End of programme as soon as @/stopü(Finished/fluffing) indicator light flashes

Adding or removing laundry

The drying cycle can be interrupted in order to add or remove laundry.

The programme must then be continued or ended.

The drum and the door may be hot!

1. Open the door. The drying process is interrupted.

2. Load or remove laundry and close the door.

3. If required, select a new programme and additional functions.

4. Press the inicio/stop (start/stop) button.

Emptying condensation

Empty the container after every use.

1. Remove the condensation container and hold it

level.

2. Open the locking cap.

3. Pour out the condensation.

Check the valve in the condensation container for dirt:

If there are fluff deposits on the valve

a rinse the valve under running water.

Also pour some tap water into the empty condensation container then pour it out again

through the valve.

To do this, press the valve in and allow all the water to drain out.

4. Close the locking cap.

5. Always push the tank fully back in until it locks in place.

If the depósito (Container) / limp. m/l(Cleaning) indicator

light comes on after emptying the container

asee page 10.

Cleaning the fluff filter

Clean the fluff filter after every use.

1. Open the door and pull out the fluff filter.

2. Remove the fluff (brush your hand over the fluff filter).

If the fluff filter is very dirty or blocked, wash it out with warm water

and dry thoroughly.

3. Replace the fluff filter.

4. Remove fluff from door/door area.

Switching off the dryer

Set the programme selector to o (Off).

Do not leave laundry in the dryer.

Removing the laundry

Your dryer has an automatic anti-crease function. The drum is moved at set intervals for 30 minutes after

the programme has ended. Laundry remains loose and fluffy (for 90 minutes, if additional menos (Easy-

iron) function is selected - depending on model).

... and adapt to individual requirements

Never operate the dryer if it is damaged.

Inform your after-sales service.

Inspecting

the dryer

Sorting and loading laundry

Remove all objects from pockets.

Pay particular attention to cigarette lighters.

The drum must be empty before filling.

Your new dryer

Congratulations - You have chosen to buy a modern, high-quality

Siemens domestic appliance.

A distinctive feature of your dryer is its low energy consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased

to help.

Disposal in an environmentally-responsible manner

Dispose of packaging in an environmentally-responsible manner.

This appliance is designated according to European directive



2002/96/EC which governs waste electrical and electronic

equipment (WEEE).

The directive provides an EU-wide framework for the return and

recycling of old appliances.

For further information about our products, accessories, spare parts

and services, please visit: www.siemens-home.com

Intended use

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5

ʋCare and cleaning . . . . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection / Transport . . . . . . . . . . . 8

ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . . . 9

ʋWhat to do if... / After-sales service . . . . 10

ʋSafety instructions . . . . . . . . . . . . . . . . 11

Preparing for installation, see page 8

Selecting and adjusting the programme

Drying

Condensation container

Control panel

Care and cleaning

Dryer cabinet, control panel, air cooler, moisture sensors

– Wipe off with a soft, damp cloth.

– Do not use abrasive cleaners or solvents.

– Remove detergent and cleaning agent residue immediately.

Clean the air cooler 5 to 6 times a year

or if

depósito (Container) / limp. m/l(Cleaning) flashes after cleaning the fluff filter.

Air cooler

In order to clean it, the air cooler must be removed.

– Allow the dryer to cool.

– Residual water may leak out, so place an absorbent towel underneath

the maintenance door.

1. Unlock the maintenance door (1).

2. Fully open the maintenance door (2).

3. Turn both locking levers outwards (1).

4. Pull out the front insert (2).

5. Remove the air cooler.

Take care not to damage the air cooler.

When cleaning, use warm water only. Do not use hard or sharp-edged objects.

6. Clean the air cooler thoroughly and allow the water to drain off.

Clean the seals.

7. First insert the air cooler (handle at the bottom) and then the front insert.

8. Turn back both locking levers.

9. Lock the maintenance door.

Moisture sensors

The dryer is fitted with stainless steel moisture sensors. The sensors measure the level of

moisture in the laundry. After a long period of operation, a fine layer of limescale may form

on the sensors.

1. Open the door.

2. Clean the moisture sensors using a slightly damp sponge with a rough

surface.

Do not use steel wool or abrasive materials.

Select the drying programme ...

Press the inicio/stop (start/stop) button

Only if your hands are dry.

Only hold the plug by the plug

casing.

Connecting the

mains plug

Drying

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

(Drying at normal temperature.

'cLow-temperature drying a in addition, select delicado (Low heat).

)cDo not machine dry.

Be sure to follow the safety instructions asee page 11!

