Gigaset A120/A120A/A220/A220A
The handset at a glance
1 Charge status of the batteries:
= e V U
(flat to full)
= flashes: batteries almost flat
e V U flashes: charging
2 Answering machine icon (A120A/
A220A only)
3Display keys
4 End call key and On/Off key
5 Talk key/Handsfree key
6 Control key (
u)
7 Directory key (press down on the
control key)
8 Key 1
Open the answering machine
(A120A/A220A only)/network mailbox
9 Star key
Ringers on/off (press and hold); with
an open connection: switch from pulse
dialling to tone dialling (press briefly)
10 Key 0/recall key
Consultation call (flash): press and hold
11 Hash key
Keypad lock on/off (press and hold);
toggles between upper/lower case
and digits; inserts a dialling pause
(press and hold)
12 Microphone
(handsfree mode A220/A220A only)
1 ±V
11.12. 11:56
INT MENU
1
2
3
4
5
6
7
8
9
10
11
12
Please note
New messages in the calls list/answering machine list/network mailbox list (¢ page 6)
are indicated in the display by the message New messages.
Display keys:
Pressing a key launches the function that appears above
th
at key in the display.
Gigaset service contact numbers:
For personal advice on our range of products and for repairs or guarantee/warranty claims
call:
Service Centre UK: 0845 0318190 (local call cost charge)
Service Centre IE: 0818 200 033 (6.6561 Ct./Call)
Please have your proof of purchase ready when calling.
Display Function when pressed
INT Call other registered handsets
¢ page 9.
MENU Open main/submenu (see menu overview
¢ page 15).
“
Go back one menu level.
U
Scroll up/down or adjust volume with u.
T
Move cursor to left/right with u.
˜
Backspace deletes one character at a time.
OK
Confirm menu function or save entry.
ECO DECT
During a call, the level of the handset's radio signal adjusts automatically according to
the distance between the handset and base station: the shorter the distance, the lower
the signal strength (radiation).
The handset’s radio signal is switched off when it is in standby mode. The base station,
ho
wever, maintains contact with the handset with fewer radio signals.
In addition, the base station radio signals are switched off when the No
Radiation
setting is enabled.
MENU
¤ u Settings ¤ OK ¤ u Base ¤ OK ¤ u ECO DECT ¤ OK ¤ No Radiation
¤ OK (‰= radiation switched off, icon ½ in the left-hand corner of the display)
Please note
◆ All registered handsets must support this feature.
◆ For quick connection of incoming calls the handset repeatedly switches to recep-
tion mode for short periods. This increases energy consumption and therefore
r
educes the standby and talk times.
The base station at a
glance
Registration/paging key:
Search for handsets (press
briefly, "Paging"
¢ page 9)
Register handsets (press and
hold
¢ page 9).
