Side 1/16

Version 04-2017

Setup and Operation

P. 1

Setup and Operation

of ’SECU-TANK’ tank monitoring devices

ONE / RELAY software version V6.0x or higher

QUATTRO software version V6.0x or higher

NET / QUATTRO NET software version V6.0x or higher

DATA GSM / QUATTRO GSM software version V6.0x or higher

Content:

Page:

Device setup and probe mounting 2

Control elements and display 2

Setup / Programming 4

Programming examples 7

Tank with interior mantle 8

Special parameters 9

Error codes / error display 12

Add. setup NET / QUATTRO NET 13

Add. setup DATA GSM / QUATTRO GSM 14

Order numbers 15

Maintenance 16

P. 2

Setup and Operation

Version 04-2017

Device setup and probe mounting

Concerning installation and mounting as well as regulations and operation please check the cor-

responding device documentation.

The initial setup is to be performed after completed mounting.

The monitoring devices of the SECU TANK-series are to be used for tank content measurement

and if applicable for data forwarding or transmission.

For programming of the device the subsequent description is to be followed.

Determine the tank data beforehand and enter it in the menu input steps.

To enter the menu mode from the displaying mode press the [Enter] push button.

Confirm the ‘Exit’ menu item in step 0 or 7 or 8 to exit the programming mode and return to the

general displaying mode.

This tank content measuring system is not a safety device.

The device can support the safety device of the tank but cannot replace it.

Control elements and display

Pushbuttons

The device setting is to be performed via three little blue pushbuttons: [ + ] [Enter] [ - ]

They are located on the electronic PCB between the connecting clamps.

Language

The menu operating language is selectable via menu item 18 by pressing the buttons

[Enter] [ + ] [ + ] [ + ] . . . 18. Language/Sprache [Enter] . . .

The setup of the device has to be completed once during the initial setup. After the initial setup

the device operates in the displaying mode with closed cover.

Display panel

The LCD-display consists of 2 rows of 16 characters.

The display has a background lighting for the best readability at all lighting conditions.

Depending on the number of connected measuring probes the following display will be shown:

One tank: Two or more tanks, paging forward… :

In case of more than one tank the displaying of the single tanks shown above can be extended

by showing the total inventory and the percent values of the single tanks.

At menue item ‘6. View’ select ‘Percent = YES ( / No)

(paging forward to)

Tank 2: => ...

T2 Name Content/L

Fillspace/L cm/%

T3 Liter T4 Liter

T1 Name Content/L

Fillspace/L cm/%

Total invent. ∑ Liters

% values: T1 T2 T3 T4

Liters T1 Liters T2

Liters T3 Liters T4
