Thermometer with thermistance
Measuring range Resolution
0.1°C from -20°C to +150°C
±1°C maximum from -20°C to +100°C
Technical
specificationsDescription
• Stainless steel probe: 105 mm
• Ambient temperature for
housing: from -10 °C to +40 °C
• Battery: 1.5 V AAA type, LR03 or
equal. Battery life: about 1 year.
• Dimensions: 100 x 64 x 21 mm
1. Open the battery compartment and
2. Take out the protective cap and insert
the probe for at least 1 cm in the
3. Put the switch on ON/OFF ‘‘ON’’.
4. Put the selector on to T/H ‘‘T’’
program a continuous display or on
‘‘H’’ to hold the displayed value.
In that case, °C ashes: slide on ‘‘T’’
Temperature alarm
configuration
1. Press the button MAX. ALARM
during about 3 seconds: -50°C is
displayed then the screen scrolls.
2. Release the button to stop scrolling.
Select the chosen accurate value, as
each pressure increases the display
3. About 5 seconds later, the screen
displays once again the measured
4. When the measured value reaches
the selected value, the alarm sounds
5. To stop the alarm, press any button.
6. Follow the same procedure to select
the minimum alarm temperature.
The T/H display mode change cancels the alarm congurations.
If the device is not used for a long time, please remove the batteries.
NTang – TH300 – 04/10/24 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Throwing a used battery in the
environment or with household waste
pollutes and avoids the valuable materials
recovering. It is therefore important to limit
the batteries consumption and observe the
- prefer alkaline batteries (they last longer
than saline batteries) and when it is
possible, use rechargeable batteries
- place the used batteries and accumulators
in the dedicated containers available
in local shops. Therefore, metals will be
enhanced and will not pollute environment,
because they contain heavy metals that
are dangerous for health and environment
(mainly cadmium and nickel)
When placing batteries, carefully respect
the polarity indicated on the device and
An incorrect positionning can damage the
device or cause leakages on the batteries,
or in extreme cases create a re hazard or
To ensure a correct operating, the batteries
must be in a good working order. If
an anomaly is detected in the device
functioning, insert new batteries.
Never try to load batteries that are not
rechargeable batteries. They can leak, heat
up, cause a re hazard or an explosion.
Replace all the batteries at the same time.
Never mix saline batteries with alkaline or
The used batteries must be removed from
Also, remove the batteries from your device
if it is not used for a long period. Otherwise
the batteries may leak and cause damages.
Never try to short-circuit the terminals
Never dispose of your batteries in re, they
The accumulators recharging must be
carried out by an adult person.
Remove the accumulators from the device
We recommend the adult to watch out
carefuly the kids during the batteries
replacement in order to ensure the
instructions are observed, or to carry out
the batteries replacement in person.
If a battery is swallawed, immediatly
consult your doctor or the nearest poison
control centre. Do not forget to bring
Precisions & precautions for batteries use
ZA Bernard Moulinet - 24700 Montpon-Ménestérol - France
+33 (0)5 53 80 85 00 services@sauermanngroup.com
Thermometer with thermistance
Measuring range Resolution
0.1°C from -20°C to +150°C
±1°C maximum from -20°C to +100°C
Technical
specificationsDescription
• Stainless steel probe: 105 mm
• Ambient temperature for
housing: from -10 °C to +40 °C
• Battery: 1.5 V AAA type, LR03 or
equal. Battery life: about 1 year.
• Dimensions: 100 x 64 x 21 mm
1. Open the battery compartment and
2. Take out the protective cap and insert
the probe for at least 1 cm in the
3. Put the switch on ON/OFF ‘‘ON’’.
4. Put the selector on to T/H ‘‘T’’
program a continuous display or on
‘‘H’’ to hold the displayed value.
In that case, °C ashes: slide on ‘‘T’’
Temperature alarm
configuration
1. Press the button MAX. ALARM
during about 3 seconds: -50°C is
displayed then the screen scrolls.
2. Release the button to stop scrolling.
Select the chosen accurate value, as
each pressure increases the display
3. About 5 seconds later, the screen
displays once again the measured
4. When the measured value reaches
the selected value, the alarm sounds
5. To stop the alarm, press any button.
6. Follow the same procedure to select
the minimum alarm temperature.
The T/H display mode change cancels the alarm congurations.
If the device is not used for a long time, please remove the batteries.
NTang – TH300 – 04/10/24 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Throwing a used battery in the
environment or with household waste
pollutes and avoids the valuable materials
recovering. It is therefore important to limit
the batteries consumption and observe the
- prefer alkaline batteries (they last longer
than saline batteries) and when it is
possible, use rechargeable batteries
- place the used batteries and accumulators
in the dedicated containers available
in local shops. Therefore, metals will be
enhanced and will not pollute environment,
because they contain heavy metals that
are dangerous for health and environment
(mainly cadmium and nickel)
When placing batteries, carefully respect
the polarity indicated on the device and
An incorrect positionning can damage the
device or cause leakages on the batteries,
or in extreme cases create a re hazard or
To ensure a correct operating, the batteries
must be in a good working order. If
an anomaly is detected in the device
functioning, insert new batteries.
Never try to load batteries that are not
rechargeable batteries. They can leak, heat
up, cause a re hazard or an explosion.
Replace all the batteries at the same time.
Never mix saline batteries with alkaline or
The used batteries must be removed from
Also, remove the batteries from your device
if it is not used for a long period. Otherwise
the batteries may leak and cause damages.
Never try to short-circuit the terminals
Never dispose of your batteries in re, they
The accumulators recharging must be
carried out by an adult person.
Remove the accumulators from the device
We recommend the adult to watch out
carefuly the kids during the batteries
replacement in order to ensure the
instructions are observed, or to carry out
the batteries replacement in person.
If a battery is swallawed, immediatly
consult your doctor or the nearest poison
control centre. Do not forget to bring
Precisions & precautions for batteries use
ZA Bernard Moulinet - 24700 Montpon-Ménestérol - France
+33 (0)5 53 80 85 00 services@sauermanngroup.com
