Manometer

USER MANUAL

Description of the device

1. OK key

2. Backlight key

3. Select key

4. On/Off/Esc key

5. Hold/min/max key

MP 120

Technical specications

General features

*All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.

Measuring element Piezoresistive sensor

Tolerated overpressure 250 mbar

Connector Ø 6.2 mm threaded connectors made of nickelled brass

Display

4 lines, LCD technology. Dimensions 50 x 36 mm.

2 lines of 5 digits with 7 segments (value)

2 lines of 5 digits with 16 segments (unit)

Housing ABS, protection IP54

Keypad 5 keys

European directives 2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE

Power supply 4 batteries AAA LR03 1.5 V

Battery life 180 hours

Ambience Neutral gas

Conditions of use (°C,%RH, m) From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.

Storage temperature From -20 to +80 °C

Auto shut-off Adjustable from 0 to 120 minutes

Weight 220 g

Parameters Measuring units Accuracy Measuring range Resolution*

Pressure Pa, mmH

O, inWg, daPa, m/s, fpm ±0.5% of reading ±2 Pa From -1000 to +1000 Pa 1 Pa

Air velocity m/s, fpm, km/h

From 2 to 5 m/s: ±0.7 m/s

From 5 to 40 m/s: ±0.5% of reading

±0.3 m/s

From 0 to 40 m/s 0.1 m/s

Once the measurement is frozen:

• Press on "Hold/min/max".

The device displays the maximum value of pressure measured during the last questioning at the top of the screen and

the minimum value of pressure measured since the last questioning at the bottom of the screen.

• Press again on "Hold/min/max".

The device displays the maximum value of velocity measured since the last questioning at the top of the screen and the

minimum value of velocity since the last questioning at the bottom of the screen.

• Press on "On/Off/Esc" to returns to the measurement display.

Display the minimum and the maximum

• Turn on the device by pressing on "On/Off/Esc".

The device displays its name "MP120", then performs an autozero.

• Connect the pressure tubes or a differential pressure element to the device (Pitot tube, Debimo blades,..).

The device displays the pressure or/and the measured velocity.

Perform a measurement

During a measurement:

• Press on "Hold/min/max".

"Hold" appears on the screen and the measurements are frozen.

• Press on "On/Off/Esc" to exit the hold function

The device returns to the measurement display.

Freeze the measurement

Adjust the device

Device drop-down menu

Measure and display the velocity

It’s possible to measure and display the velocity on a MP120 manometer. A differential pressure element (Pitot tube,

debimo blades,...) must be necessarily connected to the manometer.

The device is on and displays the pressure measurement.

• Press on "Select".

"VELO" blinks on screen.

• Press on "OK".

"OFF" blinks on screen.

• Press on "Select" to select "ON" then press on "OK" to validate.

"VELO" blinks on screen.

• Press on "On/Off/Esc" to return to the measurements display.

The device is on and displays the pressure and velocity measurements.

• Disconnect the pressure tubes.

• Press on "OK".

"Autozero" displays on the screen, the device performs an autozero, then returns to the measurement display.

Perform an autozero
