Side 1/2
MP 110 - MP 111
MP 115 - MP 112
Manometer
DATA SHEET
Parameter Models Measuring units Accuracy Measuring range Resolution**
Pressure
MP 110
Pa, mmH
2
daPa
±0.5% of reading ±0.008 inWg
(±0.5% of reading ±2 Pa)
From -4.01 to 4.01 inWg
(from -1000 to +1000 Pa)
0.01 inWg
(1 Pa)
MP 111
kPa, mmH
2
mbar, mmHg, daPa
±0.5% of reading ±0.079 inWg
(±0.5% of reading ±2 mmH
2
O)
From -39.370 to +39.370 inWg
(from -1000 to +1000 mmH
2
O)
0.001 from 0 to ±7.87 inWg
Beyond: 0.01 inWg
(from 0 to ±200 mmH
2
O: 0.1 mmH
2
O
Beyond: 1 mmH
2
O)
MP 115
kPa, inWg, mbar,
mmHg, PSI
±0.5% of reading ±0.03 PSI
(±0.5% of reading ±0.5 mbar)
From -7.252 to 7.252 PSI
(from -500 to +500 mbar)
0.01 PSI
(0.1 mbar)
MP 112
kPa, inWg, mbar,
mmHg, PSI, bar
±0.5% of reading ±0.0073 PSI
(±0.5% of reading ±2 mbar)
From -29 to 29 PSI
(from -2000 to +2000 mbar)
0.001 PSI
(1 mbar)
Features
• Air and neutral gas pressure
measurement
• Selection of units
• Manual auto-zero
• Hold function
• Display of minimum and
maximum values
• Congurable auto shut-off
• Backlight
Technical specications
Selection of unitsEasy to use
Manual auto-zeroHold-min-max functions
Supplied with
CALIBRATION
certicate*
*Except class 110 S which is supplied with adjustment certicate.
**All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
These handheld micromanometers are easy-to-use devices that offer reliable, accurate
and fast measurements. They are used in HVAC systems to maintain the balance of venti-
lation and occupant loads.
This device can also optimize equipment performance and boost service life.
Measuring element Piezoresistive sensor
Tolerated
overpressure
MP 110: 100.37 inWg (250 mbar) / MP 111: 281.03 inWg (700 mbar)
MP115: 20.31 PSI (1.4 bar) / MP112: 43.52PSI (3 bar)
Connector
MP 110 / 111: ¼’’ diameter (6.2 mm)
barbed connectors made of nickelled brass
MP 115 / 112:
3
/
16
‘‘ diameter (4.6 mm)
barbed connectors made of nickelled brass
Display
4 lines, LCD technology.
Dimensions 1
31
/
32
x 1
13
/
32
’’ (50 x 36 mm)
2 lines of 5 digits with 7 segments (value)
2 lines of 5 digits with 16 segments (unit)
Housing ABS, protection IP54
Keypad 5 keys
Standards
2014/30/EU EMC; 2014/35/EU Low Voltage;
2011/65/EU RoHS II; 2012/19/EU WEEE; FCC part 15
Power supply 4 batteries AAA LR03 1.5 V
Battery life 180 hours
Ambience Neutral gas
Conditions of use
°F (°C), %RH, p2-yd (m)
From 32 to +122 °F (0 to +50 °C). In non condensing conditions.
From 0 to 2188 p2-yd (from 0 to 2000 m)
Storage
temperature
From -4 to +176 °F (-20 to +80 °C)
Auto shut-off Adjustable from 0 to 120 min
Weight 0.485 lbs (220 g)
General features Dimensions (in ‘‘/mm)
Kit content
Accessories
DS_EN-US – MP120 – 01/10/24 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Operating principle
Piezoresistive Sensor
When pressure is applied, it deforms the silicon layer, generating a voltage at
its terminals. This voltage is directly related to the amount of pressure applied.
Voltage
Vacuum
Silicon layer
Pressure
2 25/32’’ / 71.5 mm
5 25/32’’ / 147.9 mm
1 11/32’’
34.2 mm
1/4’’
6.2 mm
5/16’’
8.5 mm
7/8’’
22 mm
Model
Part
Number
Description
MP 110 24615
Manometer with 2 x 39
3
/
8
’’ (1 m) of silicon
tube
5
/
32
’’ x
9
/
32
’’ diameter (4 x 7 mm), stainless
steel tip
15
/
64
’’ x 3
15
/
16
’’ diameter (6 x 100 mm),
calibration certicate and soft transport case
MP 110 S 24712
Manometer with 2 x 39
3
/
8
’’ (1 m) of silicon
tube
5
/
32
’’ x
9
/
32
’’ diameter (4 x 7 mm), stainless
steel tip
15
/
64
’’ x 3
15
/
16
’’ diameter (6 x 100 mm),
adjustment certicate and soft transport case
MP 111 24616
Manometer with 2 x 39
3
/
8
’’ (1 m) of silicon
tube
5
/
32
’’ x
9
/
32
’’ diameter (4 x 7 mm), stainless
steel tip
15
/
64
’’ x 3
15
/
16
’’ diameter (6 x 100 mm),
calibration certicate and soft transport case
MP 111 S 24713
Manometer with 2 x 39
3
/
8
’’ (1 m) of silicon
tube
5
/
32
’’ x
9
/
32
’’ diameter (4 x 7 mm), stainless
steel tip
15
/
64
’’ x 3
15
/
16
’’ diameter (6 x 100 mm),
adjustment certicate and soft transport case
MP 112 24618
Manometer with 2 x 1 m of crystal tube
5
/
32
’’ x
15
/
64
’’ diameter (4 x 6 mm), calibration
certicate and soft transport case
MP 112 S 24721
Manometer with 2 x 39
3
/
8
’’ (1 m) of crystal
tube
5
/
32
’’ x
15
/
64
’’ diameter (4 x 6 mm), ad-
justment certicate and soft transport case
MP 115 24617
Manometer with 2 x 39
3
/
8
’’ (1 m) of crystal
tube
5
/
32
’’ x
15
/
64
’’ diameter (4 x 6 mm), cali-
bration certicate and soft transport case
MP 115 S 24720
Manometer with 2 x 39
3
/
8
’’ (1 m) of crystal
tube
5
/
32
’’ x
15
/
64
’’ diameter (4 x 6 mm), ad-
justment certicate and soft transport case
Model Part Number Description
CQ 15 24633 Magnetic protective housing
ST 110 24635 Soft transport case
Calibration Certicate
Involves comparing an instrument’s values to a standard to
determine measurement errors and associated uncertain-
ties. A calibration certicate ensures that measurements
are traceable to national standards.
Adjustment Certicate
A document that veries a device’s conformity with the
tolerances specied in its data sheet. It conrms that the
device has adhered to the manufacturing process.
Certicates
Maintenance
We provide calibration, adjustment, and maintenance for your instruments
to ensure consistent measurement quality. As part of our Quality Assurance
Standards, we recommend conducting an annual check-up.
sauermanngroup.com
