KIRAY 100

Infrared thermometer

DATA SHEET

Spectral response 8 - 14 μm

Optical D.S: 20:1 (13 mm at 260 mm)

Temperature range From -50 to +800 °C

Accuracy*

From -50 to +20 °C: ±2.5 °C

From +20 to +300°C: ±2% of reading ±2°C

From +300 °C to +800 °C: ±2% of reading

Infrared repeatability

From -50 to +20 °C: ±1.3 °C

From +20 to +800 °C: ±0.5% or ±0.5 °C

Display resolution 0.1 °C

Response time 150 ms

Emissivity Adjustable from 0.10 to 1.0 (pre-set at 0.95)

Over range indication Display indication : "----"

Dual laser sighting

Wave length: from 630 nm to 670 nm

Output < 1mW, Class 2 (II)

Positive or negative

temperature indication

Automatic (no indication for a positive temperature)

(-) sign for a negative temperature

Display 4 digits with LCD backlighted display

Auto-extinction Automatic after 7 seconds of inactivity

High/low alarm

Flashing signal on display and beep signal

with adjustable thresholds

Power supply Alkaline 9 V battery

Autonomy

105 h (inactive laser and backlight)

20 h (active laser and backlight)

Operating temperature

From 0 to +10 °C for a short period

From +11 to +50 °C for a long period

Storage temperature From -10 °C to +60 °C

Relative humidity From 10 to 90%HR in operating mode and > 80%RH in storage

Dimensions 145 x 95 x 40 mm

Weight 180 g (included battery)

*Accuracy for an ambient temperature from 23 to 25 °C (with a relative humidity lower than 80% RH).

Infrared thermometer KIRAY 100 with dual laser sighting is a key tool to diagnose,

inspect and check any temperature, with the advantage of using “no-contact”

technology. You can safely measure surface temperatures of hot objects, dangerous

or difcult to access. Perfect tool to take temperature in a house, a garage, a

workshop, an ofce, a car, a kitchen etc...

Technical specications

°C

°F

Distance from the target

Make sure that the target is larger than the

size of the laser sighting.

Display

FT_EN – Kiray 100 – 29/10/18– Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.

www.sauermanngroup.com

1 – Technical unit °C/°F

2 – Low battery indicator

3 – Emissivity value = 0.95 (factory setting)

4 – Max temperature indicator.

5 – Temperature value

6 – Current measurement indicator

7 – HOLD indicator (xed measurement)

8 – Laser in operation indicator

9 – Lock indicator (continuous measurement)

10 – High alarm symbol (xed : activated alarm ;

ashing + beep : alarm thresholds exceeded)

11 – Low alarm symbol (xed : activated alarm ;

ashing + beep : alarm thresholds exceeded)

Description

1 - LCD backlighted display

2 - IR sensor (infrared)

3 - Up button

4 - Down button

5 - Mode button

1 - Output laser sighting

2 - Trigger

3 - Set technical unit

(°C/°F)

4 - Battery compartment

Kiray 100 buttons

1 – Up button: It allows to increment

emissivity and high/low alarm thresholds.

This button also allows in measurement

mode to activate or deactivate the laser.

2 – Mode button: It allows to navigate

through the modes (emissivity, lock, high

alarm, low alarm).

3 – Down button: It allows to decrement

emissivity and high/low alarm thresholds.

This button also allows in measurement

mode to activate or deactivate the

backlight.

Kit content

• Case with passer-by belt

• User manual

CE certication

This device meets with following standards’ requirements:

EN 61326-1: 2013 and EN 61326-2: 2013

Infrared thermometer, how does it work?

Infrared thermometers can measure the surface

temperature of an object. Its optic lens catches the

energy emitted and reected by the object. This

energy is collected and focused onto a detector. This

information is displayed as temperature. The laser

pointer is only used to aim at the target.
