Side 1/3
POCKET RGB VIDEO LIGHT
USAGE INSTRUCTIONS
®
®
REMOVE SHOE
MOUNT FROM
BALL HEAD
CHARGE PORT
ON/OFF SWITCH
ON/OFF SWITCH
BRIGHTNESS
HUE/SATURATION/BRIGHTNESS
TOGGLE CCT/RGB
TOGGLE CCT/RGB
KELVIN TEMP
MOUNT TO A CAMERA
To attach to a camera with a shoe mount, screw the included ball head into the bottom of the Pocket
RGB Video Light. Slide the shoe mount adapter on the bottom of the ball head into the camera shoe
mount. Tighten using the knurled knob to secure.
MOUNT TO A LIGHT STAND
To mount to a light stand, unscrew the shoe adapter from the bottom of the ball head and thread the ball
head into any light stand with a ¼”-20 male thread.
CHARGING
Plug the USB end of the supplied power cord into the AC wall adapter. Plug the USB-C end of the cord
into the port on the side of the light. Charging will begin automatically. Charging from a fully drained light
to full power can take up to 2 ½ hours.
BACK PANEL CONTROL
Slide the On/Off bar to the On position. The back panel will display in the mode it was last used.
To change from CCT (color correcting) mode to RGB (color) mode, press the CCT/Hue button in and
hold for 2 seconds. The light will shift to the RGB bulbs. To go back to CCT mode, repeat.
CCT MODE
In CCT mode, the back panel will display:
TOP LEFT: current Kelvin temperature
BOTTOM LEFT: brightness level
TOP RIGHT: expected run time at the current brightness level
To increase brightness, press the upward arrow button until the desired level is reached. Press the
downward arrow to decrease. To increase Kelvin temperature, press the right arrow. Press the left arrow
to decrease the Kelvin temperature. 5600K is considered daylight and 3200K is a tungsten source
similar in appearance to an incandescent household bulb. Adjusting the Kelvin temperature can be used
to achieve color accuracy (5600K) or gradually warm the subject by decreasing. Besides warming the
subject for creative purposes, the feature can also be used to match the available light already present
in any environment. Almost all locations will be somewhere between 3200K and 5600K.
RGB MODE
After switching to RGB mode, the panel will display:
TOP LEFT: “Hue” (color)
MIDDLE LEFT: “Sat.” (saturation)
BOTTOM LEFT: “Int.” (brightness)
“Hue” allows selection of 360 available colors while “Sat.” allows adjustment of the intensity of each
selected color. To select a desired color, press the right or left arrows to scroll through the 360
available colors.
0 = RED, 120 = GREEN, 240 = BLUE
To change the saturation of a selected color, press the CCT/Hue button one time. You can now use the
right/left arrow to increase or decrease the saturation of the color. At any selected color or saturation,
press the up arrow to increase light output and the down arrow to decrease.
SAVAGE UNIVERSAL CORPORATION SAVAGEUNIVERSAL.COM 800.624.8891
