Conguration and data viewing

software freely downloadable

KT 50 - KH 50

KISTOCK Data logger

or HVAC - Temperature, Humidity

Conguration and data processing

software available as option

16,000 measurement points

Measure up to 2 parameters

• 2 congurable setpoint alarms

• 1 line LCD display

• Fast data download (1,000 values/second)

• IP65 (KT 50) and IP20 (KH 50) housing

DATA SHEET

KT 50 KH 50

Units displayed °C, °F °C, °F, %RH

Resolution 0.1 °C, 0.1 °F 0.1 °C, 0.1 °F, 0.1 %RH

External inputs Micro-USB connector

Internal sensor Temperature Humidity, temperature

Setpoints alarm 2 setpoint alarms on each channel

Frequency of measurement From 1 minute to 24 hours

Operating temperature

(1)

From -40 to +70 °C

-40 to +158 °F

From -20 to +70 °C

-4 to +158 °F

Storage temperature From -20 to +50 °C / -4 to +122 °F

Battery life 500 days

(2)

365 days

(2)

Standards

2014/30/EU EMC; 2014/35/EU Low Voltage;

2011/65/EU RoHS II; 2012/19/EU WEEE;

FCC part 15; UL 61010

General features

Magnetic

mounting

(1)

The screen can be hard to read, and its display speed often slows down at temperatures lower than 0 °C / 32 °F. This has no effect on the accuracy of measurements.

(2)

Non-contractual value. Based on 1 measurement each 15 minutes at 25 °C / 77 °F. A correct operation of the device and the storage conditions must be respected.

°C

°F

Housing

Dimensions 61.3 x 40 x 21.9 mm / 2

’’ x 1

’’ x

’’

Weight 40 g / 1.42 oz

Display

1 line LCD screen

Screen dimensions: 26.5 x 22.5 mm / 1

‘‘ x

’’

Control 1 OK key

Material

Compatible with food industry environment

ABS housing. Caps made of Elastomer

Protection rating IP65: KT 50. IP20: KH 50

PC communication 1 micro USB input

Battery power supply 2 x CR2032 (lithium 3 V)

Environmental

conditions of use

Hygrometry: in non-condensing condition

Maximum altitude: 2000 m / 2188 yd

Air and neutral gases

KT 50 TemperatureInternal sensor

Type of sensor NTC

Measuring range From -40 to +70 °C / -40 to +158 °F

Accuracy*

±0.4 °C from -20 to 70 °C ±0.8°C below -20 °C

±0.8 °F from -4 to 158 °F ±1.5 °F below -4 °F

Technical specications

* All accuracies indicated in this document were stated in laboratory conditions and can be guaranteed for

measurements carried out in the same conditions, or carried out with calibration compensation.

** Factory calibration uncertainty: ±0.88 %RH. Temperature dependence: ±0.04 x (T-20) %HR if T<15 °C or T>

25 °C / ±0.04 x [((T°F - 32) x 5/9) -20] %RH (if T<59°F or T>77°F).

KH 50 Hygrometry TemperatureThermo-hygrometer

Type of sensor Capacitive NTC

Measuring range From 0 to 100% RH

From -20 to +70 °C

-4 to 158 °F

Accuracy*

±2.5 %RH (from +15

to +25°C / +59 to

+77 °F from 5 to 95

%RH)**

±0.4 °C from 0 to +50 °C

±0.8 °F from +32 to +122 °F

±0.8 °C below 0 °C or

above +50 °C

±1.5 °F below 32 °F or

above 122 °F

EN 12830

KT 50

DS_EN – KT 50 - KH 50 – 20/03/2025 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.

Dimensions

40 mm / 1 9/16’’

60 mm / 2 23/64’’

Maintenance: Avoid using aggressive solvents.

Protect the device from cleaning products containing

formaldehyde, which may be used for room and duct

cleaning.

Precautions for use: Always use the device as intended

and within the specied technical parameters to maintain its

protective features.

Only use the accessories

provided with the device.

Accessories

• 2 CR2032 batteries pack. Ref. P2-50

• Data collector: collects up to 20,000,000

points from one or several KISTOCK directly

on-site. Results restitution on PC of realised

datasets. Ref: KNT-320

Connections

PC connection input

Micro-USB connector

EN12830 STANDARD

KT 50 models dedicated to food industry, meet with requirements

of EN 12830 norm. This certication is required for transportation,

storage and distribution of refrigerated, frozen and deep-frozen

food, and ice cream Certication is done by an independent

laboratory, COFRAC accredited.

Recorder functions

The KISTOCK records measured values instantly and logs data at

predened intervals. Additionally, continuous operation is possible

with loop recording.

3 types of dataset start

The measurement dataset can be launched:

• With a delayed start (with predened date and time)

• With the software

• With push-button

6 types of dataset stop

You can stop your dataset:

• According to a date and time (if it was started the same way)

• According to a recording duration

• According to a predened number of recording points

• If the storage capacity of the memory is full

• With “Stop” option of the software

• By holding “OK” key during about 5 seconds, if this function has

been previously activated by the software.

Software Mounting

Freely downloadable software on sauermanngroup.com

KILOG Lite software allows to congure the data logger, to

view data and to save data in PDF le.

Conguration and data processing software

KILOG software allows you to congure, save

and process your data in a very simple way.

• Software only: ref. KILOG-3-N

• Complete set: software + 1 interface. Ref. KIC3-N

1. Necklace for anti-theft

2. Batteries cover

3. Magnetic xing

4. Locking sign of the batteries cover

USB-micro USB cable: CK50

This cable allows you to connect your KISTOCK

to your PC.

Replace the batteries

With 500 days* battery life, KISTOCK ensure long-term

measurements. To change the batteries:

• Unlock the battery cover with a screwdriver or a coin.

• Put the 2 batteries superimposing them (3 V CR2032 button

batteries) with the + pole visible.

• Put back the batteries cover: the sign of the batteries cover must

be placed in front of the opened padlock.

• Turn right the batteries cover: the sign on the batteries cover

must be placed in front of the closed padlock.

Display

°C: Temperature in degrees Celsius

°F: Temperature in degrees Fahrenheit

%RH: Relative humidity (KH 50)

Dataset is nished

Records the values at the moment when this indicator appears / ashing: the dataset has not yet started

Slow ashing: dataset is taking between 80 and 90% of storage capacity

Fast ashing: dataset is taking 90-100% of storage capacity

Constant: storage capacity lled up

Displayed values correspond to maximum and minimum values of the channels

Alarm action type: rising or

falling action

Flashing on the screen + ashing of LEDs:

means that the battery must be changed

BE CAREFUL! Material damages can happen. Please follow the recommended precautions.

*For a KT 50. Non-contractual value. Based on 1 measurement each 15 minutes

at 25 °C / 77 °F. A correct operation of the device and the storage conditions must

be respected.

KISTOCK can be mounted in different ways, you can also move it or

install it very easily.

• Magnetic mounting (see photo)

Calibration

KISTOCK data loggers can be supplied with an optional calibration certicate.

21.5 mm

27/32’’

sauermanngroup.com

Kimo, a Sauermann brand.
