•Please read this manual before using and note how

to use in the proper manner.

Please be careful of keeping the manual.

Otherwise, it should be bought separately.

•The User’s Manual is for common use.

Make use of the User’s Manual depending upon

your washing machine model.

FEATURES............................................................................................2

Keeping the tub clean............................................................................2

SAFETY INSTRUCTIONS.....................................................................3

DESCRIPTION OF PARTS ...................................................................4

CHECKING BEFORE WASHING AND CARING FOR GARMENTS ......5

CONTROL PANEL ................................................................................6

HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY ....... 7

Cleaning the tub ....................................................................................8

MANUAL FUNCTIONS .........................................................................9

INSTALLATION & MAINTENANCE......................................................9

Environment...........................................................................................9

Levelling.................................................................................................9

Connecting the water supply hose ......................................................10

Assembling the rat protection panel ....................................................11

How to connect the drain hose ............................................................11

How to add the fabric softener.............................................................12

How to put the detergent in .................................................................12

Water supply connector ﬁlter ...............................................................12

Cleaning the ﬁlter.................................................................................12

How to clean the pump ﬁlter................................................................12

TROUBLESHOOTING ........................................................................13

WASHING MACHINE WON’T WORK .................................................13

SPECIFICATIONS...............................................................................14

CODE NO.: DC68-02040Q_EN

WASHING MACHINE

User’s Manual

WA95F3/WA90F3

www.samsung.com/global/register

- 2 -

FEATURES

■RUST-PROOF FIBER BODY

• Made of durable material with rust-proof fiber body, it can endure humidity

for an extended time.

■AUTO RESTART

• The power is turned on automatically after power failure.

■SAVING ENERGY

• The ECO+ COURSE, it is a wash course to saving the energy reduces

laundry time for frequent and soiled clothes.

■DIGITAL CONTROL

Digital control operates with best washing course by sensing the washload

like artiﬁcial intelligence.

■TRANSPARENT WINDOW

This Transparent Window is the new concept to solve the curiosity of users

to see inside of washing machine while operation.

While operation, the laundry progress inside of washing machine can be

checked by looking through the transparent window.

■PULSATOR

The Pulsator helps water and detergent to go through fabrics efﬁciently

while providing both the powerful water action to clean lager and heavier

clothes and the gentle water action to clean all delicates with less wear and

tear on clothes.

■WATERFALL FLOW

The Waterfall Flow injected from under the pulsator cascades with full force

back into the tub, pushing down any clothes that ﬂoat right under the water

surface. It is this Waterfall Flow that enables this washing machine to effec-

tively wash large and heavy items, such as bluejeans and blankets.

■MAGIC FILTER

This unique magic Filter ensures that all the lint inside the tub is captured

for top quality ﬁltering results to deliver consistently effective cleaning

results.

■SOFTENER DISPENSER

The Softener Dispenser releases the fabric softener at the appropriate time

when the last rinsing proceeds.

■SUPER CLEAN

SUPER CLEAN adjust the level of water by 5 steps so as to enhance deter-

gent efﬁciency by adjusting the density of detergent to normal density.

■CHILD-LOCK FUNCTION

This is a device to protect children from being accidentally hurt while playing

with the washer.

How to start Child-Lock function:

•Press the “Power” button to go to an initial washing mode.

•By pressing “Start/Hold” button, you start washing and in case Child

Lock function is needed during the laundry

•Press both the “WATER LEVEL” and “FUNCTION” buttons in simulta-

neously and get the function started.

(Note: You cannot perform the function without the “Power” button on.)

To release the function of Child-Lock:

•In case the “Child-Lock” is programmed, press both the “WATER LEVEL”

and “FUNCTION” buttons in simultaneously.

આKeeping the tub clean

When using the machine under humid conditions for an extended time,

various bacteria from the air may stick to the tub and form black dirt (fungi),

causing damage to the human body. To keep the tub clean and hygienic at

all times, it is recommended reading “Cleaning the Tub” above and using

only dedicated or recommended detergents to clean the tub regularly at

least once every one to three months.
