

| | | OFF, ON |

| 01 | 0aaa aaaa | MIXER SAW (0 - 127) |

| 02 | 0000 000a | SW SQR (0 - 1) |

| | | OFF, ON |

| 03 | 0aaa aaaa | MIXER SQR (0 - 127) |

| 04 | 0000 000a | SW WHITE NOISE (0 - 1) |

| | | OFF, ON |

| 05 | 0aaa aaaa | MIXER WHITE NOISE (0 - 127) |

| 06 | 0000 000a | SW PINK NOISE (0 - 1) |

| | | OFF, ON |

| 07 | 0aaa aaaa | MIXER PINK NOISE (0 - 127) |

| 08 | 0aaa aaaa | (reserve) <*1> |

| : | | |

| 0F | 0aaa aaaa | (reserve) <*1> |

| 10 | 0aaa aaaa | DECAY (0 - 127) |

| 11 | 0aaa aaaa | (reserve) <*1> |

| : | | |

| 1F | 0aaa aaaa | (reserve) <*1> |

| 20 | 0aaa aaaa | VOLUME (0 - 127) |

|--------------+----------------------------------------------------------------|

| 00 00 00 21 | Total Size |

+-------------------------------------------------------------------------------+

Patch Distortion

+-------------------------------------------------------------------------------+

| Address | Description |

|--------------+----------------------------------------------------------------|

| 00 20 10 00 | 0000 000a | DISTORTION SW (0 - 1) |

| | | OFF, ON |

| 01 | 000a aaaa | TYPE (0 - 24) |

| | | 0 Mid Boost, 1 Clean Boost, 2 Treble Bst, |

| | | 3 Blues OD, 4 Crunch, 5 Natural OD, |

| | | 6 OD-1, 7 T-Scream, 8 Turbo OD, |

| | | 9 Warm OD, 10 Distortion, 11 Mild DS, |

| | | 12 Mid DS, 13 RAT, 14 GUV DS, |

| | | 15 DST+, 16 Modern DS, 17 Solid DS, |

| | | 18 Stack, 19 Loud, 20 Metal Zone, |

| | | 21 Lead, 22 ‘60s FUZZ, 23 Oct FUZZ, |

| | | 24 MUFF FUZZ |

| 02 | 0aaa aaaa | DRIVE (0 - 120) |

| 03 | 0aaa aaaa | BOTTOM (0 - 100) |

| | | -50 - +50 |

| 04 | 0aaa aaaa | TONE (0 - 100) |

| | | -50 - +50 |

| 05 | 0aaa aaaa | EFFECT LEVEL (0 - 100) |

| 06 | 0aaa aaaa | DRY LEVEL (0 - 100) |

|--------------+----------------------------------------------------------------|

| 00 00 00 07 | Total Size |

+-------------------------------------------------------------------------------+

Patch EFX1

+-------------------------------------------------------------------------------+

| Address | Description |

|--------------+----------------------------------------------------------------|

| 00 20 20 00 | 0000 aaaa | EFX1 TYPE (0 - 10) |

| | | BYPASS, CS, RM, BC, TR, CH, FL, PH, DD, PS, EQ |

| 01 | 0aaa aaaa | (reserve) <*1> |

| | | |

|# 02 | 0000 aaaa | PARAMETER 1 (0 - 255) |

| | 0000 bbbb | |

|# 04 | 0000 aaaa | PARAMETER 2 (0 - 255) |

| | 0000 bbbb | |

|# 06 | 0000 aaaa | PARAMETER 3 (0 - 255) |

| | 0000 bbbb | |

|# 08 | 0000 aaaa | PARAMETER 4 (0 - 255) |

| | 0000 bbbb | |

|# 0A | 0000 aaaa | PARAMETER 5 (0 - 255) |

| | 0000 bbbb | |
