Tachometer

USER MANUAL

Description of the device

1. OK key

2. Backlight key

3. Select key

4. On/Off/Esc key

5. Hold/min/max key

CT 110

Technical specications

Measuring elements

Optical tachometry: optical detection (Phototransistor sighting distance max. 40 cm)

Contact tachometry: ETC adaptator for optical tachometry probe

Display

4 lines, LCD technology. Dimensions: 50 x 36 mm

2 lines of 5 digits with 7 segments (value)

2 lines of 5 digits with 16 segments (unit)

Connector Coiled, 0.45 m length, extension: 2.4 m

Housing ABS, protection IP54

Keypad 5 keys

European directives 2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE

Power supply 4 batteries AAA LR03 1.5 V

Ambience Neutral gas

Conditions of use (°C, %RH, m) From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.

Storage temperature From -20 to +80 °C

Auto shut-off Adjustable from 0 to 120 min

Weight 190 g

General features

Parameters Measuring units Accuracy

(1)

Measuring range Resolution

Optical tachometer rpm

From 60 to 10 000 rpm:

±0.3% of reading ±1 rpm

From 10 001 to 60 000 rpm: ±30 tr/min

From 60 to 60 000 rpm 1 rpm

Contact tachometer

rpm, m/min,

ft/min, in/min, m/s

From 30 to 3000 rpm:

±1% of reading ±1 rpm

From 30 to 3000 rpm 1 rpm

(1)

All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.

Once the measurements are frozen :

• Press again on “Hold/min/max“.

The device displays the maximum value of velocity measured since the last questioning at the top of the screen and the

minimum value of velocity measured since the last questioning at the bottom of the screen.

• Press again on “On/Off/Esc“ to return to the measurement display.

Display the minimum and the maximum

• Turn on the device by pressing on “On/Off/Esc“.

The device displays its name “CT110“.

• Put the probe to the required location.

The device displays the measured velocity.

Perform a measurement

During a measurement :

• Press on “Hold/min/max“ to freeze the measurement.

“Hold“ displays on screen and the measurements are frozen.

• Press on “On/Off/Esc“ to exit the hold function.

The device returns to the measurements display.

Freeze the measurement

Adjust the device

Device drop-down menu

If the type of selected probe is the contact probe, put the contact tip on the probe.

Select the probe type

It is possible to select the probe type: optic probe or contact probe.

• Press on “Select“.

“PROBE“ blinks on screen.

• Press on “OK“.

The probe type currently used blinks on the screen.

• Press on “Select“ to select “OPTIC“ for the optic probe or “CONT“ for the contact probe.

• Press on “OK“ to validate.

“PROBE“ blinks on screen.

• Press on “On/Off/Esc“ to return to the measurement display.
