Side 1/6

Montage- und Gebrauchsanweisung

Instruction on mounting and use

Instructions de montage et mode d’emploi

Montagevoorschriften en gebruiksaanwiizing

AIR - 1AFLIDUFN - 310505

Hood Description - Fig. 1

1) Control panel

2) Metal grease filter

3) Worktop illumination

Use: Two systems are available

Exhaust mode (S)

Vapours are extracted outside through an

exhausting pipe that is affixed to the con-

nection ring above the hood.

Diameter of the exhausting pipe must be

equal to that of the connection ring.

In the horizontal runs the duct must be

slightly slanted (about 10 ) and directed°

upwards to vent the air easily from the room

to the outside.

Attention!

If the hood is supplied with carbon filter

then it must be removed.

Filter version (K)

The air is filtered through a carbon filter

(for its installation see paragraph “Car-

bon filter”) and recirculated into the room

through the grating on the lower side of the

chimney.

Attention!

If the hood is not supplied with carbon

filter, then it must be ordered and

mounted.

This version is used when there is no ex-

haust duct for venting outdoors or when it

is impossible to install one.

Installation

When installed, the distance between ex-

tractor and hob gas burners or electric plates

must be not less than 65 cm providing the

total hob output does not exceed 11kw.

For each kw in addiction, the distance be-

tween extractor and hob gas burners must

be increased of 10 cm.

Electric connection

Before completing any connection make sure

the house voltage corresponds with the

voltage indicated on the label affixed inside

the hood.

It is advisable to call a qualified technician to

make the electrical connection.

Appliance fitted with plug

Connect it to a socket which conforms with

current regulations.

If you intend to connect it directly to the elec-

tric mains, remove the plug and fit an ap-

proved bipolar switch with a minimum con-

tact opening of no less than 3mm.

If the plug is not accessible once it has been

inserted in the socket, it will however be nec-

essary to fit an approved bipolar switch with

a minimum contact opening of no less than

3mm.

Appliance without plug

Fit an approved plug or an approved bipolar

switch with a minimum contact opening of

not less than 3mm.

The manufacturer is not liable for any

problems caused by the user’s failure to

observer the above instructions.

Fastening of shelves (optional)

Fasten the four side supports to theI

adjacent cabinets and place the shelf on

the supports (Fig. 4).

Using the hood

–The hood is provided with a motor with

several speeds For the best performan-

ce, we recommend using the low speeds

in normal conditions and the high speeds

in particular cases of strong odour and

vapour concentration.

–We recommend starting up the hood a

few minutes before cooking and keeping

it running until all the odours have been

eliminated.

Warning!

–The hood cannot be connected to flues

of other appliances that run on energy

sources other than electricity.

–When the hood is used at the same time

of other appliances that run on energy

sources other than electricity, provision

must be made for an adequate air supply.

–No food must be cooked flambé under-

neath the hood.

The use of an unprotected flame is dan-

gerous for the filters and could cause fires.

Therefore, never use an open flame under

the hood. When frying foods, never leave

the pan alone because the cooking oil

could flare up.

–Please, keep to the provisions of official

directives regarding the question of fume

discharge.

–The manufacturer refuses to accept any

responsibility for damage to the hood or

its catching on fire because of failure to

observe the above instructions.

Maintenance

Before performing any maintenance opera-

tion, isolate the hood from the electrical

supply by switching off at the connector and

removing the connector fuse.

Or if the appliance has been connected

through a plug and socket, then the plug

must be removed from the socket.

Metal grease filter (2 or 3 pieces)

The metal grease filter lasts forever and

must be washed either by hand or in the

dishwasher (65 C)° with suitable detergents.

The grease fiilters must be washed at

least once a month.

Remove the filter using the handles desi-

gned for this purpose by pulling the filter

backwards and then downwards (Fig. 2).

Let the filter dry without damaging it before

putting it back into place.

Carry out the above steps in reverse orde, to

put the filters back after having washed them.

Carbon filter (2 pieces)

This filter dissolves cooking odours.

The carbon filter must never be washed.

It should be changed every 4 months with

normal use.

Mounting and replacing the carbon filter:

a) Disconnect the hood from the electricity.

b) Remove the metal grease filters (Fig. 2).

c) If the filters have not been installed, place

one filter on each side so that they cover

the grates protecting the rotor on the

motor. Then turn the center handle for the

filters in the clockwise direction (Fig. 3).

d) If the charcoal filters have already been

installed (covering the grates protecting

the rotor on the motor) and must be

replaced, turn the central handle in the

counter-clockwise direction until the filters

are unlocked.

e) Refit the the metal grease filters.

Cleaning

To clean the outside of the hood use a cloth

moistened with denatured alcohol or neutral

liquid detergents. Never use products con-

taining abrasive.

Wipe brushed stainless steel in the same

direction as the brushing to avoid scratching.

Attention

Failure to observe the rules for cleaning the

appliance and changing and cleaning the

filters can cause fires.

Therefore, we recommend observing these

instructions.

Replacing the lamp

a) Disconnect the hood from the electricity.

b) Remove the grease filters (Fig. 2).

c) Illumination: always replace burnt-out

lamps with 40 Watt max. (E14) (Fig. 5) -

20 Watt max. (Fig. 6) and 11 Watt max.

(Fig. 7).

d) Refit the the metal grease filters.

e) Before calling for repair service because

the hood fails to light up, make sure the

bulbs are screwed in tightly.

GB GB

6 7
