Pt100 thermometers

USER MANUAL

Device description

1. Backlight key

2. OK key

3. On/Off/Esc key

4. Selection key

5. Hold/min/max key

TR 61 – TR 62

Technical specications

General features

Measuring element Pt100 class A

Number of channels TR61: 1 channel / TR62: 2 channels

Display

4 lines, LCD technology. Size: 50 x 36 mm.

2 lines of 5 digits with 7 segments (value) / 2 lines of 5 digits with 16 segments (unit)

Housing ABS, protection IP54

Keypad 5 keys

Connector Compensated miniature female connectors

European directives 2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE

Power supply 4 batteries AAA LR03 1.5 V

Battery life 180 hours

Ambience Neutral gas

Conditions of use (°C, %RH, m) From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.

Storage temperature From -20 to +80 °C

Auto shut-off Adjustable from 0 to 120 min

Weight 210 g

(1) All accuracies indicated in this document were stated in laboratory conditions and can be guaranteed for measurements carried out in the same conditions, or carried out with required compensation.

Pt100 probes (see related data sheet)

Measuring units Measuring range Accuracy

Resolution

°C, °F From -100 to +400 °C ±0.4% of reading ±0.3 °C 0.1 °C

During a measurement:

• Press “Hold/min/max”.

“Hold” is displayed and the measurement is frozen.

• Press again “Hold/min/max”.

The device displays the maximum value measured since the last questioning of the frozen channel at the top of the

screen and the minimum value measured since the last questioning of the frozen channel at the bottom of the screen.

• For a TR 62 with two connected probes:

The device displays the maximum value of the C1 probe measured since the last questioning of the frozen channel at

the top of the screen and the minimum value of the C1 probe measured since the last questioning of the frozen channel

at the bottom of the screen.

• Press again ”Hold/min/max”.

The device displays the maximum value of the C2 probe measured since the last questioning of the frozen channel at

the top of the screen and the minimum value of the C2 probe measured since the last questioning of the frozen channel

at the bottom of the screen.

• Press again Hold/min/max.

The device displays the maximum value of the delta T since the last questioning of the frozen channel at the top of the

screen and the minimum value of the delta T since the last questioning of the frozen channel at the bottom of the screen.

• Press “On/Off/Esc” to return to the measurement display.

• Turn the device on by pressing “On/Off/Esc”.

Put the probe(s) to the required location.

The device displays the temperature measurement.

If the thermometer used is the TR62 with two connected probes, the device will display the two measurements.

• Press “OK“ to display the delta T between the two measured temperatures.

Perform a meaurement

Hold the measurement, display the maximum and minimum

Select the temperature unit

The device is on and displays the measurement.

• Press “Selection” until “UNIT” blinks on screen. Press “OK”.

The unit currently used blinks on screen.

• Press “Selection” until the required unit appears: °C or °F.

• Press “OK” to conrm the unit selection.

“UNIT” blinks on screen.

• Press ”On/Off/Esc” to return to the measurement display.

Set the auto shut-off

The device is on and displays the measurement.

• Press “Selection” until “AUTO OFF” blinks on screen. Press “OK”.

The time before the device auto shut-off blinks at the bottom of the screen.

• Press “Selection” until the required time before the device auto shut-off appears: 15, 30, 45, 60, 75, 90, 105, 120

minutes or OFF.

• Press “OK” to conrm the selection.

“AUTO OFF” blinks on screen.

• Press ”On/Off/Esc” to return to the measurement display.

Activate or deactivate the keys beep

The device is on and displays the measurement.

• Press “Selection” until “BEEP” blinks on screen. Press “OK”.

“OFF” or “ON” blinks on screen.

• Press “Selection” to activate the keys beep “ON” or deactivate it “OFF”.

• Press “OK” to conrm the selection.

“BEEP” blinks on screen.

• Press ”On/Off/Esc” to return to the measurement display.

Set the device
