CLASS 320 KISTOCK DATA LOGGERS

Quick Start Guide

KT320 / KTT320 / KCC320 / KPA320 / KP320 / KP321

EN FR ES ZH

Kimo, a Sauermann brand.

sauermanngroup.com

English

Quick start guide

Operating temperature, protection of the instruments and information about storage and the battery

1 Display

•

Operating temperature*:

KT320: from -40 to +70 °C / -40 to +158 °F; KTT320: from -20 to +70 °C / -4 to +158 °F;

KCC320, KPA320, KP320 & KP321: from 0 to 50 °C / 32 to 122 °F

• KT320: IP65; KTT320: IP54; KCC320, KPA320: IP40, KP320, KP321: IP65*

• Storage temperature: from -20 to +50 °C / -4 to 122 °F

Battery power supply: 2 x lithium AA 3.6 V batteries

*With the pressure connectors plugged

2 Dimensions (mm)

Five recording modes

KISTOCK can record in 5 different ways:

• ”Immediate” mode records values according to a predened interval.

• ”Minimum”, ”Maximum” and ”Average” record automatically the calculation of minimum, maxi-

mum or average of measured values during an interval of recording.

• ”Monitoring” mode allows to get an accurate history report during error events to help troubleshoot-

ing, without stopping the measurement logging. To proceed this way, you just have to dene:

- a record interval to be used whilst the readings are beyond the setpoints

- a record interval for the values measured during each reading beyond the setpoints

• Furthermore, you can also let your KISTOCK record non-stop (”loop” recording option).

Four types of dataset start

Once your recording mode has been set, you can launch your dataset:

• With a delayed start (with predened date and time)

• With the software

• With push-button

• With ”Online” option. In this case, your datasets are directly sent, saved and displayed on your PC in

real time.

Six types of dataset stop

You can stop your dataset:

• According to a date and time (if it was started the same way)

• According to a period

• According to a predened number of recording points

• Once the storage capacity is full

• With ”Stop” option of the software

• By holding ”OK” key during 5 seconds, if this function has been previously activated by the software

5 Recorder function

Reference Parameters

KT 320 Temperature, humidity, current, voltage, electric pulses

KTT 320 Temperature

KCC 320 Temperature, humidity, atmospheric pressure, CO

KPA 320 Temperature, humidity, atmospheric pressure

KP320, KP321 Differential pressure

°C: Temperature in °Celsius.

°F: Temperature in °Fahrenheit

%RH: Relative humidity

DATASET is nished.

Indicates that one value is being recorded.

It ashes: the DATASET did not start already.

Flashing slowly: DATASET is between 80 and 90% of the storage capacity.

Flashing quickly: DATASET is between 90 and 100% of the storage capacity.

Constant: storage capacity full.

Constant: indicates that the batteries have to be replaced.

Indicates the channel number which is measuring.

Screen actualisation of measured values.

The displayed values are the maximum/minimum values recorded

for the channels displayed.

Indication of the direction of exceeding the threshold in the

recorded measurement

REC

END

BAT

ACT

MIN

MAX

1 2

3 4

FULL

KT320 KTT320 KCC320, KPA320

3 Connections

KP320, KP321

PC connection

Micro-USB

connector

KT 320: 2 mini-DIN connections

KTT 320: 4 mini-thermocouples

connections

KP320, KP321: Two pressure

connections
