PLEASE STOP AND READ THIS DOCUMENT

CRITICAL INFORMATION:

DEFAULT LOG IN INFORMATION

Username: Administrator

Password: P@ssw0rd

Note: This user has administrative privileges.

SENECA CONFIDENCE QUICK START GUIDE

This product contains software that must be registered for continued use

and to enjoy the beneﬁts of eligibility for updates. Please take the time to

CONTENTS OF SENECA CONFIDENCE PACKAGE

Quantity Item

1 Seneca Conﬁdence Series NVR Server

2 Power Cords

1 Bezel with Key

1 Keyboard & Mouse

STOP

AND READ

MAIN BACK PANEL CONNECTIONS

I/O Port Connection Port Usage

NIC Port 1 Camera LAN

NIC Port 2 Viewing and Management LAN

USB Port 1 Mouse

USB Port 2 Keyboard

USB Port 3

USB Port 4

USB Port 5

USB Port 4

VGA Video Display

DisplayPort Video Display

DEFAULT 1GBE FIXED IP ADDRESSES

Port Default Label IP Address Mask Gateway

NIC 1* Camera LAN 192.168.1.253 255.255.255.0 192.168.1.1

NIC 2* Viewing and Management 192.168.1.252 255.255.255.0 192.168.1.1

*Comes pre-conﬁgured with static non-routable addresses. This is the recommended operating mode if a DHCP server is not available.

Port 1

Port 2

Viewing and

Management LAN

Camera

LAN

HDMIDisplayPort DisplayPort

Serial

USB 1

USB 2

USB 4

USB 3

USB 5

USB 2

SOFTWARE GUIDANCE IS ON THE BACK PAGE

VIDEO MANAGEMENT SOFTWARE INSTALLATION

WARNING:

Time between installation screens may take up to ﬁve (5) minutes for OS and VMS.

Many VMS’s default to Drive C: during setup as the receptacle for video storage.

It is strongly suggested to use drive letters D: and higher to contain video data.

1. After initial startup and conﬁguration, the system is ready to install the Video Management Software (VMS).

• Select the VMS Installer Icon on the OS desktop

2. Once the VMS Installer is open install the necessary prerequisites, which are listed on the Seneca VMS Installer window

3. Select the VMS followed by the VMS Server or Client application. (This process will take several minutes to load).

• If the VMS is unlisted, go to the manufacturer’s website for installation reference

4. Test to verify the VMS application is working

5. OPTIONAL: Select the Uninstall Seneca VMS Installer to reclaim the space on the OS drive (NOTE: This will not remove the VMS installed, ONLY the installer).

XCONNECT SOFTWARE OVERVIEW

xConnect is a software package that gives health status on the system (including

cameras), pushes out notiﬁcations to the xConnect Monitor, and can send email

alerts once properly conﬁgured.

1. Click on this icon to access the xConnect Management Software

2. Default Log In Information

Username: admin@xconnect

Password: P@ssw0rd

The xConnect Monitor is a desktop application that can run anywhere on the local

network. It shows the health status of the four key areas of the xConnect Management

Software. Please go to to download the software from support.senecadata.com

the module on the landing page.

Additional Help

A full user guide is available within the xConnect Software under the “Help” tab

SERVER INSTALLATION

1. Before starting the Seneca Conﬁdence server, the following must be done: Mount and cable hardware. This includes any stor-

age used external to the NVR appliance.

2. Map and record any changes to be made to factory default settings.

• (i.e. username, password, IP adress, etc.)

3. Connect a keyboard, mouse, and monitor to the server.

4. Referencing manual or Microsoft documentation, make desired additions and changes.

Inability to access appliance or settings could require complete OS and data installation. ALWAYS document

conﬁguration changes.

Hardware mounting, AC cabling, signal

cable connection

Server conﬁguration

when required

Client station and

viewing conﬁguration

Remote management, switch, camera

and viewing LAN conﬁguration

IP CAMERA PRE-INSTALLATION PREPARATION

1. Select IP camera address range and camera group settings

2. Have advanced network and switch conﬁguration requirements on hand

(i.e. port segregation supporting IP SAN trafﬁc, multi-switch settings, POE

settings, etc.)

3. Be aware of special operating system requirements such as the following:

• Drive letter designation for camera video stream storage (DO NOT USE

DRIVE C)—we are partial to X.

• IP address selection for different NIC ports, management port and

connections, RAID

IP CAMERA INSTALLATION

1. Connect camera switch 1GbE ports to Port 1

2. Connect and document camera to switch and switch port number

3. Using the camera manufacturer’s or VMS software, conﬁgure the IP address

for the cameras

SENECA NVR SUPPORT

Seneca customer care group stands ready to assist with any hardware and

operating system assistance.

Contact Seneca Digital Security and Surveillance Support:

Normal Business Hours Outside Business Hours

800.227.3432 option 5 888.227.9994

Available Monday–Friday 8am–6pm EST

NOTE: All Video Management Software (VMS) and IP Camera support questions

should be directed to the VMS and Camera manufacturers.

First level of data protection and integrity begins

with AC power protection.

Please consult your Seneca Account Manager for

properly sized, uninterruptable power supply (UPS).

NOTE: Please reference manual for more detailed conﬁguration information.

WARNING: Power on self test takes several minutes until boots process.

xConnect
