RS81B Quartz PLL Synthesized AM/FM Tuner.
Quick Start Guide
ROLLS CORPORATION
SALT LAKE CITY, UTAH
10/15
www.rolls.com
SERIAL NUMBER
LINE LEVEL XLR OUTPUTS
RS81B
Quartz PLL Synthesized AM/FM RDS Tuner
AM
LOOP ANT
FM ANT
75 L
R
OUTPUT
RIGHT LEFT
MODEL RS81B
www.rolls.com
WARNING: DO NOT EX POSE THIS EQUIPMENT TO RAI N O R MOISTURE.
RISQUE DE CHOC - NE P AS ENLIVER
FUSE T1A 250V
DC 24V
HEADPHONE
HEADPHONE
OUTPUT
CAUTION: TO REDU CE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CA UTI ON
RIS K OF ELEC TRIC
SHOC K D O NOT OPEN
MADE IN TAIWAN
DIRECT
TUNING
M3 / 3 M4 / 4M1 / 1 M2 / 2
M6 M7 / 6 / 7 M8 M9 M10 / 8 / 9 / 10
M5 / 5
0
TA PTY MO / ST MEM. UP BAND
DISP AF DN UPMEMORY SLEEP
+_
POWER INPUT
110-120V 60Hz 45W
220-240V 50Hz 45W
SIGNAL
STRENGHT
Specs:
FM SECTION
Tuning Range: 87.5-108MHz
3 dB Limiting: 12dB
Image Rejection: 53dB
Usable sensitivity mono IHF: 9dB
Selectivity: (-70KHz : +90KHz)
S/N Ratio at 1 mV Mono: 52dB
Stereo: 50dB
THD at 1 mV 40 kHz deviation: 0.18%
Stereo Separation: 28dB
Auto Scan Sensitivity: 23dB
AM Suppression Mod: 52dB
Antenna Input Impedance: 75 Ohms
AM SECTION
Tuning Range: 530 - 1710 kHz (10 kHz increm.)
522 - 1611 kHz (9 kHz increm.)
IF Frequency: 450KHz
Usable Sensitivity: 28dB
Auto Scan Sensitivity: 41dB
S/N Ratio at 5 mV/M: 46dB
6 dB Bandwidth: 7KHz
Image Rejection: 42dB
A.C.A. +/- 9 kHz: 46dB
AGC Action: 43dB
THD at 5mV/M: 0.40%
Antenna Input Impedance: 300 Ohms
Size: 19” x 1.75” x 7”
(48.3 x 4.5 x 12 cm)
Weight: 7.1 lbs. (3.2 kg)
FRONT PANEL DESCRIPTION
www.rolls.com
RS81B
Quartz PLL Synthesized AM/FM RDS Tuner
HEADPHONE
HEADPHONE
OUTPUT
DIRECT
TUNING
M3 / 3 M4 / 4M1 / 1 M2 / 2
M6 M7 / 6 / 7 M8 M9 M10 / 8 / 9 / 10
M5 / 5
0
TA PTY MO / ST MEM. UP BAND
DISP AF DN UPMEMORY SLEEP
SIGNAL
STRENGHT
- MEM. UP: Increments up Presets. If the tuner is stepped beyond the
highest number preset stored, it will “wrap around” and step back to the
lowest numbered preset.
- BAND: Switch for AM or FM (FM 1 / FM 2 / AM)
- Tuning + / - : Increases or Decreases the tuner frequency each time it is
pressed. Press in for 2 seconds for automatic scan searching. After a sta-
tion is received, it will stop automatically and start to play.
- MO/ST: Selects between Stereo and Mono operation (FM mode only).
- DISP: Displays the current RDS information (if available) from the cur-
rent station.
-DIRECT: Press to directly select a radio frequency. For example, to di-
rectly select station107.7, simply press “DIRECT” + number “1077”.
-Headphone Level: Adjusts the signal level of the Headphone Out.
-Headphone Out: 1/8” Tip-Ring-Sleeve stereo jack for connection to ste-
reo headphones. The use of MONO jacks will permanently damage the
RS81B. Make sure you are using a stereo jack.
-Power Switch: Applies power to the RS81B.
- SIGNAL STRENGTH: This is a general signal strength meter. It is not cali-
brated to a specic level. It will indicate the general strength of a signal
coming into the RS81B. Remote Description:
-BAND: Switch for AM or FM
-Press “ BAND ” to select FM 1,FM 2, or AM frequencies.
-Press “TUN+ / TUN-” to select stations. Press and hold for over 2 seconds
enters into automatic scan searching. After a station is received, it will
stop automatically and start to play the station.
-DIRECT: Press to directly select a radio frequency. For example, to di-
rectly select station107.7, simply press “DIRECT” + number “1077”.
-Remote buttons work the same as front panel buttons, refer to the sec-
tion of the manual with the description of the front panel.
REMOTE
Remote Operation:
The included Infrared Remote provides a way to control the RS81B at a
distance from the unit. It must be located in the “line-of-sight”.
Radio Memory Function
-The 30 Radio presets are in 3 sections: FM 1 x 10 / FM 2 x 10 / AM x 10
-First select the channel which wants to be stored
-Press “ MEMORY “
-Press “1 ~ 10” To select the channel number for preset memory.
-Press “ MEMORY “ again to conrm the memory. LCD shows “CH1 ~ 10”.
-Repeat above steps to store more channels. Up to 10 channels can be
stored per section.