For example, do not use the dryer for the following fabrics:

– Airtight fabrics (e.g. rubber-coated fabrics).

– Delicate materials (silk, curtains made from synthetic material) a they may crease.

– Laundry contaminated with oil.

Before drying for the first time

– Do not put any laundry in the dryer. Set the programme selector to a timed programme

(asee page 7) and select inicio/stop (start/stop). When the programme has finished,

set the programme selector to o (Off).

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. hand towels).

– Fasten zips, hooks and eyelets, button covers and tie together cloth belts, strips, etc.

– Do not overdry easy-care laundry a risk of creasing.

Allow laundry to finish drying in the air.

– Do not iron laundry immediately after drying, fold items up and leave for a while a the

remaining moisture will then be distributed evenly.

– Knitted fabrics (e.g. T shirts, knitwear) often shrink when tumble dried for the first time

a do not use the seco plus (Extra Dry) programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

adversely affects the drying operation.

– Use the correct dosage of fabric softener as per the manufacturer's instructions when

washing the laundry to be dried subsequently.

– Using a timed programme with a small laundry load a optimisation of the drying result.

Environmental protection/energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine a the higher the spin

speed, the shorter the drying time will be (consumes less energy), also spin easy-care

laundry.

– Use the maximum recommended fill level but do not overload laundry

aoverview of programmes, see page 7.

– Make sure the room is well ventilated during drying.

– Clean the fluff filter after every drying cycle a see page 4.

– Do not block or seal the air inlet.

Only when the appliance is

switched off.

Drum

Programme selector

Only operate the dryer

with the fluff filter inserted.

Air inlet

Fluff filter

ʋexclusively for domestic use,

ʋonly for drying fabrics which have been washed using

water.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

For a detailed programme overview, a see page 7.

Before using the dryer for the first time

run the drying cycle without any laundry asee page 7.

Additional functions/status

and service indicators

ˎdelicadoø

(Low heat)

Reduced temperature for delicate fabrics ', e.g. polyacrylic,

polyamide, elastane or acetate; for longer drying times.

ˎmenos 

(Easy-iron)

Reduces creasing and prolongs the anti-creasing phase

after the programme has finished.

depósito (Container)

limp. m/l(Cleaning)

Lit a empty the container for condensation.

Flashes

a clean the fluff filter and/or air cooler.

Programme overview see also page 5

After drying:

T-shirt

Shirts

Trousers

Skirts/dresses

Sportswear

Work clothing

Anoraks

Terry towelling/

bath robe

Underwear

Socks

Bed linen

Table linen

Terry towels

Tea towels/

hand towels

c

iron



lightly re-iron

do not iron

mangle

resistentes / algod.

(Cottons)

max. 7 kg

For whites and coloureds made of cotton or linen.

seco para  (Iron Dry) cø@c

è**è*è*è*è*è*è*

seco para guardar

(Cupboard Dry)

ccccccccc@

è*è*è*è*è*

seco plus (Extra Dry) ccccccccc@

*è*è*è*è*è*

sintéticos (Easy Care)

max. 3.5 kg

For non-iron laundry made of synthetic fibres and mixed fabric, cotton.

seco para  (Iron Dry) cø@c

è*è*è*è*è*è*

seco para guardar

(Cupboard Dry)

ccccccccc@

è*è*

programa temp.

(Timed program)

max. 3.5 kg

For pre-dried, quilted, delicate fabrics made of acrylic, or separate small items of laundry.

60 min caliente/quente (warm 60 min)

For multilayer, delicate fabrics made of acrylic fibre or cotton.

40 min caliente/quente (warm 40 min)

20 min caliente/quente (warm 20 min)

For pre-dried, multilayer, delicate fabrics made of acrylic fibre or individual small items of laundry.

Also for additional drying.

20 min frio (cold 20 min)

For all types of fabric. For freshening or airing items of clothing which are not worn very often.

1110 / 9000 420247

*420247*

Siemens Electrogeräte GmbH

Carl-Wery-Str. 34

81739 München/Germany

WT44C101EE

Installation

– Delivery includes: dryer, installation and instruction manual.

– Check dryer for transport damage.

– The dryer is very heavy. Do not lift without assistance.

– Be careful to avoid sharp edges.

– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.

– Do not install in a room which is susceptible to frost. Water may cause damage once it

starts to freeze.

– If in doubt, have the appliance connected by a specialist.

Setting up the dryer

– The appliance plug must always be accessible.

– Ensure that the appliance is installed on a clean,

level and firm surface.

