HTP-7.2

Home Theater Wallplate

Installation Manual

Overview

The Home Theater Plate (HTP-7.2) is a double-gang in-wall connection plate

designed to allow easy hookup of all the speakers in a 5.1, 6.1 or 7.1-channel

surround sound system. It includes terminals for up to seven speakers, and

two powered/active (low level) subwoofers. Its Decora design allows for

each half to be used independently if desired, for two single-gang plates,

one with 4 pairs of stereo binding posts and one with 3 pairs and a pair of

RCA jacks. The heavy-duty plates support the weight of high-quality wires,

and each connection is clearly labeled. The 7/16” gold-plated binding posts

make for easy and secure connections, and the captured posts won’t turn

while they are being tightened. The 5-way binding posts have gold plating

to resist corrosion and can accept the following: bare or tinned wire up to

12 gauge in thickness, pins, spade lugs, and single or double banana plugs.

The powered subwoofer connections use high quality RCA connectors. Be

sure to use only those connectors that are approved for audio or low voltage

use in your area.

Wiring Instructions

Be sure to use adequate gauge wires, depending upon the length of each

wire. Consult the following table for general recommendations or contact

your installer or speaker manufacturer.

Length Minimum Gauge

10 to 100 ft. 16

100 to 200 ft. 14

Over 200 ft. 12

Leave enough excess wire so as not to put too much tension on any

connections, as this can lead to loosened or inconsistent terminations. Keep

speaker wires and RCA cables away from AC wiring. If these wires must

occupy the same area, keep them as far apart as possible and have them

cross at right angles when crossing is necessary.

Russound, Inc. 1 Forbes Rd., Newmarket, NH 03857, USA

tel 603.659.5170 • fax 603.659.5388 www.russound.com

technical support: 866.888.7466 e-mail: tech@russound.com

respective owners. Russound is not responsible for typographical errors or omissions.

Specications are subject to change without notice.

Limited Warranty

The Russound HTP-7.2 is guaranteed for two (2) years from the date of purchase against

all defects in materials and workmanship. During this period Russound will replace any

defective parts and correct any defect in workmanship without charge for either parts

or labor. For this warranty to apply, the unit must be installed and used according

to its written instructions. If service is necessary, it must be performed by Russound.

Russound assumes no responsibility for defects resulting from abuse or servicing

performed by an agency or person not specically authorized in writing by Russound.

Damage to or destruction of components due to improper use voids the warranty. In

these cases the repair will be made at the owner’s expense. Accidental damage and

shipping damage are not considered defects under the terms of the warranty. To return

for repairs, the unit must be shipped to Russound at the owner’s expense, along with a

Return Authorization number and documentation explaining the nature of the service

required. Any product returned without prior written permission will be returned to

sender. Russound sells products only through authorized Dealers and Distributors

to ensure that customers obtain proper support and service. Any Russound product

purchased from an unauthorized dealer or other source, including retailers, mail order

sellers and online sellers will not be honored or serviced under existing Russound

warranty policy. Any sale of products by an unauthorized source or other manner not

authorized by Russound shall void the warranty on the applicable product.

Specications

Dimensions: 4.8W x 4.8H x 1.1D inches (12.2 x 12.2 x 2.8 cm)

Weight: 10.5 oz. (298 g)

Connectors: (14) 5-way binding posts

(2) RCA connectors

Plate Connections

1. When making any connections, make sure all the equipment is turned

o and unplugged.

2. When inserting any wires or connectors, be sure that they don’t bridge

over to another terminal or wire, causing a short circuit.

3. Typically one conductor is marked in some way, either with printing

on the outer jacket, dierent color wire conductors, a formed ridge on

the outer jacket or a thread running within one of the conductors. By

convention the marked conductor is the positive or hot lead (Red).

4. It is very important to maintain proper phasing by hooking the

positive leads to the positive terminals and negative leads to negative

terminals on every component. If one speaker is wired backwards there

will typically be a lack of bass response and the sound may appear to

wander between the speakers rather than be precisely placed.

Pin connector - Loosen the post, insert the pin into the side hole on the

binding post, then tighten the post.

Spade connector - Loosen the post. Insert the spade so that it hugs the

binding post, then tighten the post.

Banana plug connector - Make sure the post is tight. Insert the banana

plug as far as it will go into the top hole of the binding post.

Bare or tinned wire - Strip the speaker wires, exposing approximately 1/2

inch (14mm) of wire. Individually twist each conductor to keep the strands

of wire bundled together. Loosen post, insert wire into the side hole of the

binding post, then tighten the post.

RCA connector - Use the RCA connectors for powered/active subwoofers

or for any device requiring an RCA cable.

02.16.17, Rev.1
