SENCOR SMR 131 Personal Mobile Radio
USER GUIDE
Antenna
PTT(push to talk)
button
-press and hold to
transmil
(UP)/(DOWN)buttons
-press to change
channels, volume, and
to select settings durina
oroarammina.
CALL button
-press to send a ringing
tone to other PMR units.
Speaker
LCD screen
-Displays the current
Channel selection and
other radio symbols.
MENU button
-press to program the PMR
settings
MIC (mlcrophone)
(Power) button
-press and hold to tum the
PMR unit ON or OFF.
1.LCD Screen
Channel Number. Changes from 1 to 16
as selected by the user.
Displays when battery level goes low.
Displays when Sean function is activated
Displayed when Key Lock function is activated
Displayed when transmitting a signal.
Displayed when receiving a signal.
Displayed the full volume level
2. lnstallation
Belt clip latch
Figure 1
Figure 2
2.1 Removing the Belt clip
a. Pull the belt cliR latch away from the
PMR.
b. While pulling the belt clip latch, push
up the belt chp as shown in Fig. 1.
2.2 lnstalling the Belt clip
a. Slide the belt clip into the slot as
shown in Fig. 2.
b. A click“ indicates the belt cliP. is
locked into its pos1tion.
2.3 lnstalling the Batteries
Figure 3 Figure 4
Notes:
• Use only same type and make of batteries on the PMR units.
• The PMR units have a built-in Power Saver (PS) for maximum
battery life, but when not in use, turn the units OFF to save battery
power
• Remove the batteries if the units wi/1 not be used for a /ong period
of time.
a. Slide down the battery
compartment cover.
b. lnsert the 3xAAA batteries.
Position the batteries according
to the polarity marking on the
battery compartment. See Fig.3
c. Replace the battery cover. See
Fig. 4.
Battery meter
The battery icon is located in the left comer of the LCD panel. This
battery icon will displayed when low battery status. These indicate that
the battery level reaches its minimum level, at this stage the handset
ZLOOHPLWWZREHHSWRQHVDQGWKHQWWZLOODXWRPDWLFDOO\WXP2ႇWKH
power.
Battery life
The PMR has a built in power saver feature to make the batteries last
ORQJHU%XWZKHQ\RXDUHQRWXVLQJWKHKDQGVHWWWµVEHWWHUWRVZLWFKRႇ
to save the battery power.
3. Operation
3.1 Turning the Unit ON/OFF
To Turn ON;
a. Press and hold the
(Power) button. A special „beep“ sound &
will be heard. The LCD screen will display the current channel.
To switch OFF;
b. Press and hold the
(Power) button. A special „beep“ sound
will be heard and the LCD screen will tum blank.
3.2 Adjusting the speaker volume
There are 8 volume levels, the current speaker volume level
is displayed on the LCD screen. To adjust the speaker volume
level, press the (UP) button to increase, or press (DOWN) button
to decrease. The LCD screen will display the speaker volume icon
bars ascending, or descending respectively.
3.3 Receiving a Call
The unit is continuously in receive mode when the unit is tumed.
ON and not transmitting. When a signal is received on the current
channel, the receive signal icon „RX“ will be displayed on the LCD
screen.
3.4 Transmitting (sending)
a. Press and hold the PTT {Push to Talk) button to transmit your
voice. The transmit signal icon TX“ will display on the LCD
screen.
b. Hold the unit in a vertical position with the Mic (Microphone)
FPÃČODZD\IURPWKHPRXWK:KLOHKROGLQJWKH377EXWWRQ
speak into the microphone in a normal tone of voice.
F5HOHDVHWKH377EXWWRQZKHQ\RXKDYH¿QLVKHGWUDQVPLWWLQJ
lmportant:
• ln order for other people to receive your transmission, they must
also be on the same channel that you are currently using. Refer to
the „Changing Channel“ section for more information.
• When the PTT and/or GALL buttons are continuously pressed, your
PMR cannot receive any transmissions.
3.5 Roger Beep
The Roger Beep is a tone which is automatically transmitted
whenever the PTT button is released. This alerts the receiving
party that you have ended the transmission, and you are now in
receive mode.
3.6 Changing Channels
The PMR has 16 available channels. To change channels, in
normal mode;
a. Press the
(Menu) button, the channel icon „1 „on the LCD
screen will start blinking.
b. While the Channel icon is blinking, press the
or button to
select the desired channel. The channel changes from 1 to 16,
or vice versa.
c. Press the
0HQXEXWWRQWRFRQ¿UP\RXUVHWWLQJDQGUHWXUQ
to the standby mode.
Note:
Refer to the :Channel Table“ section of this Owner‘s Manual for
detailed frequency listing.
3.7 Calling (Paging) Tone
You can use the CALL button to send a tone to other users on
the same channel. To activate this feature;
a. With the PMR in normal mode, press and release the
button. The unit will transmit a 2-second page tone to the other
unit/s set with the same channel within transmitting range.