– Do not obstruct the air inlet on the front of the

dryer.

– Keep the area around the dryer clean.

– Level the dryer using the front threaded feet.

On no account remove the threaded feet.

Mains connection For safety instructions,

see page 11.

– Connect to an AC earthed socket. If in doubt have the socket checked by a specialist.

– The mains voltage must be the same as the voltage specified on the rating plate

(

see page 9).

– The connected load and necessary fuse protection are specified on the rating plate.

Changing the power input Ensure that the socket is fused.

Frost protection / Transport

Preparation

Empty the container for condensation

see page 4.

There may be residual water in the dryer.

This can leak out if the dryer is at an angle.

Remove all accessories from

the drum. The drum must be

empty.

Make sure that the air inlet

remains unobstructed

Clean and level

10 A 16 Aor

Set to o

(Off)

Press and hold the delicado

(Low heat) button and turn

the programme selector

once to the right.

Set to o

(Off)

To change the

power input, press

the menos 

(Easy-iron) button.

Do not operate the dryer if there

is a danger of frost.

Do not install the dryer behind a door or a sliding

door which could obstruct the door of the dryer or

prevent it from being opened. Children can then

not be trapped inside and their life endangered.

Technical data

Dimensions (DxWxH) 60 x 60 x 85 cm

Weight approximately 35 kg

Max. capacity 7 kg

Condensation container approx. 4.2 l

Ambient temperature 5 - 35 °C

Connection voltage 220 - 240 V

Connected load 2025/2600 W

Fuse protection 10 A / 16 A

Product number

Rating plate or inside of the door

Production number

You can find the rating plate on the back of the dryer.

Consumption rates

Specifications are average values established under normal

operating conditions. Fluctuations of up to 10 % are possible.

The value on the label is achieved at the maximum heat

setting.

Spin speed in rpm

(residual moisture)

Drying time** in

min incl. 8 min

cooling time

Energy

consumption**

in kWh

Cottons 7 kg 10 A 16 A 10 A 16 A

Cupboard Dry* 1400 (approx. 50 %) 98 90 3.32 3.32

1000 (approx. 60 %) 117 106 3.92 3.92

800 (approx. 70 %) 138 120 4.48 4.48

Iron Dry* 1400 (approx. 50 %) 76 66 2.45 2.45

1000 (approx. 60 %) 91 82 2.94 2.94

800 (approx. 70 %) 106 96 3.43 3.43

Easy Care 3.5 kg

Cupboard Dry* 800 (approx. 40 %) 42 40 1.16 1.16

600 (approx. 50 %) 53 45 1.45 1.45

*Test programmes according to DIN EN 61121.

**The values may diverge from those specified depending on over and

undervoltage, fabric type, composition of the laundry to be dried, residual moisture

in the fabric and the amount of the load.

Optional accessories (order from the after-sales service using the order number)

Washer-dryer stack connection set

The dryer can be placed on top of a suitable washing machine with the same width and depth

to save space. The dryer must be fastened on the washing machine with this connection set.

If the worktop of the washing machine is less than 544 mm deep, please consult the

after-sales service or your specialist retailer.

Platform

For improved loading and unloading. The basket located in the drawer can be used for

carrying laundry.

Built-under installation

A metal cover must be fitted by a specialist instead of the appliance's covering plate.

20311

20460

20290

What to do if ...

If you cannot rectify a fault yourself, please contact our after-sales service. We will always find

an appropriate solution and will avoid unnecessary visits by engineers. Trust the expertise of

the manufacturer and rest assured that the repair will be carried out by trained service

technicians using original spare parts. The contact details of your local after-sales service can

be found in the enclosed

after-sales service directory, or by calling one of these numbers:

– GB 0844 8928999 (Calls from a BT ladline will be charged at up to 3 pence per minute.

A call set-up fee of up to 6 pence may apply.)

– IE 01450 2655

When contacting the after-sales service, please quote the appliance's product number (E no.)

and production number (FD) (see the inside of the door).

Set the programme selector to

o (Off) and remove the appliance plug from the socket.

inicio/stop (start/stop) indicator

lamp does not light up.

Mains plug plugged in?

Programme selected?

depósito (Container) / limp. m/l

(Cleaning) indicator lights up.

Empty container for condensation

see page 4.

depósito (Container) / limp. m/l

(Cleaning) indicator light flashes.

Clean the fluff filter

see page 4.

Clean the air cooler, if required

see page 6.

Dryer does not start. Has the inicio/stop (start/stop) button been pressed?

Door closed?

Programme set?

Programme terminated shortly

after the start.

