SI 1805
Centrifugal pump
Sauermann
®
part # : SI1805SIUN23
Reduced dimensions
The SI 1805 pump is designed to be easily installed whatever the layout of the
premises. Capable of evacuating up to 500 l/h, the SI 1805 pump is suitable for
Strong, the SI 1805 tolerates charged, high temperature and acidic condensates
(pH > 3.4) produced by gas condensing boilers.
Kit content
Benets
• One-piece centrifugal pump with tank (0.5 l)
• Integrated barb end check valve Ø ext. 10 mm (3/8”)
• Power cable: (2 m with European plug)
• Safety switch cord: (1 m, bare ends)
DATA SHEET
High performance
• Can discharge condensates up to 5.4 m
• Up to 500 l/h, for shorter running time
• Low sound level – quiet operation
Versatile
• Easily removable tank and reversible pump, to
allow mounting rather on the left or on the right
of the application and choosing the side of the
water exit.
Easy hydraulic connection
• New quarter turn easily removable check valve,
designed to facilitate Ø int. 10 mm (3/8”) hose plug in.
• 2 inlet holes Ø 24 and 21 mm
High resistance
• Oil and acid resistant oat
• Mechanical structure resistant to shocks
Name #Part
Clear PVC tubing
Ø int. 10 mm (3/8’’),
25 m roll
ACC00911
ACC00915 (Braided)
Inlet adaptors
Ø int. 24/25 mm ACC00936
Ø int. 32 mm ACC00937
Ø int. 40 mm ACC00938
Check valve
For replacement
Ø ext. 10 mm (3/8’’)
ACC00925
Technical specications
Accesories
Applications
Actual ow rates (l/h)
sauermanngroup.com
SI1805SIUN23_EN - 02/12/2024 – Non-contractual document. We reserve the right to modify the characteristics on our products without prior notice.
Max. ow rate 500 l/h
Max. discharge head 5.4 m
Max pressure 5.8 m (owrate = 0)
Sound level in application at 1m (3.3 ft): ≤ 47 dBA
(Measured in Sauermann acoustic lab, pump operating with water)
Mains supply 230 V~ 50/60 Hz - 90 W
Detection levels ON: 32 mm; OFF: 25 mm; Safety: 39 mm
Safety switch NC 4 A resistive – 250V
Max. condensate temperature 65 °C, 80 °C in short peak
Max. condensate acidity pH > 3.4 (Gas condensing boilers)
Thermal protection (overheating) 120 °C (auto-reset)
Operating conditions 30 %: 3 s ON – 7 s OFF
Protection IP20
Safety standards CE and EAC
RoHS directive Compliant
WEEE directive Compliant
Pump dimensions L 195 x W 130 x H 132 mm
Tank dimensions L 195 x W 130 x H 43 mm
Box dimensions L 235 x W 135 x H 185 mm
Weight (including box) 2.0 kg
Packaging 10 pieces
Total tube length (Ø int. 10 mm, 3/8’’)
Vertical Discharge head
5 m 10 m 20 m 30 m
1 m 460 380 280 200
2 m 390 320 240 180
3 m 300 250 190 150
4 m 200 180 130 100
5 m 90 80 60 50
• Column air
conditioning units
• Multi cassettes
• Gas condensing
boilers
• High efciency gas
furnace
• Refrigerated display
cabinets
• Evaporators
• Ducted units