Ambient temperature greater than 5 °C?

Water is leaking out. Make sure the dryer is level.

The door opens by itself. Push the door closed until you hear it engage.

The required degree of dryness

was not achieved or the drying

time was too long.

Clean the fluff filter

see page 4.

Empty the container for condensation.

Ambient temperature higher than 35 °C

ventilate the

room.

Air inlet may be blocked

clear obstruction.

Unsuitable programme selected?

see page 7.

Dryer installed too closely to other objects? Provide

adequate air circulation.

Mains failure

Restart the dryer.

Fine layer of limescale on the moisture sensors. Clean the

sensors

see page 6.

Laundry damp. Use the next drying programme up or use the timed

programme as a supplement

see page 7.

Warm laundry feels damper than it really is!

The humidity in the room has

increased significantly.

Make sure the room is sufficiently ventilated.

Air inlet blocked?

Clear obstruction.

Make sure that the air cooler is inserted.

One or more indicator lights are

flashing.

Clean the fluff filter and air cooler

see page 4/6.

Check the installation conditions

see page 8.

Switch off, allow to cool, switch back on and restart the

programme.

Power failure. Remove the laundry from the dryer immediately and

spread it out. Heat may escape.

Safety instructions

Emergency

– Pull the appliance plug out of the socket immediately or disconnect the fuse.

ONLY use the

dryer...

– In rooms inside the house.

– Use for drying fabrics.

The dryer must

NEVER...

– Be used for other purposes than those described above.

– Be modified in terms of its technology or attributes.

Dangers

– The dryer must not be used by children or persons who have not been

instructed in its use.

– Do not leave children unsupervised near the dryer.

– Keep pets away from the dryer.

– Remove all objects from the pockets of garments.

Pay particular attention to cigarette lighters

risk of explosion.

– Do not lean or sit on the door

risk of tipping.

– Open the door with care. Hot steam may escape.

Installation

– Fasten down loose leads

risk of tripping.

– Do not operate the dryer where there is a risk of frost.

Mains

connection

– Connect the dryer according to specifications to an AC earthed socket, as

otherwise it cannot be guaranteed that the appliance is completely safe.

– The cable cross-section must be sufficient.

– Only use earth-leakage circuit breakers with the following symbol:

– The appliance plug and socket must be compatible.

– Do not use multiple plugs/couplings and/or extension cables.

– Do not touch or hold the appliance plug with wet hands

risk of electric

shock.

– Never pull the appliance plug out of the socket by its cable.

– Do not damage the mains lead

risk of electric shock.

Operation

– Only load the drum with items of laundry.

Check what has been loaded before switching the dryer on.

– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,

grease or paint (e.g. hair setting spray, nail polish remover, stain remover,

cleaning solvent, etc.)

fire/explosion hazard.

– Hazard due to dust (e.g. coal dust, flour):

do not use the dryer

risk of explosion.

– Do not put laundry containing foamed material/rubber in the dryer

elastic

material may be destroyed and the dryer may be damaged due to possible

deformation of the foamed material.

– Switch off the dryer once the programme has ended.

– The water from condensation is not drinking water and may be contaminated

with fluff.

Defect

– Do not use the dryer if it is defective or if you suspect that it is.

Repairs must only be carried out by the after-sales service.

– Do not use the dryer with a faulty mains cable. In order to avoid risk, have the

mains lead replaced only by our after-sales service.

Spare parts

– Only use genuine spare parts and accessories for safety reasons.

Disposal

– Dryer: pull out the mains plug, then cut the mains cable from the appliance.

Dispose of the appliance at a public disposal facility.

– Packaging: Do not allow children access to items of packaging

risk of suffocation.

– All materials are environmentally friendly and reusable. Dispose of in an

environmentally responsible manner.

Operating

and installation instructions

Observe the safety

instructions on

page 11.

Read these instructions before switching

on the dryer.

Tumble dryer

Produkt Specifikationer

Mærke:	Siemens
Kategori:	Tørretumbler
Model:	WT44C101EE
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	599 mm
Dybde:	635 mm
Højde:	842 mm
Vægt:	45000 g
Produktfarve:	Hvid
Strøm:	10 A
Ledningslængde:	1.45 m
Placering af apparat:	Fritstående
Tilsluttet belastning:	2300 W
Støjniveau:	67 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	7 kg
Maksimal centrifugeringshastighed:	1400 rpm
Indikator for LED-programfase:	Ja
Cyklustid:	117 min.
Anti-krølle funktion:	Ja
Energiforbrug:	3.92 kWh
